mTS1000 Series Tripod Turnstile
User Manual
P a g e
| 1
Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mars Pro-S1000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZKTeco Mars Pro-S1000 Series

Summary of Contents for ZKTeco Mars Pro-S1000 Series

  • Page 1 Series Tripod Turnstile User Manual P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 2 Copyright © 2025 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
  • Page 3 Mars Pro-S1000 Series User Manual relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors.
  • Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
  • Page 5 3. Make sure the switch's wiring sequence is correct after maintenance. Please make sure that the power has been disconnected before you wire, install or dismantle the  device. P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 6 Please keep all wrappers after unpack them for future use. In case of any failure occurred, you need to  return the device to the factory with the original wrapper. Transportation without the original wrapper may result in damage on the device and lead to additional costs. P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 7 SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.  The instructions shall require connection of the equipment protective earthing conductor to the  installation protective earthing conductor. P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 8: Table Of Contents

    ..............................35 OARD 4.2 PGIC C ) ....................36 ONTROLLER DDITIONAL ACCESSORY 4.3 IR B ................................37 OARD 4.4 M ....................37 ASTER LAVE OTOR RIVING ONTROLLER 5 WIRING INSTRUCTIONS ........................... 39 P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 9 8 MAINTENANCE ............................56 8.1 C ............................56 HASSIS AINTENANCE 8.2 M ..........................56 OVEMENT AINTENANCE 8.3 P ........................... 56 OWER UPPLY AINTENANCE 9 TROUBLESHOOTING ..........................57 10 PACKING LIST ............................58 P a g e Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 10: Overview

    The Mars Pro-S1000 Series swing barrier turnstile is an elegant high performance entrance control system designed for high-traffic volume. The Mars Pro-S1000 Series barriers are normally held in a locked position, thus denying access to the secured side. When the Mars Pro-S1000 Series correctly identifies the user's Card (RFID)/Fingerprint/QR code, etc.

  • Page 11: Features

    Installation Place for Facial Recognition A&C Terminals  Diameter: 34mm  Integration with Facial Recognition, Temperature and Mask Detection Terminals Infrared Sensors   16 pairs of infrared sensors for stronger tailgating detection P a g e | 11 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 12: Specification

    Mars Pro-S1000: Front View Side View 120mm 1355mm 50mm 245mm 650mm Top View Bottom View Bottom Mounting Hole 1355mm 60mm 1282mm Mounting Holes Wire Holes 28x18mm 40mm 50mm P a g e | 12 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 13 User Manual  Mars Pro-S1200: Front View Side View 120mm 1355mm 245mm Top View Bottom View Bottom Mounting Hole 1355mm 1282mm 60mm Wire Holes Mounting Holes 50x40mm 28x18mm P a g e | 13 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 14 Single-lane Dimensions of the door leaf (available): (630*295mm)(H*W)(Standard) (630*425mm)(H*W)(Optional) (1047*295mm)(H*W)(Optional) 1800mm 650mm 920mm 650mm Standard Lane Wide Lane / ADA Lane High-barrier Lane Dual-lane Multi-lane P a g e | 14 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 15: System Components

    Mars Pro-S1000 Series User Manual 1.2.2 System Components  Mars Pro-S1000: Master Slave Master Slave  Mars Pro-S1200: P a g e | 15 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 16 The system’s control center It detects the position of the pedestrian and plays a role in ensuring Infrared Sensor safety and protection Core Component Operating components of the turnstile P a g e | 16 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 17: Technical Specifications

    Gross Weight (160kg) Gross Weight (90kg) Weight Net Weight (110kg) Net Weight (65kg) 650mm (optional- 920mm) Lane width(mm) high:1200mm(Max high 1800mm) Footprint(mm*mm) 1355*120*1022(mm)Cold rolled Dimensions(L*W*H) 1355*120*1022(mm) steel P a g e | 17 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 18: Mechanical System

    Chassis: It is a carrier where the Traffic Indicator, Infrared Sensor and the Door lock are installed.  Core Component: The core component mainly consists of the Motor, Frame, Bearing and Door  Leaf. P a g e | 18 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 19: Electronic Control System

    Mars Pro-S1000: Infrared Sensor (IR Sensor Transmitter) Infrared Sensor (IR Sensor Receiver) Infrared Sensor Infrared Sensor (IR Sensor Transmitter) (IR Sensor Receiver) Master Slave  Mars Pro-S1200: P a g e | 19 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 20 Mars Pro-S1000 Series User Manual Infrared Sensor (IR Sensor Transmitter) Infrared Sensor (IR Sensor Receiver) Infrared Sensor (IR Sensor Transmitter) Infrared Sensor (IR Sensor Receiver) P a g e | 20 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 21: Authentication Methods

    Access Controller. When a user presses his / her card on the card reading area, the device enters card authentication mode. P a g e | 21 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 22: Fingerprint Verification

    Our company will assume no liability for recognition issues that may result from incorrect usage of the product. We reserve the right of final interpretation and modification concerning this point. P a g e | 22 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 23: Qr Code Verification

    Access Controller. Try to keep the face in the centre of the screen during authentication. Please face towards the camera and stay still during face registration. P a g e | 23 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 24 Mars Pro-S1000 Series User Manual Recommended Standing Posture and Facial Expression: Note: Please keep your facial expression and standing posture natural while enrollment or verification. P a g e | 24 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 25: Installation

    The reference figure is shown below: P a g e | 25 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 26: Installation Cabinet

    Remove the Top lid and Side Lid 1. Remove the four screws hidden under the top lid, then remove the top lid. 2. Remove the side lid that hang on the device. P a g e | 26 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 27 982mm 1100mm 922mm 1040mm 862mm 980mm 40mm 40mm 802mm 920mm 50mm 50mm 802mm 920mm 28mm 60mm 18mm 60mm P a g e | 27 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 28 2. Then insert the bolts vertically into the mounting holes as shown at right. 3. Make sure the bolts are placed in place. Use a hammer to tap the bolts into place, if needed. P a g e | 28 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 29 3. Tighten the nuts to hold the cabinet in place. Don't tighten it completely until after you're sure it won't move anymore. The f inished result is shown below: P a g e | 29 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 30 Mars Pro-S1000 Series User Manual P a g e | 30 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 31 Mars Pro-S1000 Series User Manual Stept 7 Close the Side Lid and Top Lid Close the side lid and top lid, and secure with screws. P a g e | 31 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 32 1. It is recommended that warning lines be marked on the ground and used to alert users. 2. A warning line can alert users to wait outside the line until the previous user completes the verif ication process and passes through the turnstile. P a g e | 32 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 33: Accessory Installation

    2. Pass the mounting bracket through the mounting holes. 3. Place the gasket and nut and tighten the nut to secure the unit. 4. Adjust the unit to a suitable angle. P a g e | 33 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 34: Door Leaf Installation

    Mars Pro-S1000 Series User Manual 3.5.2 Door Leaf Installation 1. Push the door leaf into the clamping block. 2. Lock the door leaf with the screws. P a g e | 34 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 35: Terminal Description

    12VOUT, GND 12V power supply output 24VOUT, GND 24 V power supply for the main board of the swing barrier BAT, GND Fire power supply for swing barrier P a g e | 35 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 36: Pgic Controller (Additional Accessory)

    B, G, R, GND, 12V Status indicator 485A, PE, 485B RS485 12V, GND, 485+, 485- Exit RS485 BEEP, GLED, WD1,WD0, GND, 12V Wiegand reader GND, IN *2 Auxiliary input IR sensor P a g e | 36 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 37: Ir Board

    R1, G1, R3, G3, R4, G4, GND, 24V 8-core connection wire 12V, R, G, GND *3 Left side indicator Master/Slave Motor Driving Controller Terminal Descriptions CANH, CANL, CGND CAN communication P a g e | 37 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 38 24V power supply input of clutch, Clutch Motor data cable input W, V, U, PE Motor three-phase input RBR+, NC, RBR- Reserved VDC, GND 24V power supply input P a g e | 38 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 39: Wiring Instructions

    Mars Pro-S1000 Series User Manual Wiring Instructions Master-slave Location The positions of the master and slave corresponding to single-lane, dual-lane and multi-lane are shown in the figure below. P a g e | 39 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 40: Wiring Methods

    Insert the ECU-panel connection wire through the PVC pipe and then into the Ethernet ports of the master and slave motor driving controller respectively to communicate via Ethernet, as shown in the following figure. P a g e | 40 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 41: Power And Air Switch Wiring

    120Vac and 240Vac primary power must be hard wired in place (Note: must be grounded). It is strongly recommended that a licensed electrician perform this procedure in accordance with applicable local codes. P a g e | 41 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 42: System Wiring Diagram

    Mars Pro-S1000 Series User Manual System Wiring Diagram P a g e | 42 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 43: Operation Process

    2. Credential Verification After the unit's power on self test is complete, you can test the door opening by pressing the Up button on the motherboard. P a g e | 43 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 44 The alarm signal will not be cancelled until the passenger retreats from the passage. The pedestrian can pass through the passage only after a valid card is successfully verified. P a g e | 44 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 45: Machine Operation

    Tips: For each function, you need to press ENT key first to start changing the parameters. 1. Correct Barrier Position Press ENT to modify, press UP/DOWN to select the correction type, and press ESC to exit. P a g e | 45 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 46 Zero position (Default)  Left opening position  Right opening position 2. Opening Mode Setting  Two-way controlled, both need verification (Default)  In need verification, Out free P a g e | 46 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 47 Mars Pro-S1000 Series User Manual  In free, Out need verification  Two-way free In need verification, Out prohibited  P a g e | 47 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 48 Mars Pro-S1000 Series User Manual  In prohibited, Out need verification  In free, Out prohibited In prohibited, Out free  P a g e | 48 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 49 The valid value is 2 to 60 seconds, and the default value is 5s. P a g e | 49 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 50 Set the gate opening speed to open the gate. The larger the number is set, the faster the speed. The gate opening speed value can be set between 1 to 20 and the default value is 3. P a g e | 50 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 51 1 to 20 and the default value is 3. 8. Swiping Limitations  Allowed swiping card in the channel (Default)  Forbidden swiping card in the channel P a g e | 51 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 52 The valid value for brake activation angle can be set between 3 to 10 and the default value is 3. 13. Firefighting Signal Setting According to the external fire device, select the corresponding type of trigger mode.  Right open Left open (Default)   Close P a g e | 52 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 53 Adjust the volume of the device, the valid value can be set between 1 to 16 and the default value is Close  15. IR Anti-pinch Setting  No-activated  Stop-activated (Default) P a g e | 53 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 54 When more than two legal access signals are given at the same time (including the same direction and the opposite direction), the system will remember all the pass requests and complete each pass in turn.  No (Default)  P a g e | 54 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 55 Note: ZKBZ main board 1.2 and ZKBZ main board 1.3 are set to 1, and ZKBZ main board 1.4 is set to 0. Otherwise, the voice does not broadcast. 21. Version Number  Version: V9.0.8 P a g e | 55 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 56: Maintenance

    Perform the safety check on a weekly basis to ensure that the turnstile is safe and ready for user operation. P a g e | 56 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 57: Troubleshooting

    When the gate is self-tested, the In the process of self-test, there are obstacles, swing arm is not in the normal please remove the obstacles, restart the self-test closing position! after power-on! P a g e | 57 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 58: Packing List

    The package consists of the following items:  Mars Pro-S1000: Mars Pro-S1000 (Master and Slave) Power Cable Card Expansion Screw M12*100 Washer Expansion Screw Washers Stainless Steel Maintenance Wipes Hex Wrench P a g e | 58 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 59 Mars Pro-S1000 Series User Manual  Mars Pro-S1200: Mars Pro-S1200 Power Cable Card Expansion Screw M12*100 Washer Expansion Screw Washers Stainless Steel Maintenance Wipes Hex Wrench P a g e | 59 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.

  • Page 60: Revision History

    User Manual Revision History Revision Date Author Reviewer Description V1.0 09/28/2021 Yang Kaijin Original Document The control board, and wiring V1.1 02/17/2025 Huang Liye diagram have been changed. P a g e | 60 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
  • Page 61 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2025 ZKTECO CO., LTD. All Rights Reserved. P a g e | 61 Copyright©2025 ZKTECO CO., LTD. All Rights Reserved.
