TRASSIR TR-D7121IR1v7 Manual

Specification
Model TR-D7121IR1v7
Image sensor 1/2.8" CMOS 2MP
Max resolution 2MP(1920x1080)
Main stream 50Hz: 2MP/960P/720P@25fps
60Hz: 2MP/960P/720P@30fps
Substream 50Hz: D1/VGA/HVGA@25fps
60Hz: D1/VGA/HVGA@30fps
Electronic shutter speed 1/2 ~ 1/50,000 s
Day/Night mode Mechanical ICR
Sensitivity
0.005Lux (F1.6)
IR range up to 10 m
Lens (mm) 1.9 / 2.8 / 3.6
Field of view (horiz./vert.) 1.9mm: 139˚±5˚ / 74˚±5˚
2.8mm: 110˚±5˚ / 60˚±5˚
3.6mm: 88˚±5˚ / 48˚±5˚
Axes setting Pan: 0˚-30˚
Tilt: 0˚-90˚
Rotation: 0˚-360˚
WDR Real WDR (120dB)
Digital noise reduction
Video compression Н.265+ / Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 256GB
Audio Built-in microphone
Built-in speaker
Motion detector PIR sensor
Corridor mode
IVS
General
Power supply
PoE Class
Power consumption
Case material
Dimensions (mm)
Weight Net/Gross (g)
Working temperature
3D DNR
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
Yes
Yes
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D7121IR1v7
Indoor IR Network Camera
PoE (802.3af) / 12V DC
3
DC: 2.0W
PoE: 2.9W
Plastic
129 x 99 x 60
95 / 220
-10°C ... +50°C
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
