Industrial Ethernet Switch
User manual
MIEN3210G-2GF-8GT
MIEN3210GP-2GF-8GTPoE
Packing list
1
The package of this switch contains the following items. If any item is found to be
missing or damaged, please contact the agent or the customer service center of
Maisvch for assistant
Items
Industrial Ethernet Switch
User Manual
Power cord
Product description
2
The switch is a full Gigabit unmanaged din-rail industrial Ethernet switch.
MIEN3210GP-2GF-8GTPoE provides 10 Gigabit Ethernet ports (2 Gigabit SFP ports
and 8 Gigabit PoE ports). MIEN3210G-2GF-8GT provides 10 Gigabit Ethernet ports
(2 Gigabit SFP ports and 8 Gigabit copper ports).
Version:V1.0
Quantity
Remarks
1PCS
1PCS
1PCS
AD220 only
Advertisement
Table of Contents
Related Manuals for Maisvch MIEN3210G-2GF-8GT
Summary of Contents for Maisvch MIEN3210G-2GF-8GT
- Page 1 The switch is a full Gigabit unmanaged din-rail industrial Ethernet switch. MIEN3210GP-2GF-8GTPoE provides 10 Gigabit Ethernet ports (2 Gigabit SFP ports and 8 Gigabit PoE ports). MIEN3210G-2GF-8GT provides 10 Gigabit Ethernet ports (2 Gigabit SFP ports and 8 Gigabit copper ports).
-
Page 2: Interface Description
4.Indicator light 6.Din rail kit Interface description Unit:mm Connect to the Power AC top view DC top view Using 5-position locking terminals with 5.08mm spacing. It supports dual power supply input, two power supply backup each other. Number Pin definition Power 1 Input V1+/Positive Power 1 Input V1-/Negative Grounded... - Page 3 Number Pin definition Alarm relay output normally open Alarm relay output common terminal Alarm relay output normally closed Number Pin definition Power input L/V+ The indicator description of the switch is shown in the following table. Power input N/V- Grounded Indicator lights Status Definition...
-
Page 4: Hardware Installation
Device connection Hardware installation Cable connection Connect the optical fiber and network cable to the port in the correct Installation Precautions To prevent equipment damage or personal injury caused by improper use, observe the following precautions: During the installation process, you need to wear anti-static gloves or anti-static ... -
Page 5: Specifications
2. Power-off operation: first unplug the power plug, and then remove the power Weight About 0.8kg cord. Working environment Operating temp. -40～+85℃ Specifications Storage temp. -40～+85℃ MIEN3210G-2GF-8GT MIEN3210GP-2GF-8GTPOE Humidity 5～95% (No condensation) Switch performance Bandwidth Industry standard Cache size 1.5Mbit IEC61000-4-2(ESD), Level4... - Page 6 The accessories and power supply that come with the product are guaranteed for one year. When sending the product back to Maisvch for repair, we recommend using the original packaging or equivalent protective packaging to avoid risks during transportation.
