Thank you for purchasing PLANET CAM-PT, Pan / Tilt dome cameras for integration/expansion of your
surveillance network.
This installation guide is written for CAM-PT version 2 machine. CAM-PT version 1 machine users
please find the installation guide on our server ftp://ftp.planet.com.tw/Internet_Camera/CAM-PT/v1/
Package content
Pan / Tilt dome camera
Mounting plate
Power Cord
Quick Installation Guide
Please check the package content, and contact our local distributor if any of the shipping packages is
missing.
Product features
·
High quality 1/3 inch color CCD
·
Up to 32 preset points can be setup via remote controller (CAM-PT-CTRL)
·
Horizontal rotation range 0 ~ 325 degrees; vertical rotation range 10 ~ 90 degrees.
·
Up to 31 PT Dome Cameras can be connected as a surveillance chain when using the Remote
Controller (CAM-PT-CTRL)
·
Auto White Balance (AWB), Backlight Compensation (BLC) and Auto Gain Control (AGC)
features offer clear, vivid image for surveillance.
·
Ease-of-integration via RS-485 standard interface
In this provided documentation, we'll introduce how to install CAM-PT in the following steps.
CAM-PT usage:
1. Nail the mounting plate onto a solid surface in the installation site
2. Position the CAM-PT to the mounting plate, and clockwise rotate the camera to securely attach to
the plate.
3. Carefully connect BNC connector to the video output of camera.
4. Connect the power supply to the camera
5. Adjust the view of camera, and check the video output on the monitor.
Note:
When installing multiple units in the same site, it is required to setup the camera ID first before
installation to prevent camera ID conflict.
PLANET CAM-PT
Quick Installation Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Planet CAM-PT
Summary of Contents for Planet CAM-PT
- Page 1 CAM-PT usage: 1. Nail the mounting plate onto a solid surface in the installation site 2. Position the CAM-PT to the mounting plate, and clockwise rotate the camera to securely attach to the plate. 3. Carefully connect BNC connector to the video output of camera.
- Page 2 · Alarm input/ Output Each CAM-PT is equipped with 1 external alarm input (blue & black color) and 1 alarm output (brown & orange color). Note: Normal Open (NO) and Normal Close (NC) can be selected in the camera DIP switch. The alarm I/O interface in CAM-PT can be used as On/Off switch in different surveillance applications.
- Page 3 ID and reboot camera to make the settings effective. Note: DIP 6~8 are for transmission code and the alarm mode setup. CAM-PT Transmission code / Alarm mode setup P/T Dome camera may choose 3 kinds transmissions code of 3 kinds different protocol.
- Page 4 Use the twisted pair wire to connect IR receiver to CAM-PT RS485 cable. Connect the RS-485 serial port (D +) from the IR Receiver to the CAM-PT camera RS-485 serial port (D +). Same as above procedure to connect the RS-485 serial port (D -) from the IR receiver, to the CAM-PT RS-485 serial port (D -). Note: Two sets of D + &...
-
Page 5: Alarm Input
‘level 1’). Executing Auto Pan function The CAM-PT has 32 preset points and are grouped into 4 Auto Pan groups (1-8 is group 1; 9-16 is group 2; 17-24 is group 3; 25-32 is group 4). Pressing the group number (1~4) then “AutoPan” key. The CAM-PT will execute the Auto Pan function. - Page 6 In the meanwhile, controlling power will automatically switch to alarm output device without manually switching. When alarm is triggered, the CAM-PT will issue RELAY (NO). You may press Event RST key to stop issuing RELAY When alarm is triggered, the CAM-PT will issue signal to IR receiver. On receiving the signal, the buzzer of remote control receiver will start to beep.
- Page 7 Vertical Rotation Range 10° ~ 90° Auto Pan Range 0°~ 325° Alarm Input NC / NO (Normal Close/Normal Open) Alarm Output NO (contact rating, 3A@125VAC / 30VDC) Dimension (mm) 120 (W) x 120 (D) x 116.5 (H) PLANET Technology Corp.
