PRODUCT NAME: Tilde Sideboard Soft Blue
ITEM NUMBER: SF085 SBL
ASSEMBLED DIMENSIONS : 34.5"H x 65"W x 19"D
Doors are factory leveled and aligned.
However, if adjustments are required refer to PAGE 3
for detailed instructions regarding door hinges.
TO REMOVE DRAWERS
Fully extend drawer. Metal glides on bottom.
Push in white tabs. Pull drawer out.
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 5-10-2024
Hardware packet attached to Sideboard underside.
Cleaning and Care
Periodically dust surface once or twice a week with a soft cloth.
Gently wash surface with mild soap, micorfiber cloth or soft towel.
Do not use harsh chemicals, abrasives or polishers.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
REQUIRED TOOLS:
- Phillips Screwdriver
-Two person assembly required.
ASSEMBLY TIME: 5 -10 minutes
ASSEMBLED WEIGHT: 237 lbs.
Qty.
Hardware Included
Ltr.
A
8
B
2
Qty.
Components
Ltr.
C
4
D
1
E
2
F
1
Shelf Supports
(30mm x 13mm x 16mm)
Wall Anchoring
(Anti-tip) Kits
See Page 4
Legs (C)
Center Leg (D)
Shelves (E)
Sideboard (F)
MADE IN VIETNAM
Page 1 of 4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ballard Designs Tilde SF085 SBL
Summary of Contents for Ballard Designs Tilde SF085 SBL
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Tilde Sideboard Soft Blue REQUIRED TOOLS: ITEM NUMBER: SF085 SBL - Phillips Screwdriver ASSEMBLED DIMENSIONS : 34.5”H x 65”W x 19”D -Two person assembly required. ASSEMBLY TIME: 5 -10 minutes ASSEMBLED WEIGHT: 237 lbs. Qty.
- Page 2 Assemble in location for intended use. ASSEMBLY: Place Sideboard (F) upside down onto a padded, level surface. Complete STEP 1. Turn upright and complete STEP 2. Insert, turn and tighten each Leg (C) into place as illustrated. Insert, turn and tighten Center Leg (D) as illustrated.
- Page 3 Retain this page for future reference. Adjusting Door Alignment Doors shoud arrive level and aligned, however, if adjustment is necessary follow these instructions to correct any issues. MOVE DOOR To Correct Vertical Alignment: Loosen Screw (A) then turn Screw (B) clock- wise/counterclockwise to adjust door.
- Page 4 WALL ANCHORING HARDWARE (ANTI-TIP) Ltr. Qty. Hardware Included Large Screw Small Screw WARNING Tip-Over Hazard Bracket Serious or fatal crushing injuries can occur from a furniture tip-over Prevent tipping accidents. Anchor your furniture. Retention Belt Installation: 1. Place furniture against wall at desired location then locate and mark a Wall Stud behind unit. 2.
