Corally KAGAMA ROLLER C-00474 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LANGUAGES
INSTRUCTION
MANUAL
Check that you have the latest version of this manual before each use.
Contrôlez avant chaque utilisation de ce manuel si vous en avez le dernière version.
Überprüfen Sie vor jedem Gebrauch dieses Handbuchs, ob Sie die neueste Version haben.
Controleer voor elk gebruik van deze handleiding of u over de laatste versie beschikt.
C-00474 Manual (V-4)
www.corally.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KAGAMA ROLLER C-00474 and is the answer not in the manual?

Questions and answers

Related Manuals for Corally KAGAMA ROLLER C-00474

Summary of Contents for Corally KAGAMA ROLLER C-00474

  • Page 1 Contrôlez avant chaque utilisation de ce manuel si vous en avez le dernière version. Überprüfen Sie vor jedem Gebrauch dieses Handbuchs, ob Sie die neueste Version haben. Controleer voor elk gebruik van deze handleiding of u over de laatste versie beschikt. C-00474 Manual (V-4) www.corally.com...

  • Page 2: Read First

    Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com INTRODUCTION Thank you for purchasing a Team Corally car. This manual describes the instructions for using the model and the electronic compo- nents.

  • Page 3: Use Precautions

    Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com USE PRECAUTIONS Failure to operate your model in a safe and responsible manner may result in injury to yourself, others or damage to property around you.
  • Page 4 Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com WARRANTY ( All models ) If material defects or manufacturing faults should arise in a product distributed or manufactured by Team Corally / JSP Group Intl bvba, and purchased by a consumer, we Team Corally / JSP Group Intl bvba acknowledge the obligation to correct those faults or defects within the limitations described below.

  • Page 5: Kit Content

    - Überprüfen Sie die Website corally.com im Download-Bereich und stellen Sie sicher, dass Sie die neueste Version dieses Handbuchs haben (siehe Datum auf dem Umschlag des Handbuchs). - Kijk op de corally.com website in de download sectie en zorg ervoor dat u de laatste versie van deze handleiding heeft (zie datum op de omslag van de handleiding) KIT CONTENT...

  • Page 6: Car Components

    Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com CAR COMPONENTS Front Differential Front Shock Absorber Anti-Roll Bar Suspension Arm...
  • Page 7 Téléchargez le guide de démarrage rapide en Français sur le site • Laden Sie die Kurzanleitung auf Deutsch von der Website herunter • Download de Nederlandse snelstartgids op www.corally.com QUICK START GUIDE ( General for all models) READ THE INSTRUCTIONS CHARGE THE BATTERY INSTALL 4x AA BATTERY - 1.5V...

  • Page 8: Install Electronics

    INSTALL ELECTRONICS (not included) INSTALLER L’ÉLECTRONIQUE (non inclus) • ELEKTRONIK INSTALLIEREN (nicht enthalten) • ELEKTRONICA INSTALLEREN (niet meegeleverd) SERVO INSTALLATION M3x18mm M3x10mm (2) Recommended Servo : Digital Servo - CS-5226 - High Voltage M3x12mm (4) #C-52001 ESC INSTALLATION Recommended ESC : Speed Controller - TOROX 185 - Brushless - 2-6S #C-54011...
  • Page 9 Reglers beschrieben. - Sluit de motor aan op de regelaar zoals beschreven in de handleiding van de regelaar. Apply some Corally Screw Fix - Blue # C-13094 RECEIVER INSTALLATION - Connect the servo cable to channel 1 of the receiver.

  • Page 10: Gear Ratio

    GEAR RATIO - RAPPORT DE TRANSMISSION - GETRIEBEVERHÄLTNIS- VERSNELLINGSVERHOUDING MOTOR PINION MOD1.0 - PIGNON MOTEUR MOD1.0 - MOTORRITZEL MOD1.0 - MOTOR PINION MOD1.0 High-performance pinions gear, manufactured from special steel for toughness and durability with precise tolerances and assures unparalleled concentricity. Created on a special gear machine, all pinions feature ultra-precise tooth shaping and ultra-true running for vibration-free operation.
  • Page 11 GEAR MESH ADJUSTMENT - AJUSTEMENT DE L’ENGRENAGE - GETRIEBEVERSTELLUNG - TANDWIELAFSTELLING If the gear mesh is not correct, you wear out the spur gear prematurely, the transmission will make noise, give unnecessary load on the motor (higher consumption, heating of the transmission).
  • Page 12 FRONT REAR SILICONE OIL SPRING TENSION SILICONE OIL SPRING TENSION SHOCK PISTON TRACK USE 450CPS 400CPS 6 Holes Ø1.3mm OFF-ROAD 600CPS 500CPS 6 Holes Ø1.3mm FACTORY 1000CPS 1000CPS 6 Holes Ø1.3mm .www. corally.com/Chemicals/Silicone-Oils/...

  • Page 13: Shock Absorber

    SHOCK ABSORBER - AMORTISSEUR - STOSSDÄMPFER - SCHOKDEMPER • Do not overtighten the Shock Cap to prevent deformation of the silicone Shock Bladder. • Ne serrez pas trop le capuchon de l’amortisseur pour éviter la déformation de la membrane en silicone. •...

  • Page 14: Differential Maintenance

    Perform the same maintenance operation for the Centre and Rear differentials. Effectuez la même opération d’entretien pour les différentiels central et arrière. Führen Sie die gleichen Wartungsarbeiten für das mittlere und hintere Differential durch. Doe dezelfde onderhoudswerkzaamheden voor het midden- en achterdifferentieel. www. corally.com/Chemicals/Silicone-Oils/ FRONT DIFF CENTRE DIFF REAR DIFF...
  • Page 15 REMOVING THE CENTRE DIFFERENTIAL- DEMONTER LE DIFF CENTRAL - AUSBAU DES MITTELDIFFERENTIALS - VERWIJDEREN VAN HET MIDDENDIFFERENTIEEL It may be necessary to replace the silicone oil every 50 runs (depends on how you drive and the type of terrain you drive on). To remove the centre differential, follow the steps below.

  • Page 16: Front & Rear Differential

    FRONT & REAR DIFFERENTIAL - DIFFÉRENTIEL AVANT ET ARRIÈRE - DIFFERENTIAL VORNE UND HINTEN - VOOR & ACHTER DIFFERENTIEEL C-3002-30-12 (4pcs) C-00180-153-X C-00180-205 C-3611-3-08-16-05 C-00180-179 (set) C-00180-182 C-00180-184 C-00180-178 C-00180-205 C-00180-183 C-00180-182 OPTION C-3611-3-08-16-05 Aluminium 7075 Hard Anodised Aluminium 7075 Hard Anodised Made in Italy Made in Italy C-00180-153-X...
  • Page 17 FRONT DRIVE TRAIN - TRAIN AVANT - FRONTANTRIEB - VOORSTE AANDRIJFLIJN C-00180-117 C-00180-329 C-3004-40-04 C-00180-122 C-00180-108-1 (Set) C-00180-123 (2x) C-00180-957 C-00180-207 C-00180-150 C-00180-108-1 C-00180-532 C-3611-3-08-16-05 (2x) C-00180-530 HEX BUTTON HEAD SCREWS C-00180-1068 DIN 7380 - STEEL - 10 PCS C-00180-341 M3x8mm C-3004-30-05 (x2) #C-3003-30-08...
  • Page 18 REAR DRIVE TRAIN - TRAIN ARRIÈRE - HINTERACHSANTRIEB - ACHTERSTE AANDRIJFLIJN C-00180-005-2 (Set) C-00180-226-B C-3101-30 C-00180-005-2 (Set) C-00180-1065 C-00180-005-2 (Set) C-3101-30 (x4) C-3101-40 C-00180-658 C-3213-30-5 (x2) C-3101-30 C-00180-122 DIN916•M4x4 C-00180-005-2 (Set) C-3101-40 C-00180-148 C-00180-293 C-00180-329 C-00180-539 C-00180-955 C-00180-055 C-3611-3-08-16-05 C-00180-114 C-00180-658 C-00180-553-1 C-3611-3-08-16-05...
  • Page 19 CHASSIS CENTRE Electronics not included C-00180-953 (set) C-00180-959 C-00180-834 C-00180-959 C-54055 C-00180-716 (set) C-3001-40-14 C-00180-722 C-00180-953 (set) C-3001-40-14 C-00180-177 C-3001-40-10 C-3201-40 M4x4 C-3001-40-10 C-00180-716 (set) C-00180-372 C-72113 C-00180-171 C-00180-013 (set) C-00180-305 (x2) C-00180-640 C-00180-605 C-00180-023 C-00180-149 C-00180-013 (set) C-3101-40 C-00180-129 C-00180-044 (x2) C-00180-615 (set) C-00180-018...

  • Page 20: Servo-Saver

    SERVO-SAVER - SAUVE-SERVO - SERVO-SAVER - SERVO-SAVER C-3611-3-06-10-03 C-00180-145 (set) C-00180-036 (set) C-3101-30 C-00180-216 C-3611-3-06-10-03 (x2) C-00180-191 C-00180-145 (set) C-00180-036 (set) C-3611-3-06-10-03 C-3002-30-18 (x2) C-00180-831 C-3611-3-06-10-03 (x2) C-00180-206 C-00180-147 (x2) OPTION C-3003-30-10 (x2) C-3101-30 (x2) C-00180-964 C-00180-150 (x2) C-00180-266 Servo Saver Steering Arm - 7075 T6 - Hard Anodised - Black - 1 pc...

  • Page 21: Spare Parts

    SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-004-1 C-00180-005-2 C-00180-013 C-00180-018 C-00180-023 Centre Diff Bulkhead - Compos- Battery Strap - Hook & Loop Wing Mount - Adjustable - Servo Mount - Receiver Box - Motor Mount Centre Diff Insert - ite - 1 Set - 2 pcs Composite - 1 Set...
  • Page 22 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-220 C-00180-226-B C-00180-230 C-00180-231 C-00180-246 Ball End 5.8mm - for Anti Roll Wing - Composite - 1 pc Wheel Nut - Aluminium - Collar - for Anti-roll Bar - Alu- Anti-Roll Bar - Rear - 2.6mm Bar - Steel - 4 pcs Ribbed - 4 pcs...
  • Page 23 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN C-00180-834 C-00180-871 C-00180-872 C-00180-873 C-00180-831 Steering Rack - Dual Stiffener - Centre Roll Cage Foam - Thick- Suspension Arm Mount HD - RE-FR Suspension Arm Mount HD - FR-RE Suspension Arm Mount HD - RE-RE Aluminium - 1 Pc ness 25mm - 1 pc - 8mm - Aluminium - Black - 1 pc...
  • Page 24 SPARE PARTS - PIÈCES DE RECHANGE • ERSATZTEILE • ONDERDELEN FRONT & REAR DIFFERENTIAL - SPARE PARTS FRONT & REAR DIFFERENTIAL - SPARE PARTS C-00180-090-1 C-00180-156 C-00180-178 C-00180-179 C-00180-184 Centre Diff set - Case + diff Bevel Pinion 13T - Steel - 1 pc Diff.
  • Page 25 - 4 pcs Check the availability of spare parts on the website www.corally.com Visualisez la disponibilité des pièces de rechange sur le site web www.corally.com Sehen Sie sich die Verfügbarkeit von Ersatzteilen auf der Website www.corally.com an. Controleer de beschikbaarheid van reserveonderdelen op de website www.corally.com...

  • Page 26: Option Parts

    OPTION PARTS - PIÈCES D’OPTION - OPTIONSTEILE - OPTIES C-00180-903 C-00180-143-2 C-00180-899 C-00180-316 C-00180-157 HD Steering Ball Joint - Com- Turnbuckle - M5 - 92mm - HD Rear Camber Ball Joint - Wing Washer - Lightened - Shock Cap - Lower - Aluminium posite - 1 set Spring Steel - 2 pcs Outer - Inner - 1 set...
  • Page 27 STEEL SCREWS - VISSERIE ACIER • STAHLSCHRAUBEN • STAAL SCHROEVEN LENGTH LENGTH LENGTH LENGTH HEX FLAT HEAD SCREWS HEX BUTTON HEAD SCREWS HEX SOCKET HEAD SCREWS HEX SET SCREWS DIN 7991 - STEEL - 10 PCS DIN 7380 - STEEL - 10 PCS DIN 912 - STEEL - 10 PCS DIN 916 - STEEL - 10 PCS NOMINAL...

  • Page 28: Ball Bearings

    NUTS - ECROUS • MUTTERN • MOEREN NYLSTOP NUT NYLSTOP NUT - FLANGED NYLSTOP NUT LOW PROFILE NUT ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS STEEL - 10 PCS DIN 936 - STEEL - 10 PCS NOMINAL NOMINAL NOMINAL NOMINAL COLOR COLOR...
  • Page 29 SPORT RACING - LIPO ELECTRONIC Discover our range of Precision CNC-Cut MOD-1.0 Team Corally - Sport Racing 50C - 4S or 6S - XT-90 - A range of high quality electronic equipment Pinions for motors with a ø 5.0mm motor shaft Hard Case for the best performance.
  • Page 30 M2.5 - M3 - M4 - Steel Black - 10 Sizes 10 Sizes - 370 pcs - 320 pcs More info C-38516 Universal Sport Car Series - Screws - Nuts Set - 34 Sizes - 970 pcs C-38520 Shim Ring Set - Steel- 15 Sizes - 375pcs www.corally.com...

  • Page 31: Declaration Of Conformity

    Title/Titel/Titre : Ceo This manual is an edition of Corally, a division of JSP GROUP INTL nv, Geelseweg 80, B-2250 Olen, Belgium. This manual is protected by a copyright and nothing from this edition may be reproduced or used without any prior written authorisation. Whilst every effort has been made to ensure the accuracy of the information in this manual, errors creep in and Corally can accept no responsibility for failures, wrong specifications, accuracy of colours, losses or damages caused.
