Industrial Ethernet Switch
User manual
MISCOM7210G-2GF-8GT
Packing list
1
The package of this switch contains the following items. If any item is found
to be missing or damaged, please contact the agent or the customer service
center of Maisvch for assistant
Items
Industrial Ethernet Switch
Power cord
User Manual
2
Product description
The switch is a full Gigabit managed din-rail industrial Ethernet switch.
MISCOM7210G-2GF-8GTE provides 10 Gigabit Ethernet ports (2 Gigabit
SFP ports and 8 Gigabit RJ45 ports).
V1.0
Quantity
Remarks
1PC
1PC
AD220V only
1PC
Advertisement
Related Manuals for Maisvch MISCOM7210G-2GF-8GT
Summary of Contents for Maisvch MISCOM7210G-2GF-8GT
- Page 1 Packing list The package of this switch contains the following items. If any item is found to be missing or damaged, please contact the agent or the customer service center of Maisvch for assistant Items Quantity Remarks Industrial Ethernet Switch...
-
Page 2: Interface Description
[Connect the power] Interface description The DC power supply model of this switch supports dual power input, and the two power supplies are mutually backup; Using 5-position locking terminals Unit:mm with 5.08mm spacing, the wiring definitions are as follows: Number Pin definition Power 1 Input V1+ /Positive(DC) Power 1 Input V1-/Negative (DC) - Page 3 The switch indicator lights description is shown in the table below: Indicator Status Definition lights System Status LED The power is connected and operating normally PWR1/PWR2 The power is not connected or the system is not operating normally Flashing The system is operating normally The system is not working properly Number Pin definition...
- Page 4 Hardware Installation [Device connection] Connect the network cable to the port in the correct direction. Installation Precautions To prevent equipment damage or personal injury caused by improper use, observe the following precautions: During the installation process, you need to wear anti-static gloves or ...
-
Page 5: Specifications
Storage Temp. -40℃~+85℃ and the user name and password are both "none". 5%~95%(No condensation) Humidity Industry Standard Specifications IEC61000-4-2(ESD), Level 4 MISCOM7210G-2GF-8GT IEC61000-4-5(Surge), Level 3 ※Ethernet ports support 6KV lightning protection Switch properties IEC61000-4- 4(EFT), Level 4 Bandwidth 20Gbps Cache size 4.1Mbit... -
Page 6: Order Guide
The accessories and power supply that come with the product are guaranteed for one year. When sending the product back to Maisvch for repair, we recommend using the original packaging or equivalent protective packaging to avoid risks during transportation.
