- Page 1 PYTES V10 LFP Battery User Manual Version 1.0 Date: 2024-9-20 Information Subject to Change without Notice...
- Page 2 Please keep this manual in a safe location, as it is the original manual. For the latest version of all manuals, please visit our website at http://www.pytesgroup.com. Thank you again for choosing Pytes, and please do not hesitate to contact us if you have any questions or concerns about your Product.
-
Page 3: Before Using
Pytes V10 LFP Battery User Manual Before Using Read and understand the following instructions: Warning 1. This equipment must be installed, operated and maintained by qualified personnel (electrician). 2. The local safety regulations and relevant operating procedures must be observed during the installation, operation and maintenance of the Product, otherwise the Product may get damaged. - Page 4 6. Do not expose Li-ion battery to heat or fire. In case of fire, please use fire extinguisher. 7. Do not dismantle any part of the system without contacting PYTES or PYTES authorized technical engineers. System failure caused by such action will not be...
- Page 5 Pytes V10 LFP Battery User Manual Symbols Read the instruction manual before starting installation and operation. Caution, do not dispose of batteries in a fire, the battery may explode. Caution, a battery can present a risk of electric shock and burns by high short-circuit current.
-
Page 6: Table Of Contents
Pytes V10 LFP Battery User Manual Contents 1. Safety Precautions ..................7 1.1 Transportation .................. 7 1.2 Storage ....................7 1.3 Emergency Situations ..............8 1.4 Disposal ....................8 2. Specifications ..................... 9 2.1 Parameters ..................9 2.2 Packing List ..................10 2.3 BMS Functions .................11... - Page 7 Pytes V10 LFP Battery User Manual 7.3 Unable to Discharge ..............25 7.4 Alarm Indicator Constantly on ..........26...
-
Page 8: Safety Precautions
Pytes V10 LFP Battery User Manual 1. Safety Precautions 1.1 Transportation Pytes V10 original packaging complies with regulation of UN3480, Class 9, Packaging Group II. Always check all applicable local, national, and international regulations before transporting a LFP battery. The battery must be transported in its original or equivalent package and in an upright position. -
Page 9: Emergency Situations
3) Wet Batteries If the battery pack is wet or submerged in water, do not allow any person access, and then contact PYTES or an authorized dealer for technical support. 4) Damaged Batteries Damaged batteries are dangerous and must be handled with extreme care. -
Page 10: Specifications
Pytes V10 LFP Battery User Manual facilities using safe and appropriate method. 2. Specifications 2.1Parameters Battery Model V10/V10α Chemistry Nominal Voltage 51.2V Voltage Range 47.5V-56.8V Nominal Capacity 230Ah Usable Capacity 200Ah Nominal Energy 11.776kWh Usable Energy 10.24kWh L671.2±2.0 x W260±2.0 x H520.0±2.0mm Unit Dimension L26.43±0.08 x W10.24±0.08 x H20.47±0.08 inch... -
Page 11: Packing List
Rated voltage: 500VDC *Fuse Parameters Rated current: 450A Rated voltage: 250VDC Circuit breaker Parameters Rated current: 125A (1P) *If there is a problem with FUSE, please contact Pytes directly to replace it, do not replace it yourself. 2.2Packing List Item Specifications Picture LFP Battery Pack Voltage: 51.2V... -
Page 12: Bms Functions
Spray-Silver 1408-Screw-GB-T22795(TGQ)-2008-M8--M Expansion 8×50-Carbon Steel-Blue and White Zinc 8pcs screws Plated-Silver-72H Lifting handle 2pcs Used to install in the slot, lift v10 Spare RJ45 2pcs Backup Connector 2.3BMS Functions Protection and Alarm Management and Monitor Charge/Discharge End Cut-off Cells Balance... -
Page 13: Interface And Components
Pytes V10 LFP Battery User Manual 3. Interface and Components 3.1 Interface 3.2 Components Name Label Function description When switched to "ON", the system can be Power Switch POWER activated by "SW" or external power supply; when switched to "OFF", the system is off. - Page 14 Pytes V10 LFP Battery User Manual Red light. The light flashes when Alarm. The light is Alarm indicator continuously on when under protection. Green light. The light flashes when Standby. The Running light light is constantly on when charging. The light...
-
Page 15: Operating Environment
Pytes V10 LFP Battery User Manual Ground Point Connection for ground cable 4. Operating Environment Battery Installation, operating, maintenance environment requirements: Operating Temperature: -20°C~55°C Relative Humidity: 20%-80%, no condensation Altitude: ＜4000m Installation Location Conditions: 1) no heat source, flammable or explosive materials. - Page 16 Pytes V10 LFP Battery User Manual observe local safety regulations and the safety requirements listed below during the installation process. Before installing or removing the battery, make sure that the system is disconnected from any power source and that the battery is off state. Distribution cabling needs to be handled carefully with protective measures.
-
Page 17: Unpacking
The V10 should be installed upright on a vertical, solid surface, such as a brick or concrete wall, and the wall must be made of non-combustible materials. Since the V10 is heavy, it is recommended that two or more people install it. - Page 18 (Figure2) to the wall using the corresponding nut. Step 3. After ensuring stability, install the left and right handles on the V10 battery. Tilt the handle 45 degrees to lock it. Lift the battery and align the rear track with...
- Page 19 Pytes V10 LFP Battery User Manual 5.3.2 Connect Ground Cable Connect one end of ground cable to ground point on V10 and tighten the screw with screw driver. Connect the other end of the earthing cable to a reliable ground point.
- Page 20 21.15 83.5 95.2 5.3.3.1 Single Battery Connect the positive and negative terminals of V10 to energy storage inverter with power cables. 5.3.3.2 Multiple Batteries Connect the positive and negative terminals from V10 separately to positive and negative busbars. Then connect the positive and negative busbars to inverter.
- Page 21 Note: Before starting the system, strictly check the connection terminals to ensure that the terminals are firmly connected. Make sure V10 is powered on prior to turn on the inverter. This is to avoid battery shock by the in-rush current of the large capacitors of the inverter.
- Page 22 Step 2. Turn on the power switch. Step 3. Press SW button for 1 second to turn on V10. If V10 is parallel connected, only press SW of master battery to power on the system. Step 4. Battery indicator lights will go on indicating batteries are running.
-
Page 23: Communication
Pytes V10 LFP Battery User Manual 6. Communication There are RS-232, RS485 and CAN communication ports on the Product. The battery status can be obtained and the battery internal parameters can be modified via Pytes monitoring software. CAN communication Terminal, RJ45 port, follow CAN protocol, to output batteries information. -
Page 24: Troubleshooting
Pytes V10 LFP Battery User Manual CANH CANL RS485A RS485B Table 6-2 RS485 and CAN Connector Pin Assignments 7. Troubleshooting Normal/ Capacity Alarm/ Description ● ● Protection Shutdown All off All lights will be on for 1 second at the... -
Page 25: Unable To Start
Pytes V10 LFP Battery User Manual doesn’t indicate the battery is faulty if the ALM alarm red light is blinking or constantly on. When there is an "alarm" indication, it usually works well and needs no troubleshooting. When there is "protection" indication, the battery will work normally automatically after “protection”... - Page 26 Pytes V10 LFP Battery User Manual 1. Confirm the battery is turned on; 2. Check the power cable. Confirm the power cables are correctly connected and the charging circuit is correct; 3. Check the battery indicator LED to see if the battery is under “Protection”...
- Page 27 Pytes V10 LFP Battery User Manual Warning: Do NOT repair the battery without authorization from PYTES. 7.4 Alarm Indicator Constantly on When the ALM indicator is constantly on and the other indicators are off, the battery is in the “Protection” state. When protection condition is released, the battery will automatically return to normal operation.
-
Page 28: Warranty Card
Pytes V10 LFP Battery User Manual Warranty Card Customer Information Contact Name Phone Number Email Address Product Information Battery Model Inverter Brand/Model Battery Quantity Inverter Quantity Purchase Date Inverter Using Time Serial Number on/off Grid Installer Information Installer Name Installation Date... - Page 29 Pytes V10 LFP Battery User Manual Shanghai PYTES Energy Co., LTD No.3492 Jinqian Road, Fengxian District, Shanghai, China +86 21 57474761 ess_support@pytesgroup.com The right of interpretation belongs to Pytes Energy...
