Summary of Contents for EIPL RM40
- Page 1 Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 RM40 RM40 DEHUMIDIFIER RM40 RM40 DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER OWNER’S MANUAL www.eipl.co.uk Page 1 of 13...
-
Page 2: Safety Information
Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 SAFETY INFORMATION Children shall not play with the appliance. This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved. - Page 3 Before disposing all refrigerant should be evacuated and disposed of as required by local environmental laws. • If there is any damage to the appliance, DO NOT USE and contact EIPL. • The appliance must not be used in a potentially explosive atmosphere.
- Page 4 Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 DEHUMIDIFIER PRINCIPLE Dehumidifiers remove moisture from the air that is circulating through the appliance. The resulting reduction of relative humidity helps prevent rust, rot, mould, mildew and condensation within the room, or other enclosed spaces where the dehumidifier is used.
-
Page 5: Installation
Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 INSTALLATION POSITIONING: Position the appliance in the center of the room to be conditioned if at all possible. However, if a damp patch is particularly apparent the outlet grille should be pointed towards it. - Page 6 Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 RM40 CONTROL PANEL Button / Ledgend Function Description ON / OFF Switch the dehumidifier ON/OFF Cycle through menu options and adjust the Menu desired set point. See below for list of menu...
-
Page 7: Menu Options
Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 MENU OPTIONS Pressing the Menu button cycles through the following pages of information. Menu Display Information Using the Up / Down Keys adjust the humidity to the desired Set RH set-point, pressing the Enter key to accept and save. -
Page 8: Operation
The unit will automatically defrost as needed. In warmer climates defrost is not required, allowing the dehumidifier to continually dry. Moving / Transporting the unit The RM40 has a removable water container, therefore its’ advisable to allow any frost to melt, and empty this container prior to moving. Instructions / sequence Switch the unit off by the control panel ON/OFF switch Allow approximately 30mins for any frost / ice to melt. -
Page 9: Routine Service
1. Insufficient air flow 1. Check all of the above Little or no water 2. Compressor fault 2. Contact EIPL extraction 3. Loss of refrigerant gas 3. Contact EIPL Little or no defrost 1. Faulty Timer 1. -
Page 10: Specifications
Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 SPECIFICATIONS : RM40 ODEL : 615 mm EIGHT : 382 mm IDTH : 365 mm EPTH : 26 Kg EIGHT : 185 M IRFLOW : 230 V, 1 ph, 50 Hz... - Page 11 Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 APPLIANCE SPARE PARTS LIST Description Part Number Appliance Number 11187MB-GB Filter 1019712 Water Container with float assembly 1137907 PCB - Control Board 1619522 PCB - Humidity Sensor 1619526 PCB - Display 1619528 Outlet Grille 2018704 Plastic Drain Tray 2018705...
- Page 12 Drawing : - TPC587 Issue : - 1 Date : - 28/10/22 Page 12 of 13...
- Page 13 Bishop Auckland Suite 109, Newport News County Durham Virginia, 23606-2575 DL14 9AD Tel: +44 (0) 1388 664400 Tel: +01 757 873 6800 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 www.eipl.co.uk www.ebacusa.com sales@eipl.co.uk sales@ebacusa.com Page 13 of 13...
