GoldenDesigns GDI-7689-01 Owner's Manual

2, 3 and 6 person saunas
Hide thumbs Also See for GDI-7689-01:
Table of Contents

Advertisement

Quick Links

Download this manual
GDI-7289-01 / GDI-7389-01 / GDI-7689-01
2, 3 and 6 Person Saunas
OWNER'S MANUAL
FOR STEAM MODEL SAUNAS
REQUIRES 240VAC /1PHASE (30/40AMP, depending on your electrical code)
DEDICATED CIRCUIT FOR THE STOVE
REQUIRES 120VAC 15 AMP CIRCUIT FOR THE SAUNA
Please Note: The stove must be installed by a certified electrician per the
manufacturer's manual. The stove must be installed per the electrical code
in your area with reference to the breaker and wire sizes. Models are subject
to change.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDI-7689-01 and is the answer not in the manual?

Questions and answers

Related Manuals for GoldenDesigns GDI-7689-01

Summary of Contents for GoldenDesigns GDI-7689-01

  • Page 1 GDI-7289-01 / GDI-7389-01 / GDI-7689-01 2, 3 and 6 Person Saunas OWNER’S MANUAL FOR STEAM MODEL SAUNAS REQUIRES 240VAC /1PHASE (30/40AMP, depending on your electrical code) DEDICATED CIRCUIT FOR THE STOVE REQUIRES 120VAC 15 AMP CIRCUIT FOR THE SAUNA Please Note: The stove must be installed by a certified electrician per the manufacturer’s manual.
  • Page 2 Thank you for the purchase of your new Steam Sauna! FOLLOW ALL INSTRUCTIONS AND BE CAUTIOUS OF SAFETY SYMBOLS. All electrical wiring must be performed by a qualified licensed electrician. High Voltage Symbol: Be cautious as there is the presence of a high voltage current that flows through the equipment! General Caution Symbol: Be cautious as the equipment uses electrical current that can cause serious injury.
  • Page 3 CAUTION: Exit sauna immediately if you feel dizzy, sleepy, or any discomfort. READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-7289-01 *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown. Parts and accessories may vary.
  • Page 4 GDI-7289-01 Schematics *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown. Parts and accessories may vary.
  • Page 5 CAUTION: Exit sauna immediately if you feel dizzy, sleepy, or any discomfort. READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-7389-01 *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown. Parts and accessories may vary.
  • Page 6 GDI-7389-01 Schematics *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown. Parts and accessories may vary.
  • Page 7 CAUTION: Exit sauna immediately if you feel dizzy, sleepy, or any discomfort. READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-7689-01 *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown.
  • Page 8 GDI-7689-01 Schematics *The above assembly diagram i s for quick reference only. Read all instructions before assembling. All sauna models may not be shown. Parts and accessories may vary.

  • Page 9: Table Of Contents

    TABLE OF CONTENTS Product Introduction Parts Description Assembly Instructions Control Panel Operation Tips for Using Your Sauna Safety Instructions Safeguards for Your Sauna Warranty Warranty Card WARNING: Visually inspect all parts before assembly to make sure they are not damaged. Any excessive vibrations during transport could cause damage to the sauna components.
  • Page 10 B. The SIDE WALL PANELS are the same size. The LEFT SIDE WALL PANEL on model GDI-7289-01 will have a vent at the top of the wall panel. The RIGHT SIDE WALL PANEL on models GDI-7389-01 and GDI-7689-01 will have a vent at the top of the wall panel. (see Figure 2)

  • Page 11: Assembly Instructions

    1. The location must be dry, leveled, and away from any source of water. 2. The stove must be installed by a certified electrician. 3. Two adults are required for installation on model GDI-7289-01 and three adults for installation on models GDI-7389-01/GDI-7689-01. 4. Wood cabin installation order: REAR WALL PANEL RIGHT SIDE WALL...
  • Page 12 RIGHT SIDE WALL PANEL to the REAR WALL PANEL. Make sure to use the correct size wood screws when screwing the wall panels together. (see Figure 6 & 7) GDI-7289-01 GDI-7389-01 GDI-7689-01 Figure 6...
  • Page 13 Figure 7 D. Installing the FLOOR WOOD GRADE and FRONT WALL PANEL to the LEFT SIDE WALL PANEL and RIGHT SIDE WALL PANEL 1. First, place the FLOOR PANEL on the inside of the sauna room and on your floor (concrete floor is preferred). Two/three adults will be need to install the front wall panel.
  • Page 14 1. Hold the SECOND LAYER BENCH SUPPORT PANEL vertically in place and install it as seen in Figure 9 below. The SECOND LAYER BENCH SUPPORT PANEL is only on model GDI-7689-01. 2. Next, hold the FIRST LAYER BENCH SUPPORT PANEL vertically in place and Install it as seen in Figure 9 below.
  • Page 15 BENCH (upper bench for model GDI-7689-01 only). (see Figure 11) 2. Next, slide into position the SECOND LAYER BENCH (upper bench for models GDI-7689-01). The screw locations are indicated with arrows for the upper and lower benches. (see Figure 12 & 12a)(Please Note: ONLY INSTALL BENCH ALONG REAR WALL AT THIS TIME) 3.
  • Page 16 Figure 12a Figure 13 GDI-7289-01 Figure 13a...
  • Page 17 (see Figure 14 & 15) Also, you will need to connect the wire connection from the RIGHT REAR CORNER to the wire connection on the BACKREST ON THE RIGHT SIDE WALL PANEL (for GDI-7389-01 & GDI-7689-01). After connected, tuck the wires behind the BACKREST. Use the provided screws to screw into place.
  • Page 18 H. Installing the FAN SHAPED BENCH, RIGHT SIDE BENCH SUPPORT PANEL, RIGHT SIDE BENCH REINFORCEMENT, and RIGHT SIDE BENCH (only on models GDI- 7389-01 and GDI-7689-01) 1. You are ready to install the FAN SHAPED BENCH, RIGHT SIDE BENCH SUPPORT PANEL, and RIGHT SIDE BENCH REINFORCEMENT.
  • Page 19 Figure 18 2. The RIGHT SIDE BENCH and FAN SHAPED BENCH are ready to be installed. (see Figure 19, 20, & 21) Figure 19 Figure 20 GDI-7389-01 GDI-7689-01 Figure 21...
  • Page 20 1. Place the ROOF PANEL over the wall panels carefully. (see Figure 22) 2. Next, carefully slide the ROOF PANEL into place. 3. Use the provided screws to secure the roof into place. (see Figure 23 & 24) GDI-7289-01 GDI-7389-01 GDI-7689-01 Figure 22 Figure 23...
  • Page 21 Figure 24 Please Note: Model designs are subject to change. Steam heater must be installed by a certified electrician. J. Installing the Stove Please Note: The stove must be installed by a certified electrician per the manufacturer’s manual. The stove must be installed per the electrical code in your area with reference to the breaker and wire sizes &...
  • Page 22 2. Next, the stove will need to be lifted and placed inside the wood housing and onto the metal brackets at the bottom of the wood housing. (see Figure 25) Figure 25 ASSEMBLY COMPLETED!
  • Page 23 SAUNA CONTROL PANEL - GENERAL INTRODUCTION 1. Description of Functions Functions Touch Key technology √ FM Radio √ Reading Lamp √ Background Lamp and Star Lights √ Bluetooth Music Play √ 2. Control System Specifications A.) Rated Voltage: AC100V-AC240V B.) Bluetooth Approximate Effective Distance: 33 feet C.) Rated Power: 50Hz/60Hz 3.

  • Page 24: Control Panel Operation

    5. Control Panel Display CONTROL PANEL OPERATION 1. “ “: Powers the unit “ON/OFF”. A.) Press the “ “ to turn the Control Panel “ON”. The LED will display “ “, which means the Control System has powered “ON”. In addition, the Reading Lamp should be “ON”...
  • Page 25 A.) Press the “ “ to turn on the Background Lamp and Star Lights. The LED will show “ “. Press the “ “ again to turn the Background Lamp and Star Lights “OFF” and the “ “ will disappear. 4.

  • Page 26: Tips For Using Your Sauna

    Once the Bluetooth is connected to your musical device, the “ “ and “ “ will stop flashing. If the “ “ and “ “ continue to flash, then your musical device has not connected to the Bluetooth. To disconnect your device from the Bluetooth, turn off your device and press “...

  • Page 27: Safety Instructions

    body has cooled down and you feel comfortable, you can exit the sauna. After about twenty minutes and when your body has completely cooled down, you can take a shower to rinse the perspiration off your body. Safety Instructions 1.) Read and follow all instructions carefully before using the sauna. 2.) When installing and using the electrical equipment, safety precautions should always be followed.

  • Page 28: Safeguards For Your Sauna

    wet feet to avoid risk of electric shock. Never touch the metal prongs of the plug. 18) Do not attempt to make any repairs yourself without contacting the manufacturer first. If a problem occurs with the sauna, please contact seller, distributor, or the manufacturer to avoid safety risks.

  • Page 29: Warranty

    Limited Lifetime Warranty *Limited Lifetime Warranty: Golden Designs, Inc. warranties the sauna room and its attached electronics against defects in material and workmanship for the life of the product from the original date of purchase. This sauna is for indoor use or outdoor use when protected from the outdoor weather elements by a structure that includes a water-proof roof.
  • Page 30 Since the wood used in construction has been kiln dried, a certain amount of expansion and contraction occurs in the wood in a sauna environment. Disclaimers Golden Designs, Inc. shall not be liable for loss of use of sauna or other Golden Designs, Inc. products or other secondary or incidental or consequential costs, expense or damages - which may include the removal of permanent structures or other custom fixtures or the necessity for crane removal - arising directly or indirectly out of the use or inability to use the product.

  • Page 31: Warranty Card

    WARRANTY CARD Congratulations on your purchase of an Infrared Sauna from Golden Designs, Inc. Please take the time to complete the following Warranty Card and mail it back to: Golden Designs, Inc. 3550 Jurupa Street, Unit B Ontario, CA 91761 Please include a copy of your sales receipt showing date of purchase as this will serve as proof of purchase.
