INTENDED FOR USE BY PROFESSIONAL EQUIPMENT OPERATORS
OPERATING
INSTRUCTIONS
READ AND UNDERSTAND BEFORE
OPERATING THIS EQUIPMENT
APPLICABLE TO SERIAL NUMBERS 20230630
AND LATER. FOR EARLIER NUMBERS,
SEARCH WPG'S ARCHIVE.
POWER TILTER 1500,
AIR POWERED
Model numbers: PT1010TAIR (shown),
PT1010TAIRO, PT1410TAIRO
Original Instructions © Wood's Powr-Grip Co., Inc.
Rev 18.0/11-23
1
908 W. Main • P.O. Box 368
Laurel, MT USA 59044
800-548-7341
406-628-8231
www.WPG.com
PT-10TAIR: #35143
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WPG POWER TILTER 1500
Summary of Contents for WPG POWER TILTER 1500
- Page 1 READ AND UNDERSTAND BEFORE OPERATING THIS EQUIPMENT APPLICABLE TO SERIAL NUMBERS 20230630 AND LATER. FOR EARLIER NUMBERS, SEARCH WPG’S ARCHIVE. POWER TILTER 1500, AIR POWERED Model numbers: PT1010TAIR (shown), PT1010TAIRO, PT1410TAIRO Original Instructions © Wood’s Powr-Grip Co., Inc. Rev 18.0/11-23...
- Page 2 PT-10TAIR: #35143 Rev 18.0/11-23...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ..................3 SAFETY....................5 OPERATING FEATURES................6 ASSEMBLY....................7 ..........10 NSTALL THE ONTROL ANDLE XTENSIONS INTENDED USE ..................11 ................11 HARACTERISTICS ..................12 NDIRECT OADING ................12 PERATING NVIRONMENT ................12 ISPOSAL OF THE IFTER OPERATION..................13 ................13 EFORE SING THE IFTER Taking Safety Precautions ....................13 Performing Inspections and Tests ..................13 .................14 SE THE... - Page 4 Pad-to-Load Friction Coefficient ..................26 Pad Inspection ........................26 Pad Cleaning ........................27 VPFS10T P ..........28 EPLACE EALING ING IN REPLACEMENT PARTS................29 REGISTRATION AND LIMITED WARRANTY ..........30 WPG P ...............30 EGISTER THIS RODUCT ..............30 BOUT THE IMITED ARRANTY Obtaining Warranty Service or Repair Service..............30 PT-10TAIR: #35143...
-
Page 5: Specifications
“Rated Load Test”). 2..For PT1410TAIR lifters, calculated lifting capacities cannot exceed Maximum Load Capacity. 3..Available with other rubber compounds for special purposes (see www.wpg.com). 4..Standard with replaceable sealing rings for rough or textured surfaces (see “REPLACEMENT PARTS”). - Page 6 SPECIFICATIONS Note: A standard PT1010TAIR is shown at top; a PT1010TAIRO (with pad frame option) is shown at center; a standard PT1410TAIRO (with Control Handle Extension) is shown at bottom. PT-10TAIR: #35143 Rev 18.0/11-23...
-
Page 7: Safety
SAFETY Wear personal protective equipment Make sure the contact surfaces of the that is appropriate for the load load and vacuum pads are clean material. Follow trade association before attaching the lifter (see guidelines. “MAINTENANCE”). Do not remove or obscure safety Position the vacuum pads correctly on labels. -
Page 8: Operating Features
OPERATING FEATURES Features shown here are underlined on their first appearance in each section following. LIFT BAR VACUUM RESERVE TANK LIFT POINT TILT SPEED VALVE TILT ACTUATOR VACUUM PAD PAD SHUTOFF CONTROL HANDLE PAD FRAME 10 VACUUM PUMP (venturi) 11 VACUUM CONTROL VALVE 12 AIR FILTER —... -
Page 9: Assembly
ASSEMBLY 1) Remove all shipping materials and save them with the shipping container for future use. 2) Select a crane and/or hoist rated for the Maximum Load Capacity plus the Lifter Weight. Note: Any lifter use must comply with all statutory or regulatory standards for hoisting equipment in your region. - Page 10 ASSEMBLY 7) Connect the lifter to an appropriate compressed air supply (see Power Source under “SPECIFICATIONS”): Note: Qualified service personnel should This installation should be performed install the female quick connector by qualified service personnel. (supplied) on the compressed air line. Caution: Make sure the air line is routed so that it does not become tangled or damaged during operation.
- Page 11 ASSEMBLY 7.4) Adjust the air pressure regulator to supply 80 psi [550 kPa]: Pull up the adjustment collar on top of the regulator. Turn the collar clockwise to increase pressure or counter-clockwise to decrease pressure (fig. 7E). When the pressure gauge registers a minimum air pressure of 80 psi [550 kPa], push down the collar to lock it in place.
-
Page 12: Nstall The Ontrol Andle Xtensions
ASSEMBLY NSTALL THE ONTROL ANDLE XTENSIONS When applicable, install the Control Handle Extensions using the parts supplied: RIGHT CONTROL HANDLE EXTENSION 1/4-20 X 3/4" HEXHEAD SCREW 1/4" SPLIT LOCK WASHER 1/4" SAE FLAT WASHER CONTROL HANDLE EXTENSION CONNECTOR LEFT CONTROL HANDLE EXTENSION 3/8-16 X 4"... -
Page 13: Intended Use
2..A “single piece” of material includes curtainwall assemblies, unitized glazing systems and similar construction units. 3..Vacuum pads made from a heat-resistant rubber compound can enable you to lift loads with higher surface temperatures. Contact WPG or an authorized dealer for more information. -
Page 14: Indirect Loading
1..Although lifter use may be possible at higher elevation, lifting capacity is reduced whenever the lifter is unable to attain vacuum in the green range on the vacuum gauge. Contact WPG for more information. 2..Special provisions may allow the lifter to operate outside the specified temperature range. Contact WPG for more information. PT-10TAIR: #35143... -
Page 15: Operation
OPERATION EFORE SING THE IFTER Determine whether the vacuum lifter is capable of each intended task (see “SPECIFICATIONS” “INTENDED USE”). Then complete the following preparations: Taking Safety Precautions • Be trained in all industry Read all directions and safety rules before using and regulatory standards lifter. -
Page 16: T O Use The Pad Shutoffs
OPERATION SE THE HUTOFFS Each pad shutoff on the pad frame controls the vacuum line to the adjacent vacuum pad. Activating or deactivating the airflow at specific pads enables the lifter to handle loads with different weights and dimensions (see “SPECIFICATIONS”) or to avoid holes in the load surface. To support the maximum load weight and larger load Closing any pad shutoff dimensions, all pads must be activated;... -
Page 17: T O Attach The Pads To A Load
OPERATION TTACH THE ADS TO A Generating Airflow Make sure the lever on the vacuum control valve is in stand-by mode: Simultaneously press the button (fig. 1A) and turn the lever to the center position. (fig. 1B). Place the air supply valve in the “on” position ( —... -
Page 18: Sealing The Pads On The Load
2..Although a vacuum pad may become distorted during shipping or storage, this condition should correct itself with continued use. 3..If the lifter is used above the maximum Operating Elevation (see “SPECIFICATIONS”), it may not be able to maintain sufficient vacuum for lifting. Contact WPG for more information. PT-10TAIR: #35143... -
Page 19: Ift And Ove The Oad
OPERATION IFT AND OVE THE Lift bar must be vertical to lift load. Interpreting the Vacuum Gauge Vacuum is sufficient Never lift load unless vacuum gauge registers in the to lift the Maximum green range, because premature lifting could result in Load Capacity whenever the load release and personal injury. -
Page 20: Controlling The Lifter And Load
OPERATION Controlling the Lifter and Load When the lifter is ready, use the hoisting equipment to raise the lifter and load as needed. Use a control handle (circled in fig. 1A) to keep the lifter and load in the required position. Once there is enough clearance, you may move the load as required. -
Page 21: T O Tilt The Load
OPERATION ILT THE Make sure load is positioned correctly on lifter (as previously directed). Caution: Unbalanced loads can interfere with the lifter’s tilt capability. 1) Make sure the load has enough clearance to tilt without contacting anyone or anything. 2) Use the tilt control valve to tilt the load as required: •... -
Page 22: T O Release The Pads From The Load
OPERATION ELEASE THE ADS FROM THE Make sure load is at rest and fully supported before releasing vacuum pads. Move the lever on the vacuum control valve to the “release” position ( ): Simultaneously press the control valve’s button and turn the lever clockwise (fig. -
Page 23: After Using The Lifter
OPERATION FTER SING THE IFTER 1) Place the air supply valve in the “off” position ( ). 2) Use the hoisting equipment to lower the vacuum lifter gently onto a stable support. Then detach the hoisting hook from the lift point. Caution: Do not set lifter on surfaces that could soil or damage vacuum pads. -
Page 24: Inspections And Tests
2..The Periodic Inspection is also required whenever the lifter has been out of service for 1 year or more. Keep a written record of all Periodic Inspections. If necessary, return the lifter to WPG or an authorized dealer for repair (see “REGISTRATION AND LIMITED... -
Page 25: Testing
12" Hg [-41 kPa] for 5 minutes. If not, lifting this load requires additional precautions (eg, a load sling). Contact WPG for more information. 8) Lower the load after 5 minutes or before the vacuum level diminishes to 12" Hg [-41 kPa]. -
Page 26: Operational Tests
INSPECTIONS AND TESTS Perform the following tests before placing the lifter in service initially, following any repair, when directed in the “I ”, or whenever necessary: NSPECTION CHEDULE Operational Tests Test all features and functions of the lifter (see “OPERATING FEATURES” and “OPERATION”). Vacuum Test 1) Clean the faces of the vacuum pads (see “Pad... -
Page 27: Rated Load Test
7) Prepare a written report of the test and keep it on file. 1..An equivalent simulation may also be used. Contact WPG for more information. 2..A “qualified person” has successfully demonstrated the ability to solve problems relating to the subject matter and work, either by possessing a recognized degree in an applicable field or a certificate of professional standing, or by possessing extensive knowledge, training and experience. -
Page 28: Maintenance
MAINTENANCE Note: Refer to SERVICE MANUAL #36112 when applicable. ACUUM AINTENANCE Pad-to-Load Friction Coefficient The friction coefficient represents the lifter's ability to resist load slippage. The Maximum Load Capacity assumes a friction coefficient of 1, based on testing of clean, new, standard rubber vacuum pads on clean, dry, regular glass. -
Page 29: Pad Cleaning
4) Allow the pad to dry completely before using the lifter. 1..A brush with bristles that do not harm rubber can help remove contaminates clinging to sealing edges. If these cleaning methods are not successful, contact WPG or an authorized dealer for assistance. Rev 18.0/11-23... -
Page 30: T O Replace Sealing Ring In Vpfs10T Pads
MAINTENANCE VPFS10T P EPLACE EALING ING IN If the lifter has VPFS10T vacuum pads, replace sealing rings (#49724RT or #49724TT) as follows: 1) Remove the old sealing ring (fig. 1A). Note: Make sure the entire vacuum pad is clean, including the mounting groove. -
Page 31: Replacement Parts
Shoulder Bolt – Socket Head – 5/16" x 1/2" x 1/4-20 Thread (for mounting pads) 60 / 84 * Length as required; sold by the inch (approx 2.5 cm). SERVICE MANUAL #36112 for additional parts. ERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS WPG.COM AVAILABLE AT OR THROUGH AN AUTHORIZED DEALER Rev 18.0/11-23 PT-10TAIR: #35143... -
Page 32: Registration And Limited Warranty
PRODUCT REGISTRATION page at wpg.com and complete the form. Registration keeps you advised of important updates and notifications, and simplifies inquiries to WPG regarding your product. Registration is not required to activate your Limited Warranty (see next section). BOUT THE... - Page 33 Rev 18.0/11-23 PT-10TAIR: #35143...
- Page 34 PT-10TAIR: #35143 Rev 18.0/11-23...
