- Page 1 KSZ8895 EDS2 Daughter Card User Guide 2025 Microchip Technology Inc. and its subsidiaries DS50003881A...
-
Page 2: Legal Notice
“Microchip” name and logo, the “M” logo, and other names, logos, and brands are registered and unregistered trademarks of Microchip Technology Incorporated or its affiliates and/or subsidiaries in the United States and/or other countries (“Microchip Trademarks”). Information regarding Microchip Trademarks can be found at https://www.microchip.com/en-us/about/legal-information/microchip-... -
Page 3: Table Of Contents
Chapter 2. Getting Started 2.1 Overview ...................... 13 2.2 KSZ8895 Installation ..................13 2.3 Quick Start ....................16 2.4 KSZ8895 EDS2 Daughter Card Removal ............ 16 Chapter 3. Hardware 3.1 Introduction ....................17 3.2 Connectors ....................18 3.3 Test Points ....................19 3.4 LEDS ...................... - Page 4 KSZ8895 EDS2 Daughter Card User Guide Appendix B. Bill of Materials B.1 Introduction ....................37 Appendix C. PCB Layers C.1 Introduction ....................41 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 4...
-
Page 5: Preface
• Customer Support • Document Revision History DOCUMENT LAYOUT This document features the KSZ8895 EDS2 Daughter Card. The manual layout is as fol- lows: • Chapter 1. “Overview” – This chapter provides an overview of the KSZ8895 EDS2 and a brief description of the card’s features. -
Page 6: Conventions Used In This Guide
Choice of mutually exclusive errorlevel {0|1} character: { | } arguments; an OR selection Ellipses... Replaces repeated text var_name [, var_name...] Represents code supplied by void main (void) user { ... 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 6... -
Page 7: Warranty Registration
MPLAB REAL ICE in-circuit emulator, MPLAB ICD 3 in-circuit debugger and MPLAB PM3 device programmers. Also included are nonproduction development programmers such as PICSTART Plus and PIC-kit 2 and 3. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 7... -
Page 8: Customer Support
Technical support is available through the web site at: http://www.microchip.com/support DOCUMENT REVISION HISTORY Revisions Section/Figure/Entry Correction DS50003881A Initial release (05-30-25) 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 8... -
Page 9: Chapter 1. Overview
Chapter 1. Overview INTRODUCTION The KSZ8895 EDS2 Daughter Card is designed for evaluation of the Microchip KSZ8895 Gigabit Ethernet RGMII Switch when used with a Microchip EDS2 compati- ble host board. A SODIMM 260-pin connector for the EDS2 Host – KSZ8895 Interface is used due to its high performance, high pin count, and low cost. -
Page 10: Features
KSZ8895 EDS2 Daughter Card User Guide FEATURES Below are the features of the KSZ8895 EDS2 Daughter Card: • Microchip KSZ8895RQX 10/100 Ethernet Switch with RMII • Microchip VXM7-9013-25M0000 crystal for 25 MHz • Microchip MIC2790N Reset supervisor with Reset LED indicator •... - Page 11 Small Outline Dual In-Line Memory Module TCXO Temperature-Compensated Crystal Oscillator TFTP Trivial File Transfer Protocol Universal Asynchronous Receiver/Transceiver VDFN Very-Small Dual Flat, No Leads Virtual Machine VREG Voltage Regulator Crystal Oscillator 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 11...
- Page 12 KSZ8895 EDS2 Daughter Card User Guide NOTES: 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 12...
-
Page 13: Chapter 2. Getting Started
Chapter 2. Getting Started OVERVIEW This chapter provides a quick start guide for using the KSZ8895 EDS2 Daughter Card. The SAM9x75 Curiosity (Rev 5) serves as the host board. Refer to the SAM9x75 Curi- osity User's Guide for the correct jumper configuration. - Page 14 KSZ8895 EDS2 Daughter Card User Guide Perform the following steps to install the KSZ8895 EDS2 Daughter Card in the SOD- IMM EDS2 connector: 1. Verify that the host board power is OFF. 2. Verify if the SW1 slide switch is set as shown in Figure 2-2.
- Page 15 Connecting or disconnecting Ethernet cables after the board is powered is NOT recom- mended as the board fingers could be disconnected from the SODIMM receptacle and leave the board in an inconsistent state or even cause damage to the board. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 15...
-
Page 16: Quick Start
KSZ8895 EDS2 Daughter Card User Guide QUICK START Conduct the following steps to start using the KSZ8895 EDS2 Daughter Card: 1. Insert a programmed microSD card on SAM9X75 Curiosity microSD card slot J14. 2. Connect a USB to serial cable to SAM9X75 Curiosity J35. -
Page 17: Chapter 3. Hardware
USER GUIDE Chapter 3. Hardware INTRODUCTION This chapter provides a description of the KSZ8895 EDS2 Daughter Card hardware, including headers, test points, LEDs, and switches on the board. The top side and bottom side of the KSZ8895 are shown in... -
Page 18: Connectors
KSZ8895 EDS2 Daughter Card User Guide FIGURE 3-2: KSZ8895 EDS2 DAUGHTER CARD (BOTTOM SIDE) CONNECTORS Table 3-1 describes the connectors on the KSZ8895 EDS2 Daughter Card. TABLE 3-1: KSZ8895 EDS2 DAUGHTER CARD CONNECTORS Reference Designator Name Description RJ45 ICM Ethernet RJ45 connector with integrated magnetics for 1 Gb ports 1 and 2. -
Page 19: Test Points
KSZ8895 LED3-1 J2B - Left RJ45 Port 4 - Left Green LED connected to KSZ8895 LED4-0 J2B - Right RJ45 Port 4 - Right Yellow LED connected to KSZ8895 LED4-1 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 19... -
Page 20: Configuration Straps
KSZ8895 EDS2 Daughter Card User Guide CONFIGURATION STRAPS Table 3-4 shows the configuration straps on the KSZ8895 EDS2 Daughter Card. TABLE 3-4: KSZ8895 CONFIGURATION STRAPS Reference Designator Name Description PU/PD R23*/R24 Gigabit Select 0 – 10/100 Mbps 1* – 1 Gbps... -
Page 21: Clocks
IMM EDS2 connector. POWER The KSZ8895 EDS2 Daughter Card requires 3.3V, 2.5V, and 1.2V. The EDS2 SODIMM EDS2 interface provides 3.3V, 2.5V, and VARIO (3.3V or 2.5V). An on-board MOSFET, driven by the KSZ8895 LDO, is used to generate the 1V2 required by the KSZ8895 analog and digital core power inputs. - Page 22 ASCII UNG board revision letter BREVD ASCII Dev Tools board revision number IDBYTE0 ID BYTE 1 = AAh IDBYTE1 ID BYTE 2 = 00h IDBYTE2 ID BYTE 3 = 00h CHECKSUM CHECKSUM = AAh 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 22...
- Page 23 Hardware The EEPROM’s contents can be read within Linux via the following command: # i2cdump -f -y -r 0-0x7F 1 0x54 FIGURE 3-5: EEPROM DUMP 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 23...
- Page 24 KSZ8895 EDS2 Daughter Card User Guide NOTES: 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 24...
-
Page 25: Chapter 4. System Boot
Linux software running on the SAM9X75. The boot process for other EDS2 host platforms should be similar. The EDS2 host board should be properly configured with Linux and driver supporting the KSZ8895. Refer to the software documentation on the KSZ8895 EDS2 Daughter Card product page. - Page 26 6. Open Tera Term. Tick the Serial radio button and look for COMx:USB Serial Port. 7. COM11 is shown in Figure 4-4. Windows may assign a different port number. Click on OK. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 26...
- Page 27 System Boot FIGURE 4-4: TERA TERM SERIAL PORT SELECTION 8. Go to the Setup menu and select Serial port. See Figure 4-5. FIGURE 4-5: TERA TERM SETUP MENU 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 27...
- Page 28 4-7. ® FIGURE 4-7: LINUX PING Note: For the succeeding steps, it is assumed that a host PC with an Ethernet port that can be pinged at 192.168.0.80 is available. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 28...
- Page 29 12. Plug an Ethernet cable into one of the RJ45 ports. Check the link status with the IP utility. One of the LAN ports shows an “Up” status indicator. See Figure 4-9. FIGURE 4-9: # IP -C LINK 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 29...
- Page 30 FIGURE 4-10: # IP -C ADDR 14. Enter the following command to perform a ping test (see Figure 4-11): #ping 192.168.0.80 FIGURE 4-11: KSZ8895 EDS2 DAUGHTER CARD SYSTEM PING TEST 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 30...
-
Page 31: Appendix A. Schematics
KSZ8895 EDS2 DAUGHTER CARD USER GUIDE Appendix A. Schematics INTRODUCTION This appendix shows the KSZ8895 EDS2 Daughter Card schematics. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 31... -
Page 32: Title Page
FIGURE A-1: KSZ8895 EDS2 DAUGHTER CARD TITLE PAGE Title Page Revision History Table of Contents Revision Date Revision Summary Author Sheet Description 04/11/2024 Intial draft Alexys Antell Title Page 10/14/2024 Adding gated 3V3 for RJ-45 LEDs. Fixing hole for J2... - Page 33 FIGURE A-2: KSZ8895 EDS2 DAUGHTER CARD POWER Power Power VDDC 220R VDDC 1V2 Power VDDC VDDC 0.1uF 0.1uF 0.1uF Power "1V2" Power VARIO VDDAR 220R VDDAR i Power GREEN VDDAR SI9433 VDDAR 10uF 0.1uF GNDD 0.1uF 0.1uF 0.1uF 100k GNDD...
- Page 34 FIGURE A-3: KSZ8895 EDS2 DAUGHTER CARD PHY, CLOCK, AND STRAPS KSZ8895, Clock, and Straps Configuration Straps KSZ8895RQX RMII_RX SMRXD0 MDIX-XDIS Auto MDI/MDIX 5[3B] SMRXD0 SMRXD0 RXP1 RX1_P 4[2A] SMRXD1 Normal* 5[3B] SMRXD1 SMRXD1 RXM1 RX1_N 4[2A] VARIO SMRXD2 Disable MDI/MDIX...
-
Page 35: Ethernet Ports
FIGURE A-4: KSZ8895 EDS2 DAUGHTER CARD ETHERNET PORTS Ethernet Ports 3[4A] RX1_P 3[4A] RX3_P 0.1uF 0.1uF 3[4A] RX1_N 3[4A] RX3_N 3[4B] TX1_P 3[4B] TX3_P 0.1uF 0.1uF 3[4B] TX1_N 3[4B] TX3_N 4X 75R 4X 75R SHLD SHLD 1000pF 1000pF 1nF,2kV 1nF,2kV... - Page 36 FIGURE A-5: KSZ8895 EDS2 DAUGHTER CARD SODIMM EDGE CONNECTOR Serial Bus Configuration VARIO PHYID SODIMM Edge Connector Pin Configuration Serial Bus Configuration VARIO 24AA014H PS[1:0] = 10 SPI Slave Mode for CPU Interface* 0.1uF VARIO 4.7k 3[2C] Interface Configuration I2C Addr = 101_010xb...
-
Page 37: Appendix B. Bill Of Materials
KSZ8895 EDS2 DAUGHTER CARD USER GUIDE Appendix B. Bill of Materials INTRODUCTION This appendix contains the KSZ8895 Bill of Materials (BOM). 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 37... - Page 38 TABLE B-1: BILL OF MATERIALS Item Reference Description Populated Manufacturer Manufacturer Part Number C1, C2, C3, C6, C7, C8, C10, C11, CAP CER 0.1uF 16V 10% X7R SMD 0402 KEMET C0402C104K4RACAUTO C12, C13, C14, C15, C16, C21, C22, C23, C24, C27, C28, C29, C30 CAP CER 10UF 25V 20% X5R SMD 0603 Murata Electronics North GRM188R61E106MA73D...
- Page 39 Keystone 5004 TP4, TP6 MISC, TEST POINT MULTI PURPOSE MINI BLACK Keystone 5001 MCHP INTERFACE ETHERNET KSZ8895RQX PQFP-128 Microchip Technology KSZ8895RQX MCHP ANALOG SUPERVISOR 0.4V to 5.5V Microchip Technology MIC2790N-04VD6 MIC2790N-04VD6 SOT-23-3 MCHP MEMORY SERIAL EEPROM 1kb I2C 24AA014H-I/SN Microchip Technology...
- Page 40 KSZ8895 EDS2 Daughter Card User Guide NOTES: 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 40...
-
Page 41: Appendix C. Pcb Layers
KSZ8895 EDS2 DAUGHTER CARD USER GUIDE Appendix C. PCB Layers INTRODUCTION This appendix contains the KSZ8895’s silkscreen top and bottom layers. 2025 Microchip Technology Inc. and its subsidiaries DS50003881A-page 41... - Page 42 FIGURE C-1: KSZ8895 EDS2 DAUGHTER CARD TOP SILK SCREEN...
- Page 43 FIGURE C-2: KSZ8895 EDS2 DAUGHTER CARD TOP COPPER...
- Page 44 FIGURE C-3: KSZ8895 EDS2 DAUGHTER CARD BOTTOM COPPER...
- Page 45 FIGURE C-4: KSZ8895 EDS2 DAUGHTER CARD BOTTOM SILK SCREEN...
