- Page 2 Domi outdoot living o u t d o o r l i v i n g 8'x12' SKU：LGMF1679 Wall-Mounted Gazebo Assembly Manual © Copyright 2023-2025 Domi Outdoor Living LLC.All Rights Reserved...
- Page 3 d mi o u t d o o r l i v i n g...
- Page 8 143.3”（3640mm） 5.04”（128mm） 5.04”（128mm） 3.46”（88mm） 144.8”（3677mm）...
- Page 14 Black Rubber...
- Page 16 silicone sealant...
- Page 17 Rubber Gaskets...
- Page 20 Make sure the correct connection: A3 and A6 connected ,A4 and A5 connected...
- Page 21 The bracket #A10 is used to fix the post against the wall. If you don't need it fixed, please retain for future use and skip this step.
- Page 22 Front Beam Assembly...
- Page 28 Use silicone sealant (part # 15) to affix the gap between the two beams.
- Page 31 Side Beam Assembly...
- Page 37 Side Beam Assembly...
- Page 43 Rear Beam Assembly...
-
Page 48: Frame Assembly
Frame Assembly... - Page 53 Inside View Outside View...
- Page 54 Middle Beam Assembly...
- Page 61 The notches of #J1 are facing inward.
- Page 63 The notches of #J2 are facing inward.
- Page 65 Black Rubber Rubber Gaskets...
- Page 68 silicone sealant application: (1)Apply 3 mm wide silicone sealant to the first row of roof panels as shown. Install the second row of roof panels and fix the screws.
- Page 70 Install this step if you need fix the canopy to the wall (you need to drill holes into the wall). Otherwise please skip this step.
- Page 71 Install this step if you need fix the canopy to the wall (you need to drill holes into the wall). Otherwise please skip this step.
- Page 72 Support Tube Assembly Adjust the length of the support tubes according to the slope.
- Page 73 The support tube can strengthen the weight capacity of the metal roof. In bad weather, especially snowstorm,it is essentially needed to prevent the roof from collapsing under heavy snow;In daily life, you can put it away.
- Page 74 Nettings and Curtains Assembly...
- Page 75 Outside Track...
- Page 76 Inside Track...
- Page 77 Velcro...
- Page 78 Please close your gazebo curtain when it is incoming over 30 mph wind. Use strap to tie the curtain to the poles.
