Operating and assembly instructions
KNX building
management
system
KNX binary input
Binary input 4-gang, KNX Secure, flush-mount-
ed
TYBS704A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TYBS704A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for hager TYBS704A

  • Page 1 Operating and assembly instructions KNX building management system KNX binary input Binary input 4-gang, KNX Secure, flush-mount- TYBS704A...
  • Page 2: Table Of Contents

    Contents Contents Contents............... 2 Introduction..............3 Safety instructions............5 Scope of delivery............6 Function................ 7 Information for qualified electricians......9 Installation and electrical connection................9 Commissioning........................11 Dismantling..........................16 Appendix..............17 Technical data........................17 Accessories......................... 17 Troubleshooting........................17 Regulatory Compliance Australia..................17 Disposal note........................17 Warranty..........................
  • Page 3: Introduction

    KNX-certified Supports KNX Data Secure Compatibility with Compatibility with Hager easyTool ≥ 7.x KNX S-mode (ETS≥ 5.6.x) Suitable for use in Aus- Suitable for use in China Suitable for use in Morocco tralia and New Zealand Manufacturer’s information...
  • Page 4 Introduction Symbol Description Warning against electric shock. Warning against damage from mechanical stress. Warning against damage from electricity. Warning against damage from fire. Electronic devices may only be assembled, installed and configured by a specialist with electrical training and certification in accordance with the relevant installation standards of the country.
  • Page 5: Safety Instructions

    Safety instructions Safety instructions Electrical devices must only be installed and assembled by a qualified electrician in accordance with the relevant installation standards, guidelines, regulations, directives, safety and accident prevention directives of the country. Hazard due to electric shock. Disconnect before working on the device or load. Take into ac- count all circuit breakers that supply dangerous voltages to the device or load.
  • Page 6: Scope Of Delivery

    Scope of delivery Scope of delivery https://hgr.io/r/TYBS704A Fig. 1: Scope of delivery TYBS704A...
  • Page 7: Function

    Function Function System information This device is a product of the KNX system and corresponds to the KNX guidelines. Detailed spe- cialised knowledge obtained from KNX training courses is required for understanding. The device is KNX Data Secure-compatible. KNX Data Secure can be configured in the ETS project and offers protection against manipulation in building automation.
  • Page 8 Function Correct use – Inputs to poll conventional, potential-free contacts in KNX systems – Sending telegrams to the KNX bus to signal statuses, counter levels, operation of consumers, etc. – Outputs to control LEDs – Installation in wall box with dimensions according to DIN 49073 in combination with a suitable cover –...
  • Page 9: Information For Qualified Electricians

    Information for qualified electricians Installation and electrical connection Information for qualified electricians Installation and electrical connection Danger Electric shock when live parts are touched! An electric shock can lead to death! Disconnect all connection cables before working on the device and cover any live parts in the area! Connection and installation of the device For KNX Secure operation: Remove the device certificate from the device and store it securely...
  • Page 10 Information for qualified electricians Installation and electrical connection Note! When extending the supplied cable sets (see Fig. 3), the maximum cable length specified in the technical data may not be exceeded (see Technical data , page 17). Therefore: The total length of the Com cable per cable set may not exceed 30 m. 25 cm max.
  • Page 11: Commissioning

    Information for qualified electricians Commissioning Outputs can also be connected in parallel to increase the output current. The outputs must be parameterised in the same way. In the example, the In1-In2-In3 outputs are connected in parallel (Fig. Fig. 5: Connection example for parallel-connected outputs Commissioning The device can be programmed in three ways: –...
  • Page 12 Information for qualified electricians Commissioning Note! Use a high-resolution camera to scan the QR code. Fig. 8: Entering the QR code manually Fig. 6: Removing the de- Fig. 7: Scanning the QR code vice certificate from the de- vice (similar to illustration) Document all passwords and keep them in a safe place.
  • Page 13 Special features of localisation in the easyTool The localisation of the universal interface TYBS704A is described in the following steps and differs from the usual procedure for localisation in the easyTool. Localisation is carried out after installing sev- eral (e.g.
  • Page 14 Information for qualified electricians Commissioning Click Confirm The Localization menu box is highlighted in orange. Fig. 13: Screenshot from easyTool ‘Localization’ language-specific Note Localisation of the device is only possible if the menu box is highlighted in orange. Devices can be identified using the programming LED via three different procedures. Procedure 1: Localisation via the product list in the easyTool Select the device to be used in the device list by clicking.
  • Page 15 Information for qualified electricians Commissioning Note If several channels of the same device are highlighted in the channel list, the programming LED remains activated until the last channel of the device is unhighlighted by clicking. Procedure 3: Localisation via the device Press the programming button of the device.
  • Page 16: Dismantling

    Information for qualified electricians Dismantling Dismantling Danger Electric shock when live parts are touched! An electric shock can lead to death! Isolate all connection cables before working on the device and cover any live parts in the area! Dismantling the device Danger Electric shock when live parts are touched! An electric shock can lead to death!
  • Page 17: Appendix

    Appendix Technical data Appendix Technical data KNX Medium TP1 - 256 Configuration mode S-Mode, E-Controller KNX nominal voltage 21 ... 32 V SELV KNX connection mode KNX connecting terminal KNX current consumption 5 ... 12 mA Output voltage 5 V DC SELV Output current per channel Max.
  • Page 18: Warranty

    Appendix Warranty This marking shown on the product or its documentation indicates that it should not be disposed of with other household waste at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this device from other types of waste.
