Installation & Operating Instructions
10Kg Freestanding Washing Machine
MDAWM1014W/K/S White/Black/Silver
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Advertisement
Table of Contents
Related Manuals for montpellier MDAWM1014W
Summary of Contents for montpellier MDAWM1014W
- Page 1 C O O L I N G Installation & Operating Instructions 10Kg Freestanding Washing Machine MDAWM1014W/K/S White/Black/Silver Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Your appliance is covered by a comprehensive two year Thank you for choosing this Montpellier appliance. Parts & Labour Guarantee. In the unlikely event that you Your appliance has been designed to provide you with experience a problem with your appliance, you can rest...
-
Page 3: Table Of Contents
Contents 5 Maintenance And Cleaning 1 Safety Instructions 5.1 Cleaning The Detergent Drawer 1.1 General Safety 5.2 Cleaning The Door And Drum 1.2 Intended Use 5.3 Cleaning The Body And Controls 1.3 Children's Safety 5.4 Cleaning The Water Intake Filters 1.4 Package Information 5.5 Draining The Remaining Water And Cleaning 1.5 Disposing Of The Waste Product... -
Page 4: Important Instructions For Safety And Environment
1 Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack expe- rience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 5: Intended Use
ted by the importer in order to avoid possible risks. • Place the product on a rigid, flat and level surface. • Do not place it on a long-pile rug or similar surfaces. • Do not place the product on a high platform or near the edge on a cascaded surface. •... -
Page 6: Package Information
1.4 Package information • Packaging materials of the product are manufactured from recyclable materials in ac- cordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities. 1.5 Disposing of the waste product •... -
Page 7: Installation
2 Installation 2.3 Removing the transportation locks Refer to the nearest Authorised Service Agent for installation Do not remove the transportation locks before WARNİNG: of the product. To make the product ready for use, review taking out the packaging reinforcement. the information in the user manual and make sure that the electricity, tap water supply and water drainage systems are Remove the transportation safety bolts before... -
Page 8: Adjusting The Feet
For metal feet: Your house will be flooded if the hose comes warning out of its housing during water discharge. Moreover, there is risk of scalding due to high washing temperatures! 1.Loosen the lock nuts on the feet by spanner. To prevent such situations and to ensure smooth water 2.Adjust the feet until the product stands in a stable intake and discharge of the machine, fix the end of the... -
Page 9: Preparation
3 Preparation 3.4 Initial use Before starting to use the product, make sure that all 3.1 Sorting the laundry preparations are made in accordance with the instructions in • Sort laundry according to type of fabric, colour, and sections “Important safety instructions” and “Installation”. degree of soiling and allowable water temperature. To prepare the product for washing laundry, perform first • Always obey the instructions given on the garment tags. - Page 10 Detergent Drawer • Do not exceed the (>max<) level marking in the softener The detergent drawer is composed of three compartments: compartment. – (1) for prewash • If the softener has lost its fluidity, dilute it with water – (2) for main wash before putting it in the detergent drawer.
-
Page 11: Tips For Efficient Washing
Clothes Using starch Colours • Add liquid starch, powder starch or the fabric dye into the (Recommended temperature range based softener compartment. on soiling level: cold -40 °C) • Do not use softener and starch together in a washing Powder and liquid detergents recommended cycle. - Page 12 Detergent Recommendation Following symptoms are a sign of detergent Recommended Type of laundry overdosing: Washing Wash cycles washing and textile temp. • heavy foam formation detergent • poor washing and rinsing result Heavy-duty Cotton、 detergent with Mix、 Following symptoms are a sign of detergent bleaching Bedding、...
-
Page 13: Operating The Product
4 Operating the product 4.1 Control panel 5 - Start / Pause button 1 - Programme Selection knob (Uppermost position On / Off) 6 - Auxiliary Function buttons 2 - Display 3 - Smart button 7 - Spin Speed Adjustment button 4 - Programme Follow-up indicator 8 - Temperature Adjustment button 4.2 Preparing the machine... -
Page 14: Special Programmes
• Bedding 4.5 Special programmes The main washing objects of the program are bed sheets, quilt For specific applications, select any of the following covers, curtains, overcoats and tablecloths and so on. In the programmes. washing process, the soaking time and washing time of the •... -
Page 15: Programme And Consumption Table
4.8 Programme and consumption table Auxiliaryfunctions Programme • • • Cold-60 Quick 15′ • • • Cold-30 Silk • • • Cold-40 Bedding • • • Cold-60 Under ear • • • Cold-90 Max. Rinse Spin • • Max. Spin •... -
Page 16: Auxiliary Function Selection
4. Auxiliary function selection Additional laundry may be loaded during the delayed Select the desired auxiliary functions before starting the start period. programme. Furthermore, you may also select or cancel At the end of the countdown, duration of the selected auxiliary functions that are suitable to the running programme will be displayed. -
Page 17: Progress Of Programme
4.12 Progress of programme 4.15 Canceling the programme Progress of a running programme can be followed from the To cancel the programme, turn the Programme Selection Programme Follow-up indicator. At the beginning of every knob to select another programme. Previous programme programme step, the relevant indicator light will turn on and will be canceled. -
Page 18: Maintenance And Cleaning
5 Maintenance and cleaning Use an anti-limescale suitable for the washing machines. Service life of the product extends and frequently faced problems decrease if cleaned at regular intervals. After every washing make sure that no foreign substance is 5.1 Cleaning the detergent drawer left in the drum. Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 19: Draining Remaining Water And Cleaning The Pump Filter
3. Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean thoroughly under running water. 4. Replace the gaskets and filters carefully in their places and tighten the hose nuts by hand. 5.5 Draining remaining water and cleaning the pump filter a. -
Page 20: Technical Specifications
6 Technical specifications MDAWM1014W Model name MDAWM1014S MDAWM1014K Capacity (kg) 1400 Maximum spin speed (rpm) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) • input (V/Hz) Total 220-240V~/50Hz... -
Page 21: Troubleshooting
7 Troubleshooting Program does not start after closing the door. • Start / Pause / Cancel button was not pressed. >>> *Press the Start / Pause / Cancel button. Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. -
Page 22: Here For You
Should your appliance develop a fault, please THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. call the Montpellier customer service helpline on: Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during 03333 234473 opt 3... - Page 24 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances .com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
