Tronair 03A5800C0010 Operation & Service Manual

Tailstand with alarm
Hide thumbs

Advertisement

Quick Links

Download this manual
For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com
OPERATION & SERVICE MANUAL
Model: 03A5800C0010
Tailstand with Alarm
07/2023 − Rev. 03
Tronair, Inc.
Phone: (419) 866-6301 | 800-426-6301
1 Air Cargo Pkwy East
Web: www.tronair.com
Swanton, OH 43558
Email: sales@tronair.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 03A5800C0010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tronair 03A5800C0010

Summary of Contents for Tronair 03A5800C0010

  • Page 1 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com OPERATION & SERVICE MANUAL Model: 03A5800C0010 Tailstand with Alarm 07/2023 − Rev. 03 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
  • Page 2 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com REVISION DATE TEXT AFFECTED 09/2014 Original Release 11/2016 Modified Parts List 07/2023 Major revision...
  • Page 3 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 DESCRIPTION..............................1 MODEL & SERIAL NUMBER ..........................1 MANUFACTURER .............................. 1 SAFETY INFORMATION ..............................1 USAGE AND SAFETY INFORMATION ......................
  • Page 4 Model: 03A5800C0010 Tailstand This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur. Only Tronair OEM replacement parts shall be used.
  • Page 5 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand SAFETY GUIDELINES CAUTION! DO NOT place hands on top of tailstand near base tube receiver while lowering tailstand extension. Pinch point exists between top of tube and bracket on extension.
  • Page 6 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand ASSEMBLY GENERAL INSTRUCTIONS This product should be assembled and/or repaired using good workmanship practices and proper tools. Bolts and elastic stopnuts should be tightened to a torque not to exceed industry standards for Grade '5' bolts.
  • Page 7 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand OPERATION OPERATING PARAMETERS The user shall work in accordance with this Operator and Service The employer of the operator shall provide all necessary training Operate between -20...
  • Page 8 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand 5.3.6 Alarm Load Test Place a force between 100 to 150 lbs (45.36 to 68.04 kg) to the top of the cradle. This will activate the alarm. Refer to Trouble Shooting section of this manual if test fails.

  • Page 9: Troubleshooting

    For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand PACKAGING AND STORAGE PACKAGING REQUIREMENTS Tailstand is to be packaged as required to prevent damage to legs or cradle equipment during shipment. HANDLING Tailstand can be rolled by hand on its casters.
  • Page 10 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand MAINTENANCE GENERAL • All maintenance and/or repair work should be done using good workmanship practices and proper tools • Tailstand shall be maintained and repaired in accordance with the manufacturer’s instructions. Such maintenance and repair shall be carried out by qualified persons •...
  • Page 11 If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes on any shipping documents.
  • Page 12 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Z-1581 ASSEMBLY, CRADLE...
  • Page 13 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com Model: 03A5800C0010 Tailstand Parts List Item Part Number Description G-1155-105210 SCREW, 5/16 X 1 SOC HEAD SHOULDER H-2762 SPRING, LIGHT DUTY TIE EC-1796 SWITCH, LIMIT S-1923-01...
  • Page 14 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com...
  • Page 15 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com APPENDIX I Declaration of Conformity...
  • Page 16 For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com...

  • Page 17: Declaration Of Conformity

    For 03A5800C0010 sales, parts and service, click here to view this item on PilotJohn.com DECLARATION of CONFORMITY The design, development and manufacture is in accordance with European Community guidelines TELESCOPING TAILSTAND (TRIPOD) 03A5800C0010 Relevant provisions complied with by the machinery:...
