WALL MOUNT RANGE HOOD
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS
FOR RESIDENTIAL & INDOOR USE ONLY
INSTALLATION GUIDE & USER'S MANUAL
www.XtremeAirUsa.com
Pro-X Series: PX01-W30/36
PX02-W30/36
PX03-W30/36
PX04-W30/36/42
PX04-W30/36/42-B
PX06-W30/36/42/48
Ultra Series: D02-W30/36
UL02-W30/36
UL03-W30/36
Deluxe Series: DL08-W36/42/48
PAGE
1
Advertisement
Table of Contents
Related Manuals for XtremeAIR Deluxe Series
Summary of Contents for XtremeAIR Deluxe Series
- Page 1 INSTALLATION GUIDE & USER’S MANUAL WALL MOUNT RANGE HOOD Pro-X Series: PX01-W30/36 PX02-W30/36 PX03-W30/36 PX04-W30/36/42 PX04-W30/36/42-B PX06-W30/36/42/48 Ultra Series: D02-W30/36 UL02-W30/36 UL03-W30/36 Deluxe Series: DL08-W36/42/48 IMPORTANT: READ AND SAVE THESE INSTRUCTIONS FOR RESIDENTIAL & INDOOR USE ONLY www.XtremeAirUsa.com PAGE...
-
Page 2: Table Of Contents
: The Important Safety Instructions and warnings in this manual are not meant to cover all possible problems and/or situations that can MPORTANT OTICE occur upon installation of this unit. Use extreme caution when installing, maintaining or operating this or any other appliance. Contact the XtremeAir USA, LLC, Customer Support Team at 1.714.554.9000 or email: support@XtremeAirUsa.com with any concerns or situations that you do not understand. -
Page 3: Height & Clearance
2. HEIGHT & CLEARANCE 3. VENTING REQUIREMENTS IMPORTANT: NEVER exhaust air or terminate ductwork into crawl spaces, between walls, ceiling, attics or garages. All exhaust must be ducted to the outside. Hood mounted too low could result in heat and/or fire hazard. Hoods mounted too high will be hard to reach and will lose its performance and efficiency. -
Page 4: Parts Supplied
7. PARTS SUPPLIED DL08-W48 PX03/ PX04 PX04-B PX06 DL08 PART SKETCH CODE DESCRIPTION PX01 PX02/ UL03 UL02 MANUAL BOOK UPPER/INNER CHIMNEY LOWER/OUTER CHIMNEY CEILING MOUNTING BRACKET BODY MOUNTING ATTACH- BRACKET ATTACH- ATTACH- ATTACH- WALL ANCHOR WALL ANCHOR SCREW UPPER/INNER CHIMNEY SCREW ATTACHE ATTACHED ATTACHED... -
Page 5: Dimensions & Installation Overview
8. HOOD DIMENSIONS & INSTALLATION OVERVIEW PX02-W30/36, UL02-W30/36 PX03-W30/36, UL03-W30/36 PX01-W30/36 PX04-W30/36/42 & PX06-W30/36/42 PX08-W36/42 PX08-W48 www.XtremeAirUsa.com PAGE... -
Page 6: Installation
9. INSTALLATION STEP 1: (OPTIONAL ONLY) PROTECT THE COOK TOP & CREATE WORK STATION Have 2 pieces 2” x 4” x 20” on both sides of stove & plywood on top of them to protect cook top or stove from damage or debris. This plywood will also create a comfortable work station for easy installation of hood unit. -
Page 7: Baffle Filters Install & Removal
STEP 6: SECURE THE HOOD BODY & TEST RUN A. Use a stud finder to find all studs below the hood body. Put blue tape on every stud found. Use 1/8” drill bit to drill though the back of hood in line with blue tape. Secure the hood body by using the 2.0 inches wood screws (provided) through the back of hood to the stud. -
Page 8: Range Hood Operation
11. RANGE HOOD OPERATION IMPORTANT: BEFORE YOU BEGIN For TOUCH SENSITIVE CONTROLS, please DO NOT PRESS. A light touch and hold on the required button for a matter of a (1) one second is all that is needed. CORRECT INCORRECT OUCH THE ENTIRE BUTTON: See illustration on right: 2. - Page 9 F. Remote Control Sensor: Remote control sensor receives infrared (IR) signal from the remote control. The maximum distance for IR data transmission is 10 feet and requires direct line of sight. The transmission distance may vary depending on temperature and remote control battery condition.
-
Page 10: Specification
3. FOR ALL ULTRA SERIES: TYPE 3: MECHANICAL BUTTON CONTROL A. Activating Blower Function: Press your designed speed (1,2,3) B. Turn off power: While the blower (motor) is running, press button (0) to turn off the motors. C. To turn the light ON/OFF While the light is off, press button (4) once to turn on the light. -
Page 11: Use & Care Information
3. The blower or fan seems weak: Check that the duct sized used is at least 6”. Range hood WILL NOT function efficiently with insufficient duct size & loosely secured. Check if duct is clogged or if damper unit (half-circular flapper) is not installed correctly or opening properly. A tight mesh on a side wall cap unit might also cause restriction to the air flow. -
Page 12: Product Warranty
16. LIMITED WARRANTY www.XtremeAirUsa.com PAGE...
