User's manual
Manual del usuario
Manuel de l'utilisateur
Customer Service
Servicio de atención al Cliente
Service à la clientèle
US: 1-800-645-2986
US: 1-800-645-2986
Canada: 888-645-2986
GONDOLA SHELVING -
WALL STARTER & Wall Add-On
Model(s): 243454/243455/243456/243457
Note: Owner/Operator must read and understand this instruction manual before using the GONDOLA
SHELVING
Rev A: 4/22/2024
1
Advertisement
Related Manuals for Global Industrial GONDOLA 243454
Summary of Contents for Global Industrial GONDOLA 243454
- Page 1 User's manual Manual del usuario Manuel de l'utilisateur Customer Service Servicio de atención al Cliente Service à la clientèle US: 1-800-645-2986 US: 1-800-645-2986 Canada: 888-645-2986 GONDOLA SHELVING - WALL STARTER & Wall Add-On Model(s): 243454/243455/243456/243457 Note: Owner/Operator must read and understand this instruction manual before using the GONDOLA SHELVING Rev A: 4/22/2024...
- Page 2 GONDOLA SHELVING T O O L S N E E D E D L e v e l i n g W r e n c h ( i n c l u d e d ) Global PN: 243454 Global PN Description Quantity...
- Page 3 GONDOLA SHELVING T O O L S N E E D E D L e v e l i n g W r e n c h ( i n c l u d e d ) Global PN: 243456 Global Description Quantity...
- Page 4 GONDOLA SHELVING Shelf Load Capacity SHELF DEPTH 16" SHELF DEPTH 22" SHELF TYPE SHELF WIDTH SHELF ANGLES RECOMMENDED UNIFORM LOAD CAPACITY NOTE: Reduce capacities 36" Deck 600 LBS (275 KGS) 800 LBS (365 KGS) shown by 30% when only the front half Base Shelf (Deck) of the shelf/deck is loaded or by 50% if 48"...
- Page 5 GONDOLA SHELVING ○ ○ ○ ○ ○ NOTE: Do not adjust leveling legs on base brackets or uprights currently. Step 1. Push ②bracket into ①upright slots from two sides, then push down to secure. (It is necessary to secure the spring on Two persons work together.
- Page 6 GONDOLA SHELVING ○ ○ ○ NOTE: Splicer rail is only used for two- piece back installation. Step 3. Insert ⑦Pegboard from top to bottom, make sure the board is IMPORTANT! If ceiling height is not adequate to drop panels from top, you secured by slot on the rails, then install ⑩splicer rail on the top of can pull the upright apart to make an angle, let the upside opening larger and the ⑦Pegboard, secured on the two side uprights, after that...
- Page 7 GONDOLA SHELVING ○ ○ ○ ○ ○ Step 4. Step 5. Install 2pcs③base end trim according to the detailed Install ⑧based desk onto the Base Bracket, after picture. Insert ⑤top rail onto the top, then insert 2pcs the installation, if it is not level, use the wrench to ⑨upright trim from top to bottom, finally assemble 2pcs adjust the height of the levelers on Upright and Base ⑬top cap with the upright.
- Page 8 GONDOLA SHELVING T O O L S N E E D E D L e v e l i n g W r e n c h ( i n c l u d e d ) Global PN: 243455 Global PN Description Quantity...
- Page 9 GONDOLA SHELVING T O O L S N E E D E D L e v e l i n g W r e n c h ( i n c l u d e d ) Global PN: 243457 Global PN Description Quantity...
- Page 10 GONDOLA SHELVING ○ IMPORTANT! If ceiling height is not adequate to drop panels from top, you can pull the upright apart to make an angle, let the upside opening larger and then install the Pegboard from the front. The pegboard can be bent slightly, but don't use too much force, otherwise the pegboard will break.
- Page 11 GONDOLA SHELVING ○ ○ ○ ○ ○ Step 3. Step 4. ○ install 8 splicer rail on the top of the Pegboard, secured ○ Install 3 base end trim (from starter) according to the detailed ○ on the two side uprights, after that insert 10 top ○...
- Page 12 GONDOLA SHELVING ○ The final assembly image is shown in the figure. Step 5. ○ Install 7 based desk onto the Base Bracket, after the installing, if it is not level, use the wrench to adjust the height of the levelers on Upright and Base Bracket, until the shelf is straight and level.
