Simrad PRO AC70 Installation Manual

AC70 COMPUTER
INSTALLATION GUIDE
For technical specifications,
certificates and declarations,
refer to the product web site on:
pro.simrad-yachting.com www.simrad-yachting.com
*988-10472-001*
Parts included
3
4 2
5 6 7
8
10
9
1
1 * AC70 Computer
2
1 * Cable retainer
3
6 * Fixing screws, 3.5 * 19 mm (DIN7981B)
4
10 * Strips
5
6 * Connectors
6
1 * Receptacle
7
2 * 30 Amp Fuse
8
1* Micro-C Drop cable (male)
9
1* Micro-C T-Joiner
10
1* Micro-C Power cable with 120 Ohm terminator, female
11
1* Micro-C Terminator, 120 Ohm (male)
Mounting
Dimensions
1
211 mm (8.29")
197 mm (7.77")
185 mm (7.27")
11
System wiring
T
1
4
5
NMEA 0183
12 V DC
AC70
12/24V DC
180 mm
(7.08")
80 mm
(3.15")
48 mm
(1.88")
AP70/80
AP60
GPS
SENSOR
AUTOPILOT
2 3
CONTROL
HEAD
12/24V DC
1*
4*
NMEA 0183
OPTION
IN/OUT
IN/OUT
AD80/
SD80
1
Micro-C CAN bus backbone
2
SimNet to Micro-C (male) Drop cable
3
Micro-C Drop cable (female to male)
4
Micro-C Power cable with 120 Ohm
terminator, female
5
THRUSTER
Micro-C Drop cable, male
CONTROL
6
Micro-C T-Joiners
DRIVE UNIT
7
Micro-C Terminator, 120 Ohm, male
60 mm
(2.36")
COMPASS
6 T
7
OPTION
SI80
12/24V DC
