Industrial Ethernet Switch
User manual
MIEN2016
MIEN2018-2F
MIEN2024
MIEN2026-2F
1
The package of this switch contains the following items. If any item is found to be
missing or damaged, please contact the agent or the customer service center of
Maisvch for assistant.
Industrial Ethernet Switch
2
These series is L2 unmanaged rack-mount industrial Ethernet switch.
MIEN2016 provides 16 100M copper ports. MIEN2018-2F provides 2x100M
fiber ports+ 16x100M copper ports; MIEN2024 provides 24x100M copper
ports; MIEN2026-2F provides 2x100M fiber ports+ 24x100M copper ports.
Version:V2.1
Packing list
Items
Quantity
1PCS
Power cord
1PCS
User Manual
1PCS
Product description
Remarks
AD220 model only
Advertisement
Table of Contents
Related Manuals for Maisvch MIEN2016
Summary of Contents for Maisvch MIEN2016
- Page 1 Industrial Ethernet Switch These series is L2 unmanaged rack-mount industrial Ethernet switch. User manual MIEN2016 provides 16 100M copper ports. MIEN2018-2F provides 2x100M fiber ports+ 16x100M copper ports; MIEN2024 provides 24x100M copper ports; MIEN2026-2F provides 2x100M fiber ports+ 24x100M copper ports.
-
Page 2: Interface Description
Interface description with a 5.08mm pitch. Unit:mm It has adaptive function and supports automatic Take MIEN2026-2F as an example: MDI/MDI-X connection. The switch can be connected to 100M copper port end devices, servers, hubs, or other switches using straight-through or crossover cables. The 100M fiber port is a 100Base-FX full-duplex 100M fiber port single-mode or multi-mode optical fiber interface, and the... - Page 3 Alarm relay output normally closed Grounded Power 2 Input V2+/Positive(DC) The switch indicator lights description is shown in the table below: Power 2 Input V2-/Negative (DC) Indicator lights Status Definition System Status LED Power model input power range The power is connected and operating normally PWR1/PWR2 The power is not connected or the system is not AD220...
-
Page 4: Hardware Installation
Hardware Installation Installation Precautions To prevent equipment damage or personal injury caused by improper use, observe Installation Size the following precautions: Unit:mm During the installation process, you need to wear anti-static gloves or anti-static gloves, and power-off the switch. Please make sure that the input voltage is within the input voltage range marked ... -
Page 5: Device Connection
Step 1 Select the installation location of the device and make sure it has Removing rack-mounted device sufficient size. Step 1 The device is powered off. Step 2Use a screwdriver to loosen the 4 screws fixed on the rack ear. ... -
Page 6: Specifications
Specifications Storage -40℃~+85℃ Temp. MIEN2016 MIEN2018-2F MIEN2024 MIEN2026-2F Humidity 5%~95%(No condensation) Switch properties Bandwidth 8.8Gbps IEC61000-4-2(ESD),Level 4 Cache size 3Mbit IEC61000-4-5(Surge),Level 4※Ethernet ports support 6KV MAC table size lightning protection Port IEC61000-4- 4(EFT),Level 4 100M 2*100Base-FX 2*100Base-FX IEC61000-4-3(RS),Level 4 Fiber port... - Page 7 The accessories and power supply that come with the product are guaranteed for one year. When sending the product back to Maisvch for repair, we recommend using the original packaging or equivalent protective packaging to avoid risks during transportation.
