Operation and maintenance
manual
Mouse – a modern stroller for the
youngest

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mouse and is the answer not in the manual?

Questions and answers

Related Manuals for MyWam Mouse

Summary of Contents for MyWam Mouse

  • Page 1 Operation and maintenance manual Mouse – a modern stroller for the youngest...

  • Page 2: Table Of Contents

    Contents: The Purpose of the Stroller Mouse Important safety rules and instruction Intention of the manual Construction of the stroller Accessories Anti-Corrosion Protection Reuse of the Stroller The manual The Usage of the Stroller Cleaning and Maintenance Periodical maintenance checks The Stroller’s Technical Data __________________ 28...

  • Page 3: The Purpose Of The Stroller Mouse

    The stroller Mouse is for users who are 70-110 cm hight and weigh up to 35 Statistically, children from the age of 2 to 6 fit these specifications.
  • Page 4 2.10. DO NOT use the stroller if it was damaged or if you suspect it was damaged or if it does not work properly. Contact the Seller and Manufacturer promptly to get advice. 2.11. Make sure you use only the original stroller accessories. 2.12.
  • Page 5 stroller. They are also to prevent your child’s feet from sliding off the footrest. 2.20. The stroller CANNOT be used for a purpose other than intended. 2.21. Never leave your child unattended in the stroller, especially on a hilly surface. 2.22.
  • Page 6 2.37. CAUTION! The Manufacturer is ONLY responsible for the defects and technical damage resulting from the use of the stroller that is in strict compliance with the instructions and safety rules specified in this manual. 2.38. CAUTION! When reclining the seat, you need to adjust the length of the 5-point belt each time.

  • Page 7: Intention Of The Manual

    Intention of the manual The manual contains basic information about the proper use of the Mouse stroller, its assembly, maintenance and cleaning and warranty conditions. Please keep the manual in an easily accessible place. The manual is intended for the caregivers of special needs children, as well as the doctors and physical therapists who will use the stroller.
  • Page 8 4.2. The steal frame (Fig.4.1. ) with aluminium elements includes: 4.2.1. Adjustable, ergonomic handlebar (Fig.4.1.-nr 2) 4.2.2. Front swivel wheels (Fig.4.1.-nr12) 4.2.3. Front wheel direction lock (Fig.4.1.-nr15) 4.2.4. Front wheel fork shock absorption system (Fig.4.1.-nr14) 4.2.5. Front wheel folding system (Fig.4.1.-nr13) 4.2.6.

  • Page 9: Accessories

    Accessories Mouse stroller offers a wide range of accessories. 5.1. The standard accessories on the stroller’s frame include: Figure 5.1.1. Figure 5.1.2 The central brake Shopping basket (Fastened under the seat) 5.2. The standard seat accessories include Figure 5.2.1. Figure 5.2.2...

  • Page 10: Anti-Corrosion Protection

    Figure 5.2.5. Figure 5.2.6. Adjustable canopy with window Adjustable and folding footrest Figure 5.2.7 Side pads- reducer Anti-corrosion Protection In order to avoid damage resulting from corrosion, the stroller shouldn’t be used or kept in wet or damp spaces. If the stroller has been soaked in water, it needs to be dried with a soft cloth and treated by a preservative that has light oil basis.

  • Page 11: Reuse Of The Stroller

    The Reuse of the stroller The product is suitable for reuse. All products that are reused may change their usability due to change in their specifications and performance characteristics and, therefore, need to be checked for efficacy. The safety of the persons using the stroller as well as the accompanying people may be endangered in such circumstances.
  • Page 12 8.1.3. Rear wheel assembly To attach the rear wheels, press the button in the middle of the wheels. Attach both wheels, by inserting the wheel axles into the folding system slot. You need to hear the ‘click’. Figure 8.1.2. Figure 8.1.3. 8.1.4.
  • Page 13 8.2. Dismantling the stroller 8.2.1. Dismantling the seat To dismantle the seat, press two colorful buttons situated on the lower part of the stroller’s frame hooks. Next, eject the seat from the all 4 frame hooks (Fig. 8.1.4 ). Figure 8.2.1. 8.2.2.
  • Page 14 8.2.4. jlk 8.2.4.1. Folding the bottom part of the frame To fold the stroller’s frame, pull up both handles of the bottom frame folding mechanism. Next, fold the stroller’s frame and lock the transport block Figure 8.2.4.1 8.2.4.2. The folding of the upper part of the frame To fold the stroller’s frame, press the red button on the frame folding mechanism and simultaneously pull up both handles situated on the upper part of the frame folding mechanism.
  • Page 15 8.3. Adjustable, ergonomic handlebar To change the handle bar’s angle, simultaneously press the two buttons situated on each side of the handle bar. After the angle has been adjusted, release the buttons, and the handle bar will stay in this position. Figure 8.3.
  • Page 16 8.5. Front wheel forks shock absorption system The stroller is equipped with the front wheel absorption system that works automatically. It should not be adjusted. Figure 8.5. 8.6. Two-step rear wheel shock absorption system The stroller is equipped with two types of shock absorption system: spring and strut.
  • Page 17 8.7. The central brake and optional inclination bar To switch the brake on, press the brake pedal down. To switch the brake off, pull the brake pedal up. Fig. 8.7.1. To lift the front wheels, simultaneously press the inclination bar and pull the handlebar towards you in the same time.
  • Page 18 The detailed description of the proper use of the hooks are found in point 8.1 and 8.2 Make sure there aren’t any cracks and damage in the stroller’s frame. Also, check if it works properly. Do not use the stroller in case of any suspicion as to the proper operation of the stroller.
  • Page 19 8.12. The frame folding mechanism The four frame folding mechanisms are very important elements of the stroller. They consist of two bottom mechanisms (big handles) and two top mechanisms (smaller handles and the red button). Points 8.1. and 8.2. contain the exact description. Make sure there aren’t any cracks and damage in the stroller’s frame.
  • Page 20 8.14. Adjustable backrest The stroller’s backrest can be adjusted to various positions varying from a seating position to a lying position. To change the position, move the backrest towards a seating position first. Then, pull the handle located at the back of the backrest and change the position slowly.
  • Page 21 8.16. Safety barrier Slide the safety barrier into the attachment tubes and listen for the ‘click’. The clearly audible ‘click’ is an indication that the safety barrier has been securely attached to the seat. To take the safety barrier out, press the two buttons on the attachment tube and slide the tray out.
  • Page 22 8.18. Wedge The wedge should be placed between the child’s legs. Figure 8.18. 8.19. Adjustable head pads - ↔ and ↕ To adjust the head pads, draw aside the seat upholstery on the front and back of the seat. Next, take off the head support knobs, which are situated on the back of the seat and adjust the head pads at the front of the seat.
  • Page 23 8.20. Adjustable canopy with a peek-a-boo window To fold and unfold the canopy, pull it in the appropriate direction and adjust its position. The window opens with a zipper. Figure 8.20. 8.21. Adjustable footrest In order to change the inclination of the footrest, press the buttons marked on the picture on both sides of the footrest, then set the appropriate position and release the buttons.

  • Page 24: The Usage Of The Stroller

    8.22. Side inserts - reducer The stroller is equipped with an upholstered insert for the smallest children, which reduces the dimensions of the seat (width and depth). The insert consists of one element that attaches itself to the sides of the seat and with the backrest with Velcro.

  • Page 25: Cleaning And Maintenance

    9.2.1.2. Place the stroller on a smooth and safe surface and assemble it properly. Use the instruction manual. 9.2.1.3. Adjust all parts of the stroller including the seat, the backrest, the head support, the pads, the footrest, the handlebar, the canopy and adjust the length of five-point belts and rear wheel shock absorption system.

  • Page 26: Periodical Maintenance Checks

    10.4.4. Finally, rinse the stain using a clean sponge or cloth soaked with lukewarm water. Do not use detergent at this point. Wipe from the outside of the stain to the center. 10.5. Disinfectants that do not contain organic solvents can be used in accordance with the specifications given by the product manufacturer.
  • Page 27 The periodical service: WHEN? WHAT? REMARK Before starting out Test brakes for faultless Activate brake pedal(-s) to the limit. operation The locked wheels can not be able to turn under operating conditions Check all construction’s Wheels, frame, seat, 5 point belts, elements footrest, safety barrier Check air pressure of the...

  • Page 28: The Stroller's Technical Data

    The Stroller’s Technical Data PARAMETER MOUSE Lengh 110 cm Width 59,5 cm Height 122 cm The seat’s width 24 (with reducer) cm & 30 The seat’s depth 22 (with reducer) cm & 25 The backrest’s height 52,5 cm The distance of the footrest from...

  • Page 29: Table Of Parameters

    13. Table of parameters 30 kg Child’s maximum weight 30 cm Child’s maximum chest width 14 & 32 cm Minimum and maximum lower leg lengh 22 cm Minimum thigh lengh 110 cm Child’s maximum height Table: Child’s parameters 14. Utilization and recycling The used stroller needs to be dropped off at a recycling centre following the rules that are in force in a given country.

  • Page 30: The Manufacturer

    The Mouse stroller is a Polish product! Polish quality, polish price! The authorized dealer: MyWam sp.j reserves the right to introduce technical and commercial changes to the content of the Operation and maintenance manual without prior notice. Any change shall be considered as the date of latest revision.

  • Page 31: Declaration Of Ce Manufacturer's Conformity

    17. Declaration of CE Manufacturer’s Conformity...

  • Page 32: Warranty Card

    18. Warranty card Series and number: AK date of purchase: stamp and signature of the Seller: Warranty terms and conditions The manufacturer grants the purchaser a guarantee for a period of 24 months from the date of purchase. Any repairs needed within the 24-month period will be performed free of charge. To make a complaint about the product, the purchaser should bring the stroller to the seller or manufacturer in its original packaging together with the properly protected parts.
