- Page 1 AQUUS 600 GPD Tankless 1.5:1 RO Filtration System with Smart Faucet Setup Manual Model No.: TROE600COL...
-
Page 2: Table Of Contents
Table of Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Intended Use . -
Page 3: Safety Information
Safety Information WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling, installing, and operating this filtration system . • This RO water filtration system is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety . -
Page 4: Intended Use
Intended Use This appliance is intended to be used in household and similar applications such as: • Staff kitchen areas in shops, offices, and other working environments • Farm houses • Hotels, motels, and other residential-type environments • Bed-and-breakfast environments •... -
Page 5: Product Features
Product Features Part Description Part Description RO filter compartment Purified water port PCB filter compartment Filtered water port Indicator panel Inlet water port System power cord connection Filtered water handle Smart faucet power cord connection Purified water handle Wastewater port Indicator Panel Description No . -
Page 6: Technical Specifications
Technical Specifications Model No . TROE600COL Daily Purified (RO) Production Rate 600 GPD Filtered Water Flow Rate 2 .5 L/min Purified Water Flow Rate 1 .5 L/min Recovery Rate 1 .5:1 Product Dimensions (WxHxD) 5 .2 x 16 .6 x 18 .2 in . (13 .2 x 42 x 46 .2 cm) Net Weight 28 .2 lb (12 .8 kg) TDS Reduction Rates... -
Page 7: Connect To The Cold Water Supply
2 . Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE . The water supply to the unit MUST be from the COLD WATER LINE . Using HOT WATER will severely damage your filters . Turn off cold water supply . -
Page 8: Connect The Ro Wastewater Tube
3 . Connect the RO Wastewater Tube The drain saddle (K) is designed to fit around a standard 1 .5 in . OD (outer diameter) drain pipe . Always install the drain saddle before the P-trap and on a straight vertical or horizontal section of the pipe . -
Page 9: Install The Smart Faucet
4 . Install the Smart Faucet NOTE: An optional faucet base (T) has been included to accommodate your sink hole . If using, thread power cord through it before mounting faucet on counter . Ensure that you have a faucet mounting hole in your sink or sink countertop for this faucet . If you do not, create a mounting hole no less than 1 –... -
Page 10: Complete The Installation
5 . Complete the Installation IMPORTANT: The filtration system has been fitted with protective plugs to ensure system ports are not damaged during shipping . Plugs MUST BE removed before connecting tubing . To remove plugs, slide release tool of tube cutter (N) around the base of the plug and over top of gray collar . -
Page 11: Shutting Down The Water Filtration System
Shutting Down the Water Filtration System If the system will not be used for an extended period of time, turn off the shut-off valve on the shut-off valve tube (R), press the power supply button to turn the unit off, then unplug the water filtration system . When the system is turned on again, it will go into automatic flushing mode to clear the filters . -
Page 12: Troubleshooting
Troubleshooting Problem Probable cause Solution The filters are generating a The filters will generate a light noise This is normal . light noise during operation . during operation . • Flush or replace the filter . • The filter is jammed . •... -
Page 13: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Brio Water Filtration System (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship . - Page 14 WWW.BRIOWATER.COM ©2025 Brio Water Technology, Inc.
