TR40S SIMULATOR
Assembly Guide
IMPORTANT: Different regions may have different models. Please ensure the part number
below matches that on your product's box.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TRAK RACER TR40S
Summary of Contents for TRAK RACER TR40S
- Page 1 Share your build online and tag us to be featured! TR40S SIMULATOR Assembly Guide www.trakracer.com IMPORTANT: Different regions may have different models. Please ensure the part number @trakracer @trakracer @trak_racer below matches that on your product's box.
- Page 2 PART LIST Recommended: Two people for Safety glasses required the task Tighten the hardware Attention/Priority needed ASSEMBLY NOTES TR40S Keep the hardware loose BC-40 & CB-40 Reserve for the next step for adjustments NS-M8 & NS-M6 Mirrored components Make the necessary adjustments...
- Page 3 PART LIST PART LIST COMPONENTS ACCESSORIES 460mm (18.11”) 550mm (21.65”) 580mm (22.84”) 695mm (27.36”) M8x16mm M8x20mm M8x30mm M8x16mm Aluminum Profile Aluminum Profile Aluminum Profile Aluminum Profile M8x16 Flat Hex Screw M8x20 Flat Hex Screw M8x30 Flat Hex Screw M8x16 Cap Hex Screw TR-4040-460 TR-4040-550 TR-4040-580...
- Page 4 ASSEMBLY NOTES ASSEMBLY NOTES TR40S BC-40 & CB-40 TOP SIDE These brackets come with guide tabs on the rear. These tabs help align the brackets to the profile when fitted in the same orientation as the profile. When used in the alternate orientation, these tabs are designed BACK SIDE to snap off for a flush mount against the profile.
- Page 5 ASSEMBLY NOTES ASSEMBLY INSTRUCTIONS NS-M8 & NS-M6 TR40S B X2 H X4 AE X4 AH X4 AI X2 TR-4040-550 FR-1 SH-M8-20 NS-M8 WF-M8-16 Slide T-Nuts into the ends of the profiles. Some must be added early, so follow the steps in this manual carefully.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR40S TR40S C X2 AA X4 AH X4 D X2 H X2 AE X2 AH X2 AI X2 TR-4040-580 SH-M8-16 NS-M8 TR-4040-695 FR-01 SH-M8-20 NS-M8 WF-M8-16 I X4 AD X4 AE X4 AH X2 I X2...
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR40S TR40S AA X2 AH X2 E X2 AA X4 AH X4 I X4 SH-M8-16 NS-M8 TR-8040-700 SF-M8-16 NS-M8 CB-40 AA X2 AC X2 AH X2 I X2 AA X4 AH X4 J X2 SF-M8-16 SF-M8-30...
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR40S TR40S AA X8 AH X8 S X1 AE X4 AJ X4 AK X4 AH X4 SH-M8-16 NS-M8 SFTSUP SH-M8-20 WF-M8-20 WL-M8 NS-M8 F X1 M X2 AE X4 AJ X4 AK X4 AH X4 Q X2...
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR40S TR40S E X1 AA X8 AH X8 I X4 U X1 V X1 AD X8 TR-8040-100 SH-M8-16 NS-M8 CB-40 GRP1 GRP2 SH-M8-16 AD X4 AJ X4 AH X4 O X1 AE X4 AJ X4 AK X4...
- Page 10 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR40S TR40S R X1 AB X2 K X4 L X5 N X2 SH-M8-20 EC-40 EC-80 BC-40-CAP...
- Page 11 TR80-SHORTSHIFT PART LIST COMPONENTS 240mm (9.45”) Aluminum Profile Shifter Plate Shifter Support Plate Shifter Side Plate TR-8040-240 SM-01 SM-02 BP-80-H Corner Bracket Corner Bracket Cup 40x80 End Cap BC-40 BC-40-CUP EC-80 ACCESSORIES (NOTE: Extra hardware may be included as spare parts) M8x20mm M8x20mm M8x20 Cap Hex Screw...
- Page 12 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR80-SHORTSHIFT TR80-SHORTSHIFT A X1 E X2 AA X2 AC X2 C X2 AD X2 D X2 AE X2 AA X6 AC X6 C X2 AD X6 D X2 AE X6 TR-8040-240 BC-40 SH-M8-20 NS-M8 WF-M8-20 WL-M8 SH-M8-20 NS-M8 WF-M8-20...
- Page 13 ASSEMBLY INSTRUCTIONS TR80-SHORTSHIFT D X1 AA X2 AC X2 C X2 AD X2 D X2 AE X2 BP-80-H SH-M8-20 NS-M8 WF-M8-20 WL-M8 F X2 G X1 BC-40-CAP EC-80 SHIFTER OPTION 2 TR120-SMEX...
- Page 14 TR120-SMEX PART LIST ASSEMBLY INSTRUCTIONS TR120-SMEX COMPONENTS A X1 F X3 AA X3 AC X3 C X2 AD X3 D X2 AE X3 TR-8040-200 BC-40 SH-M8-20 NS-M8 WF-M8-20 WL-M8 200mm (7.87”) 580mm (22.84”) Aluminum Profile Aluminum Profile Shifter Plate Shifter Support Plate TR-8040-200 TR-4040-580 SM-01...
- Page 15 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR120-SMEX TR120-SMEX C X1 D X1 AA X2 D X2 AB X2 AD X2 C X2 AE X2 AA X1 AC X1 C X2 AD X1 D X2 AE X1 SM-01 SM-02 SH-M8-20 NF-M8 WF-M8-20 WL-M8 SH-M8-20 NS-M8 WF-M8-20...
- Page 16 ASSEMBLY INSTRUCTIONS TR120-SMEX E X1 AA X4 AC X4 C X2 AD X4 D X2 AE X4 BP-120-H SH-M8-20 NS-M8 WF-M8-20 WL-M8 G X5 H X1 BC-40-CAP EC-80 DIRECT MOUNT TR-DDBR2 Slide the Slider all the way back to install screws and nuts. Then slide all the way forward and repeat for front screws and nuts.
- Page 17 TR-DDBR2 PART LIST ASSEMBLY INSTRUCTIONS TR-DDBR2 ACCESSORIES (NOTE: Extra hardware may be included as spare parts) AA X1 AD X4 AE X4 AF X4 OPTION 2 TR-DDBR2 SF-M8-16 WL-M8 WF-M8-20 M8x25mm M8x16mm Direct Motor Mount Mounting Plate M8x25 Cap Hex Screw M8x16 Cap Hex Screw TR-DDBR2 TR-DDBR2...
- Page 18 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TR-DDBR2 TR-DDBR2 AA X1 AD X4 AG X4 AA X1 AD X4 AG X4 OPTION 3 OPTION 4 TR-DDBR2 SF-M8-16 NF-M8 TR-DDBR2 SF-M8-16 NF-M8 GRP1 AB X1 AC X4 GRP1 TR-DDBR2 SF-M8-25...
- Page 19 TR80-NWMDD2 PART LIST ACCESSORIES (NOTE: Extra hardware may be included as spare parts) M8x20mm M8x25mm M8x20 Cap Hex Screw M8x25 Cap Hex Screw TR80-NWMDD2 SH-M8-20 SH-M8-25 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Two installation options for different needs. AA X1 AB X4 OPTION 1 TR80-NWMDD2 SF-M8-20...
- Page 20 TR-RSB-CH PART LIST ACCESSORIES (NOTE:SCREWS SUPPLIED WITH SEAT SB-03) M8x16mm M8x20mm M8x16 Cap Hex Screw M8x20 Washer(Flat) SB-03 SH-M8-16 WF-M8-20 ASSEMBLY INSTRUCTIONS AA X1 AB X4 AC X4 SB-03 SF-M8-20 WF-M8-20 NON-ADJUSTABLE RECLINE SEAT BRACKETS Assembly Guide TR-RSB-CH...
- Page 21 ASSEMBLY INSTRUCTIONS TR-RSB-CH AB X4 BC X4 AD X4 SH-M8-16 WF-M8-20 NL-M8 GT/RALLY SEAT ASSEMBLY SA-09 and SA-10...
- Page 22 TR-RSB-CH PART LIST ASSEMBLY INSTRUCTIONS TR-RSB-CH ACCESSORIES (NOTE:SCREWS SUPPLIED WITH SEAT SB-03) AA X4 AB X4 SH-M8-16 WF-M8-20 Slide the slider all the way back to install screws and nuts. Then slide all M8x16mm M8x20mm the way forward and repeat for front screws and nuts. M8x16 Cap Hex Screw M8x20 Washer(Flat) M8 Lock Washer...
