TRAK RACER TR-One TR80-HYPL Quick Start Manual

TR-One
Hybrid Pedal System
TR80-HYPL
NOTE: Hardware to attach pedals to plate not included.
Please use hardware included with your pedal set.
Part #
BOX #: TR80-INVPED3
SH-M8-20
SL-M8-25
WF-M8
WL-M8
NF-M8
NS-M8
PP-IN-BR
PP-IN-FR
PP-IN-SM
BOX #: TR80-NEWPLATE
PP-80-TP
PP-NP-LB
SH-M8-25
SF-M8-20
SH-M6-15
NF-M8
WF-M8
WL-M8
* NOTE: Extra hardware may be included as spare parts
TR80-INVPED3 + TR80-NEWPLATE
Description
Screw (Hex), M8x20
Screw (Handle) M8x25
Washer (Flat), M8
Washer (Lock), M8
Nut (Flange), M8
T-Nut (Spring), M8
Pedal Plate, Inverted, Brackets
Pedal Plate, Inverted, Footrest
Pedal Plate, Inverted, Side Mounts
Pedal Plate, TR80 Top Plate
Pedal Plate, L Bracket
Screw (Hex), M8x25
Screw (Flat), M8x20
Screw (Hex), M6x15
Nut (Flange), M8
Washer (Flat), M8
Washer (Lock), M8
QTY Check
16
4
16
16
8
12
2
1
2
1
2
4
10
4
14
4
4
