Hypercharger – Configuration manual
Version 1-4
Content
Configuration manual
Hypercharger HYC50 / HYC150 / HYC200 /
HYC300 / HYC400
(50kW – 400kW)
Ultra-fast charging system for electric
vehicles
for SW-Versions 2.3.x
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYC300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpitronic HYC300

  • Page 1 Hypercharger HYC50 / HYC150 / HYC200 / HYC300 / HYC400 (50kW – 400kW) Ultra-fast charging system for electric vehicles for SW-Versions 2.3.x All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 2 Hypercharger – Configuration manual Version 1-4 Content This page was intentionally left blank. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 3: Configuration Manual

    Via di Mezzo ai Piani, 33 39100 Bolzano (BZ) ITALY Tel.: +39 0471 1961 333 Fax: +39 0471 1961 451 Homepage: http://www.alpitronic.it E-Mail: support@hypercharger.it All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 4 Reference to installation and maintenance manual: Hardware relevant information regarding the Hypercharger is found in the dedicated installation and maintenance manuals available on Hyperdoc. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 5: Table Of Contents

    General Settings ....................43 2.4.1. System settings ....................44 2.4.2. Power ......................45 2.4.3. White List NFC ....................46 2.4.4. GUI .........................47 2.4.4.1. GUI Configuration ..................47 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 6 For Local Credit Card sessions ...............75 3.3.2. For Remote (non-local Credit Card) sessions ..........76 4. List of figures ......................... 78 5. List of tables ........................80 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 7: Connection To The Charging Station

    The advantage of this variant is that you don't need to be on the same network to get access. Notice The IPv6 address is to be put in square brackets […]. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 8: Adjustment Of The Network Settings

    Now press the Windows and the "R" key simultaneously to open the dialog shown in the following figure. Enter “ncpa.cpl” in the field and then click OK. Figure 1: Win + R The “Network Connections” window opens. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 9 "Network cable has been removed", "Disabled" or "Network not connected". Now select the network for the Hypercharger, press the right mouse button and open the properties. Figure 2: Network Connection All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 10 Page 10 of 81 Select "Internet Protocol Version 4 (TCP/IPv4)" with a mouse click and then click on "Properties". Figure 3: Network Properties All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 11 Make a note of any settings you change so that you can restore your device to its original settings. "Obtain an IP address automatically" is selected by default. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 12: Remote Access To The Charging Station

    Notice If you encounter problems with the remote access, please align with your IT department, your backend provider or your network provider. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 13: Access Data

    Table 2: Login information for the web interface Notice For security reasons it is important to change the username and password! make these changes the "Password Configuration" menu. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 14: Web Interface Configuration

    In any configuration page, after any change that requires a restart, fields appear in red. Figure 7: Landing page of the web interface All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 15: Network Configuration

    2.1. Network Configuration In the Network menu the following settings can be changed: Ethernet Configuration OpenVPN Preferred Network Figure 8: Network Configuration All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 16: Ethernet Configuration

    If the Ethernet connection is not required to establish a connection to the backend (e.g., because this is implemented via a GSM connection), this setup menu can be ignored. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 17: Ip Addresses Used (Blocked) By The Charger

    LAN network that needs to communicate with the charger - thus, also the default gateway for the charger cannot be one of those IPs. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 18: Sim Configuration

    2.1.2. SIM Configuration The SIM Configuration menu contains the five categories which are presented below. 2.1.2.1. Signal Figure 10: SIM - Signal All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 19 The customer SIM card is in the first SIM slot. The service SIM that is used by Hypercharger support is inserted in the second SIM slot. Figure 11: Location of SIM cards in the Hypercharger All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 20: Apn Configuration

    You can obtain the APN data from your SIM service provider. If authentication is necessary, the data can be entered by selecting the option "APN Authentication Required". All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 21: Provider Selection

    Changing the default setting is only necessary if the auto selection causes issues, e.g., due to poor coverage for a certain connection standard. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 22 By selecting “Scan for Network Providers” a list of all available mobile network providers appears. This allows to select a specific provider and connection standard. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 23 (e.g. after a reboot). All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 24: Default Modem

    This menu is used if the CTRL_COM is exchanged and the built-in modems change. Notice The Default Modem is set during the production process and should not be altered. Figure 17: IMEI number All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 25: Dns

    Via the DNS menu, you have the option of specifying dedicated DNS servers that enable the connection to the backend based on top level domains. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 26: Open Vpn Configuration

    For all Hypercharger software versions < 2.0.0, use OpenVPN version 2.4.3. For all Hypercharger software versions ≥ 2.0.0, use OpenVPN version 2.5.2. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 27: Preferred Network

    "Change Network". Notice The charging station will only attempt to establish a connection with the backend using the channel selected here. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 28: Hypercharger Status

    The following settings are available in the HyperCharger Status menu: Processes View Stop Button Stacks Connectors LoadManagement Software Version Logs Figure 21: HyperCharger Status All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 29: Processes View

    For each process there are the two options “Running” or “Not Running”. Note that the website is updated automatically and has a time stamp. Figure 22: Process View All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 30: Stop Button

    Hypercharger is only reset when it is not in use. To continue using the charger, the stop button has to be manually disengaged. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 31: Stack Status

    Figure 24: Status - Stack Status In this menu the installed Power-Stacks in the Hypercharger are displayed with all relevant information such as voltages, currents and temperatures. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 32: Connectors

    A cycle is counted every time a cable is plugged in- and then out of a car, even if no charging occurred. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 33: Load Management

    In the following are described the most important parameters. For more details, refer to the load management manual which is available on Hyperdoc. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 34: Software Version

    The Software Version menu shows the current version of the binary files running on the charging station. Notice Click on "3 Party Licenses" to see a detailed list of open source licences used. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 35: Logs

    2.2.8. Figure 29: Status – IMD Here you can monitor the isolation values of the insulation monitoring device (IMD). All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 36: Ocpp Configuration

    The parameters that can be adjusted via the web interface or the customer backend can be found in a separate document on our document platform Hyperdoc. 2.3.1. OCPP File Figure 30: OCPP File_1 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 37 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 37 of 81 Figure 31: OCPP File_2 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 38 Figure 32: OCPP File_3 Notice A list of all OCPP configuration keys and error codes can be found in separate documents available on Hyperdoc. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 39: Boot.ini File

    Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 39 of 81 2.3.2. BOOT.INI File Figure 33: OCPP - BOOT.INI File All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 40: Chargeboxserialnumber

    • CON(1) is the first connector – counting from left to right CON(n) is the last connector furthest to the right • All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 41: Chargepointserialnumber

    Card. A full ICCID is 19 or 20 characters. The ICCID can be thought of as the serial number of the SIM Card. It is also considered as Issuers Identification Number. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 42: Imsi

    2.3.2.9. meterType This value represents the type of the main electrical meter of the Charge Point. None reported by Hypercharger Charge Points. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 43: General Settings

    The following setting are available in the general settings menu: WhiteList NFC Power GUI (Graphical User Interface) Software Update Configure Stacks Figure 34: General Settings All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 44: System Settings

    TimeZone: all schedule times are based on the specified time zone. Valid values are those accepted by the POSIX TZ environment variable. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 45: Power

    On this menu you can also configure in which period of time the charger is in silent mode to reduce the noise. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 46: White List Nfc

    The third allows the addition of new NFC tags by entering the ID directly into the text box The last part allows to delete the entire list of NFC cards stored on the charging station All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 47: Gui

    The simultaneous configuration of multiple charging stations is only possible via OCPP backend. 2.4.4.1. GUI Configuration Figure 38: General - GUI – Configuration All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 48 3 for more details. GUI Colors: Allows the user to select an RGB scale color in which text and icons are displayed on the GUI. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 49 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 49 of 81 Figure 39: Language selection All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 50: Ui Customization

    The UI customization section allows you to personalize the user experience by uploading custom images. Figure 40: General - GUI - UI customization All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 51 "otherChargerInfoRemote_fg.png" or "otherChargerInfoRemote_bg.png" PNG format 1366 x 768 pixels (for HYC150, HYC200, HYC300, HYC400) 800 x 1280 pixels (for HYC50) RGBA colors All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 52 (“Logo.png”, “Authenticate.png”) are no longer supported. All custom images can also be transparent, allowing for the definition of multiple levels of customization. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 53: Slide Show

    Figure 42: General - GUI - Slide Show For the Slide Show mode, there is no limit to the number of images that can be displayed alternately. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 54 For this reason, the upper part of the display with a height of 46 pixels should be left blank on these models. Please take this into account when designing your graphics. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 55 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 55 of 81 Figure 43: Different possible layers Figure 44: Merged display elements All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 56: Creditcard Terminal

    Please refer to the single configuration instructions for the supported credit card terminals available on Hyperdoc. Figure 45: General – CreditCard Terminal – Status and Commands All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 57 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 57 of 81 Figure 46: General – CreditCard Terminal – Terminal Config All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 58 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 58 of 81 Figure 47: General – CreditCard Terminal – Tariff Config All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 59 Hypercharger - Configuration manual Version 1-4 2 Web interface configuration Page 59 of 81 Figure 48: General – CreditCard Terminal – Transactions DB All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 60: Giro-E

    Notice This functionality has to be supported by the customer backend. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 61: Configure Stacks

    Figure 51. Confirm your settings with "Change Stack Configuration". All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 62 Figure 51: Change of the stack configuration Notice The order of the stacks is shown in the figure next to the settings. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 63: Software Update

    Hypercharger. If no warranty extension is active for the period after that, you have the option of purchasing software upgrade packages separately. You can send a request to sales@hypercharger.it. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 64: Software Rollback

    The Software RollBack menu allows you reverting to a previous software version. Notice Please contact the support before doing this operation. 2.5. Password Configuration Figure 54: Password Configuration All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 65: Reset Hypercharger

    Before resetting, make sure that no vehicles are connected to the charging station! All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 66: Overview Of Connectors

    By clicking on "Click to Expand" the user gets to the detailed view. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 67 If you have questions or if you encounter any problems, please do not hesitate to contact our Hypercharger support team: support@hypercharger.it or +39 0471 1961 333 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 68: Ocpp Parameters Affecting Behaviour Of Ui

    This parameter controls the visibility of the chargepoint ID. If it’s set to true, a text label with the value will be shown as an overlay on the top left corner on all pages. Figure 58: Chargepoint ID All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 69 MMMM The long month name ('January' to 'December'). yy The year as a two digit number (00 to 99) yyyy The year as a four digit number. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 70 Error FF0000 – Controls color of error messages in the Pure red Unplug page and specific error icons Table 6: GUI Colors All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 71 FAULTED: Is the color used when there is a fault in the system and the • connector is not available for charging. RESERVED: Is the color used when a connector is reserved for charging • All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 72: Parameters Affecting The User Flow Of The Ui

    “AuthModes” Page of the GUI. When the user selects a connector and is not yet authenticated, this page will appear with the available authentication methods and the respective instructions. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 73: Display Of Qr Codes

    Will be replaced with the session id generated locally by the system. This is an UUID <chargePointIdentity> Will be replaced with the chargePointIdentity parameter value Table 8: QR Code place holders All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 74 Upon the setting of the Live View QR code via GUIChargingQRCode and/or HyperchargerLiveViewEnabled keys, the activation of the LiveView (from http://live.hypercharger.it/<sessionID> ) needs to be requested and approved by Alpitronic. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 75: Ocpp Parameters That Affect Tariff And Cost Display

    This parameter is used in the Receipt page to show the URL where the receipt of a credit card session can be downloaded. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 76: For Remote (Non-Local Credit Card) Sessions

    PriceTextOffline Alternative text for display pricing message when charge point is offline. Figure 62: The default price is shown before user authentication All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 77 Whether or not QR code customisation of the transaction end event is enabled as per OCPP California 2.0.1. DefaultPriceMessageSources List of enabled message sources for the OCPP 2.0.1 California default price message. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 78: List Of Figures

    Figure 50: General - Configure Stacks ................61 Figure 51: Change of the stack configuration ..............62 Figure 52: General - Software Update ................63 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 79 Figure 58: Chargepoint ID ....................68 Figure 59: Example of different GUI colors ...............71 Figure 60: Auth Modes page .....................73 Figure 61: Example for QR Code ..................74 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 80: List Of Tables

    Table 5: Supported custom images ...................51 Table 6: GUI Colors ......................70 Table 7: Holder colors .......................71 Table 8: QR Code place holders ..................73 All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
  • Page 81 Hypercharger - Configuration manual Version 1-4 Page 81 of 81 This page was intentionally left blank. All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by Alpitronic Srl...
