- Page 1 Digital Instant Hot Water Dispenser System with 3-Stage Filtration & Dual Flow Faucet User Manual for Model Nos.: CLIHD300CP, CLIHD300BN, CLIHD300BLK, CLIHD300BG, CLIHD300RG, CLIHD300RB...
-
Page 2: Table Of Contents
Table of Contents General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Electrical Safety Information . -
Page 3: General Safety Information
General Safety Information WARNING: To reduce risk of fire, injury, and property damage, you must read this entire manual before installing and operating this instant hot water dispenser system . • This instant hot water dispenser system is NOT intended for commercial use . It MUST be used for domestic purposes only, and only for the purposes for which it was intended . -
Page 4: Installation And Usage Requirements
Installation and Usage Requirements WARNING: Install the instant hot water dispenser according to the following guidelines: Do NOT install the instant hot water dispenser outdoors or in a location where the ambient temperature may • fall below 32 °F (0 °C) otherwise damage to the instant hot water dispenser system and serious injury may occur . -
Page 5: Product Features
Product Features Your package contains three numbered boxes, each containing a component of the dispenser system: 1 . Filtration system; 2 . Boiler tank; 3 . Instant hot water faucet . Open and inspect each box, comparing contents with lists provided below and ensure everything has been included . -
Page 6: Instant Hot Water Boiler, Faucet, And Components
2 . Boxes 2 & 3: Instant Hot Water Boiler, Faucet, and Components Part Description Part Description Hose 1 (T-connect to faucet/boiler) O-ring Hose 2 (T-connect to faucet) Rubber washer Hose 3 (faucet to blue boiler inlet) Metal washer Hose 4 (faucet to red boiler outlet) Fixing nut with screws Power cord Boiling water outlet (red) -
Page 7: Operational Specifications
You must use the instant hot water dispenser system within the following operational parameters to ensure safe, optimal performance . Model Nos . CLIHD300CP, CLIHD300BN, CLIHD300BLK, CLIHD300BG, CLIHD300RG, CLIHD300RB Rated Voltage / Frequency 110–120 V / 60 Hz Rated Power... -
Page 8: Filtation System Installation Overview
2 . Filtration System Installation Overview Part Description Part Description Sediment filter (stage 1) Blue filtration system tube Carbon block filter (stage 2) Hose 1 Post carbon filter (stage 3) Hose 2 Feedwater adapter Hose 3 White inlet water tube Hose 4... -
Page 9: Connect To The Cold Water Supply
3 . Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE . The water supply to the unit MUST be from the COLD WATER LINE . Using HOT WATER will severely damage the filters Turn off the cold water supply valve . -
Page 10: Install The Battery
4 . Install the Battery Lift off the top cover (A) of the filter housing and remove the transparent cover plate (D) . Insert the battery (E) into the indicator panel (C) . The positive side of the battery should be facing outward . -
Page 11: Install Instant Hot Water Faucet
3 . Install Instant Hot Water Faucet NOTE: If you do not have a faucet hole, one will need to be drilled . If you are unsure how to drill a faucet hole, contact the appropriate professional to drill one for you . The hole should be 1-1 . -
Page 12: Connect The Tubes And Hoses
4 . Connect the Tubes and Hoses NOTE: Faucet stems and braided hoses have been identified with a matching number system to facilitate installation . One by one, attach each of the 4 faucet hoses to its matching numbered stem . Carefully tighten to ensure a secure fit for each . -
Page 13: Overview Of Completed Installation
5 . Overview of Completed Installation 6 . Flush the Filters IMPORTANT: Do NOT drink water that is produced during the filter flushing process . Rotate the ambient water handle on the instant hot water faucet open . Slowly turn on the main water supply . Allow water to run from the instant hot water faucet for 10 minutes . -
Page 14: Operation
Operation 1 . Connect Boiler to Power Connect the power cord (5) to the boiler then to the dedicated power socket . Press the power button (24) to turn on the boiler . The boiler will power on and the LED touch panel will illuminate . Using the the up arrow (25), select the desired hot water temperature: 113 °F (45 °C) 131 °F (55 °C) -
Page 15: Irregular Water Production
5 . Irregular Water Production The system is designed to notify you of any irregular water production . If water is continuously dispensed for 30 minutes or more, the filtration unit will beep . To turn off beeping, turn off instant hot water faucet . Care and Maintenance If the instant hot water dispenser system is not going to be used for 2 days or more, power down the boiler to save power . -
Page 16: Replace The Filters
3 . Replace the Filters The filters have a capacity of 1500 gallons, and typically last 3 to 6 months, depending on the level of usage . When the filters reach end of life, the red LED light on the indicator panel will flash and the filtration unit will emit a beep each time you turn on the instant hot water faucet . -
Page 17: Replace The Battery
5 . Replace the Battery To ensure normal operation of the indicator panel, replace the battery every time you replace the filter . Use only a CR2450 battery . Lift off the top cover (A) of the filter housing and remove the transparent cover plate (D) . Remove and properly dispose of the old battery (E) . -
Page 18: Troubleshooting
Troubleshooting Problem Probable Cause Solution • Open the hot water faucet handle and release water . • Adjust the water temperature on the Hot water and/or steam boiler to a lower temperature . is spitting from faucet • Water in tank is boiling . spout . -
Page 19: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Instant Hot Water Dispenser System (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship . - Page 20 WWW.BRIOWATER.COM ©2024 Brio Water Technology, Inc.
