- Page 1 PRODUCER / ENTITY CONDUCTING ADVERTISING: MyWam sp. z o.o. Manual Supplement to the manual for selected special wheelchairs Edit 5 / 2023-12-05 Indoor base in.basic Accessories for special needs strollers Mewa/Mouse P a g e...
- Page 2 INDOOR BASE in.basic Edit 5 / 2023-12-05 Unfolding the room stand Lift, apply the brakes, unfold the outriggers and tighten them with the star knobs located at the base of the frame (Fig. 1). Photo 1 Unfold the cross supports and tighten with the star knobs to the vertical main frame (Fig. 2-5).
- Page 3 INDOOR BASE in.basic Edit 5 / 2023-12-05 Mewa/Mouse Seat Assembly: Mount the seat forward or rearward facing. a) Lock the brakes (Fig. 8-9). Pic. 8 Good Pic. 9 Bad b) Insert the seat into the tabs of the indoor base until it clicks (Fig. 10-11).
- Page 4 INDOOR BASE in.basic Edit 5 / 2023-12-05 b) adjust the height (the height scale is described by numbers 1-6) (Fig. 14-15). Photo 14 Photo 15 REMARK! Before locking the mechanism, make sure that the height on both sides is identical! c) Lock the clamp (the wings should be on the left side) (Fig.
- Page 5 INDOOR BASE in.basic Edit 5 / 2023-12-05 b) Detach the seat and set the height of the indoor base to the lowest (marked with the number 1). Unscrew the seat mount star knob and retract the cross legs into the mount (Fig. 18).
- Page 6 INDOOR BASE in.basic Edit 5 / 2023-12-05 Technical specification of the in.basic indoor base length of the indoor base 95 cm Width of the indoor base 58 cm Indoor Base Height 104 cm Mass 7.5 kg seat height adjustment 53 - 71 cm...
