Tronair 10-6412-0000 Operation & Service Manual

Lavatory service unit
Hide thumbs

Advertisement

Table of Contents

For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com
OPERATION & SERVICE MANUAL
Model: 10-6412-0000
Lavatory Service Unit
09/2024 – Rev. 02
The Tronair Group of Companies:
Tronair | EBIS | Columbus Jack | Eagle | DAE | Malabar International
Tronair, Inc.
Phone: (419) 866-6301 | 800-426-6301
1 Air Cargo Pkwy East
Web: www.tronair.com
Swanton, OH 43558
Email: sales@tronair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10-6412-0000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tronair 10-6412-0000

Summary of Contents for Tronair 10-6412-0000

  • Page 1 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com OPERATION & SERVICE MANUAL Model: 10-6412-0000 Lavatory Service Unit 09/2024 – Rev. 02 The Tronair Group of Companies: Tronair | EBIS | Columbus Jack | Eagle | DAE | Malabar International Tronair, Inc.
  • Page 2 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com REVISION DATE TEXT AFFECTED 12/2013 Original release 09/2024 Major revision...
  • Page 3 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit TABLE OF CONTENTS PAGE PRODUCT INFORMATION .............................. 1 DESCRIPTION..............................1 MODEL & SERIAL NUMBER ..........................1 MANUFACTURER .............................. 1 SPECIFICATIONS .............................. 1 FILL (FRESH) SYSTEM ............................

  • Page 4: Specifications

    Model: 10-6412-0000 Lavatory Service Unit This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., its suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.

  • Page 5: Training Program

    Read this entire manual prior to operation of the unit. All personnel using this Electric Lavatory Service Unit should understand and follow this manual and receive training. We encourage our customers to call Tronair to discuss any operating or testing requirements, telephone: (419) 866-6301 or (800) 426-6301.

  • Page 6: Troubleshooting

    For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit STORAGE The tank must be drained before storage. Disconnect all battery connections. Store the unit in a clean, dry place when not in use.
  • Page 7 If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes on any shipping documents.
  • Page 8 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. 09/2024 | Rev. 02 Page | 5...
  • Page 9 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Parts List Item Part Number Description Z-7425 ASSEMBLY, PUMP H-1996 BOX, BATTERY G-1235 NUT, SS BATTERY HOLD DOWN EC-1656 BATTERY, 12 VOLT...
  • Page 10 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Parts List Item Part Number Description K-3970 KIT, PIN REPLACEMENT; consists of: G-1301-02 PIN, COTTER, 1/8" DIAMETER X 1" LONG R-2096 K-1550 KIT, WHEEL (SINGLE) REPLACEMENT;...
  • Page 11 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description K-1253 KIT, BEARING &...
  • Page 12 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Pump Assembly Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. 09/2024 | Rev. 02...
  • Page 13 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit Parts List Item Part Number Description ; consists of: Z-7425 ASSEMBLY, PUMP G-1159-103506 SCREW, #10-32 RD HD CRS REC G-1250-1030N FLATWASHER, #10 NARROW...
  • Page 14 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 15 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit APPENDIX I Johnson Controls Safety Data Sheet...
  • Page 16 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 17 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 18 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 19 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 20 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 21 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 22 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 23 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 24 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 25 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 26 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
  • Page 27 For 10-6412-0000 sales, parts and service, click here to view this item on PilotJohn.com Model: 10-6412-0000 Lavatory Service Unit...
