- Page 1 INSTALLATION GUIDE & USER’S MANUAL ISLAND MOUNT RANGE HOOD Model: Pro-X Series PX07-I36 / I42 / I48 IMPORTANT: READ AND SAVE THESE INSTRUCTIONS FOR RESIDENTIAL & INDOOR USE ONLY www.XtremeAirUsa.com PAGE...
-
Page 2: Table Of Contents
: The Important Safety Instructions and warnings in this manual are not meant to cover all possible problems and/or situations that can MPORTANT OTICE occur upon installation of this unit. Use extreme caution when installing, maintaining or operating this or any other appliance. Contact the XtremeAir USA, LLC, Customer Support Team at 1.714.554.9000 or email: support@XtremeAirUsa.com with any concerns or situations that you do not understand. -
Page 3: Height & Clearance
2. HEIGHT & CLEARANCE 3. VENTING REQUIREMENTS IMPORTANT: NEVER exhaust air or terminate ductwork into crawl spaces, between walls, ceiling, attics or garages. All exhaust must be ducted to the outside. Hood mounted too low could result in heat and/or fire hazard. Hoods mounted too high will be hard to reach and will lose its performance and efficiency. -
Page 4: Parts Supplied
BRACKET (W/ 16 ATTACHED BOLTS) (4) 1 ¾” SCREWS ALUMINUM PIPE (EXCEPT PX06-I48) AIR DIVIDER (PX07-I48 ONLY) (2) DUCT CLAMP (EXCEPT PX06-I48) BAFLE FILTER ( 4) PX07-I36/42 (6) PX07-I48 REMOTE CONTROL UPPER “SLOT” CHIMNEY DIMENSION TABLE 10.5 12 5/8 23.0 19.0... -
Page 5: Installation
9. INSTALLATION STEP 2: INSTALLING “CEILING BRACKET” STEP 1: MARKING “CEILING BRACKET” A. Cut out a hole in the ceiling where the ducting A. Put a thick, protective covering over counter top, cook top or will go. Range to protect from damage or debris. B. -
Page 6: Range Hood Operation
STEP 6: INSTALL & REMOVE BAFFLE FILTERS Refer to picture at left for the following steps: 1. Angle baffle filter toward front of hood or control side Figure 1 & 1A 2. Lift a baffle filter up above horizontal level then slide forward into Figure 1A slot behind the front of hood Figure 2 &... -
Page 7: 11 Specification
The system saves user configurations, settings such as light, timer and blower (motor) speed will remain the same the next time it is turned on. 11. SPECIFICATION PX07-I36 & PX06-I42 PX07-I48 Body Design Non-Magnetic 1.0 mm Stainless Steel, Satin Finish Non-Magnetic 1.0 mm Stainless Steel, Satin Finish... -
Page 8: 13 Use & Care Information
3. The blower or fan seems weak: Check that the duct sized used is at least 6”. Range hood WILL NOT function efficiently with insufficient duct size & loosely secured. Check if duct is clogged or if damper unit (half-circular flapper) is not installed correctly or opening properly. A tight mesh on a side wall cap unit might also cause restriction to the air flow. -
Page 9: 15 Product Warranty
15. LIMITED WARRANTY www.XtremeAirUsa.com PAGE...
