KEEP FOR FUTURE REFERENCE
OPERATING
INSTRUCTIONS
INTENDED FOR USE BY SKILLED
PROFESSIONALS • READ AND
UNDERSTAND BEFORE OPERATING
MANUAL ROTATOR /
POWER TILTER,
HIGH-DUTY VERSION,
AC-VOLTAGE
Model numbers: MRPTHD89AC,
MRPTHD1211LAC (shown), MRPTHD2011LAC
Record serial number in blank space above (to locate, see serial
Rev 1.0/2-21
label on the product).
1
908 W. Main • P.O. Box 368
Laurel, MT USA 59044
800-548-7341 (phone)
406-628-8231 (phone)
406-628-8354 (fax)
www.WPG.com
MRPTHD-AC: #35066

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRPTHD89AC and is the answer not in the manual?

Questions and answers

Summary of Contents for WPG MRPTHD89AC

  • Page 1 PROFESSIONALS • READ AND UNDERSTAND BEFORE OPERATING MANUAL ROTATOR / POWER TILTER, HIGH-DUTY VERSION, AC-VOLTAGE Model numbers: MRPTHD89AC, MRPTHD1211LAC (shown), MRPTHD2011LAC Record serial number in blank space above (to locate, see serial Rev 1.0/2-21 MRPTHD-AC: #35066 label on the product).
  • Page 2 MRPTHD-AC: #35066 Rev 1.0/2-21...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS ..................3 SAFETY....................6 OPERATING FEATURES................7 ASSEMBLY....................8 ..........10 HANGE THE RAME ONFIGURATION Removing Parking Stands....................11 Extending/Retracting Telescoping Pad Arms ..............12 Connecting/Disconnecting Vacuum Hoses ...............13 INTENDED USE ..................14 ................14 HARACTERISTICS ................15 PERATING NVIRONMENT ................15 ISPOSAL OF THE IFTER OPERATION..................16 ................16 EFORE SING THE...
  • Page 4 TABLE OF CONTENTS ................25 NSPECTION CHEDULE ....................26 ESTING Lifter/Load Compatibility Test...................26 Operational Tests ......................27 Vacuum Test........................27 Rated Load Test.........................28 MAINTENANCE ..................29 ...............29 ACUUM AINTENANCE Pad-to-Load Friction Coefficient ..................29 Pad Inspection ........................29 Pad Cleaning ........................30 REPLACEMENT PARTS................31 LIMITED WARRANTY ................32 ...........32 BTAIN EPAIRS OR ARRANTY...
  • Page 5: Specifications

    BTH-1 1..Available with other rubber compounds for special purposes (see www.wpg.com). 2..These dimensions reflect pad configurations with the Maximum Load Capacity; other configurations are possible for lighter loads. 3..The Maximum Load Capacity is rated at a vacuum of 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces with a friction coefficient of 1. Pad compound, load rigidity, strength, surface conditions, overhang, angle, center of gravity and temperature can also affect the lifting capacity.
  • Page 6 SPECIFICATIONS Note: Standard MRPTHD89AC (top) and MRPTHD1211LAC (bottom) are shown. MRPTHD-AC: #35066 Rev 1.0/2-21...
  • Page 7 SPECIFICATIONS Note: Standard MRPTHD2011LAC is shown. Rev 1.0/2-21 MRPTHD-AC: #35066...
  • Page 8: Safety

    SAFETY Wear personal protective Make sure the contact surfaces of equipment that is appropriate for the load and vacuum pad are clean the load material. Follow trade before attaching the lifter (see association guidelines. “MAINTENANCE”). Do not remove or obscure safety Position the vacuum pads correctly labels.
  • Page 9: Operating Features

    OPERATING FEATURES Features shown here are underlined on their first appearance in each section following. VACUUM RESERVE TANK VACUUM PUMP Enclosure w/VACUUM SWITCH VACUUM GAUGE VACUUM LIFT LIGHT PAD FRAME VACUUM PAD w/ MOVABLE TELESCOPING PAD ARM QUICK CONNECTOR PAD MOUNT 10 POWER SWITCH 11 HOIST PENDANT HOLDER 12 AIR FILTER...
  • Page 10: Assembly

    ASSEMBLY 1) Remove all shipping materials and save them with the shipping container for future use. Connect the power cable: Make sure power source has ground fault circuit interrupter. 2.1) Wire the female connector provided to Wiring must be done by an appropriate power source, as qualified personnel, taking all indicated on the label attached.
  • Page 11 ASSEMBLY 4) Suspend the lifter from appropriate hoisting equipment: 4.1) Select a crane and/or hoist rated for the Maximum Load Capacity plus the Lifter Weight. Note: Any lifter use must comply with all statutory or regulatory standards for hoisting equipment in your region. 4.2) Attach the hoisting hook to the lift point (fig.
  • Page 12: T O Change The Pad Frame Configuration

    ASSEMBLY HANGE THE RAME ONFIGURATION If the lifter has an adjustable pad frame, various configurations enable it to match different load dimensions: MRPTHD1211LAC MRPTHD2011LAC 1) Choose a configuration to maximize support across the load surface and to minimize load overhang (see “L ”...
  • Page 13: Removing Parking Stands

    ASSEMBLY 2) Reposition telescoping pad arms and reposition or remove movable pad mounts as needed (see following sections): • To support the maximum load Route vacuum hoses as needed to prevent weight, you must install all damage to them during lifter operation. vacuum pads on the pad frame and connect all vacuum hoses to the pads (see following sections).
  • Page 14: Extending/Retracting Telescoping Pad Arms

    ASSEMBLY Extending/Retracting Telescoping Pad Arms Remove the cotterless hitch pin and slide a telescoping pad arm into or out of the pad frame until the hitch pin holes align at the desired position (fig. 1B). 2) Reinsert the pin to secure the telescoping pad arm (fig. 2B). 3) Repeat steps 1-2 to reposition other telescoping pad arms, as needed.
  • Page 15: Connecting/Disconnecting Vacuum Hoses

    ASSEMBLY Connecting/Disconnecting Vacuum Hoses Make sure quick connectors seal completely and all vacuum hoses function correctly (see “Vacuum Test” on page 27). To connect a vacuum hose, push the male and female ends of the quick connector together until they lock (fig. 1B). To disconnect a vacuum hose, move the release ring on the female end until the quick connector separates (fig.
  • Page 16: Intended Use

    2..A “single piece” of material includes curtainwall assemblies, unitized glazing systems and similar construction units. 3..Vacuum pads made from a heat-resistant rubber compound can enable you to lift loads with higher surface temperatures. Contact WPG or an authorized dealer for more information.
  • Page 17: Operating Environment

    1..Although lifter use may be possible at higher elevation, lifting capacity is reduced whenever the lifter is unable to attain vacuum in the green range on the vacuum gauge. Contact WPG for more information. 2..Special provisions may allow the lifter to operate outside the specified temperature range. Contact WPG for more information. Rev 1.0/2-21...
  • Page 18: Operation

    OPERATION EFORE SING THE IFTER Determine whether the vacuum lifter is capable of each intended task (see “SPECIFICATIONS” on page 3 and “INTENDED USE” on page 14). Then complete the following preparations: Taking Safety Precautions • Be trained in all industry Read all directions and safety rules before using and regulatory standards lifter.
  • Page 19: Ttach The Ads To Aoad

    OPERATION TTACH THE ADS TO A Generating Airflow Place the power switch in the “on” position ( ), to engage the vacuum pump. Keep pump running throughout lift. The lifter is designed for the vacuum pump to run continuously. Placing the power switch in the “off” position ( ) during lifter operation could result in a load release and personal injury (see “In Case of a Power Failure”...
  • Page 20: Reading The Vacuum Gauge

    1..Although a vacuum pad may become distorted during shipping or storage, this condition should correct itself with continued use. 2..If the lifter is used above the maximum Operating Elevation (see “SPECIFICATIONS” on page 3), it may not be able to maintain sufficient vacuum for lifting. Contact WPG for more information. MRPTHD-AC: #35066...
  • Page 21: Ift And Ove The Oad

    OPERATION IFT AND OVE THE Lift bar must be vertical to lift load. Interpreting the Lift Light When the vacuum lifter has Never lift load unless lift light is sufficient vacuum to lift the illuminated, because premature lifting Maximum Load Capacity, the vacuum lift could result in load release and personal injury.
  • Page 22: In Case Of A Power Failure

    OPERATION In Case of a Power Failure A vacuum reserve tank helps maintain vacuum temporarily in the event of a power failure. Although the lifter is designed to support the load for at least 5 minutes without power, this depends on many factors, including the “L ”...
  • Page 23: T O Rotate The Load

    OPERATION OTATE THE Make sure load is positioned correctly on lifter (as previously directed). 1) Make sure the load has enough clearance to rotate without contacting anyone or anything. Keep hands and fingers away from pinch points between pad frame and lift bar. Keep the load under control at all times, using control lines, hand cups or...
  • Page 24: T O Tilt The Load

    OPERATION ILT THE Make sure load is positioned correctly on lifter (as previously directed). 1) Make sure the load has enough clearance to tilt without contacting anyone or anything. Move the toggle switch on the movable control pendant up or down (fig.
  • Page 25: T O Release The Pads From The Load

    OPERATION ELEASE THE ADS FROM THE Make sure load is at rest and fully supported before releasing vacuum pads. Push the vacuum release button ( — circled in fig. 1A) on the movable control pendant, to break the vacuum seal. Do not move lifter until pads release completely, because such movement could result in load damage or personal injury.
  • Page 26: Storing The Lifter

    OPERATION 3) Use the hoisting equipment to lower the vacuum lifter gently onto a stable support. Then detach the hoisting hook from the lift point. Storing the Lifter Unplug the power cord (see “ASSEMBLY” on page 8). 2) Use the covers supplied to keep the vacuum pads clean (fig. 1A). !!–CE–!! To prevent the lifter from tipping over on relatively horizontal surfaces, use the parking stands as previously described, if the lifter has...
  • Page 27: Inspections And Tests

    2..The Periodic Inspection is also required whenever the lifter has been out of service for 1 year or more. Keep a written record of all Periodic Inspections. If necessary, return the lifter to WPG or an authorized dealer for repair (see “LIMITED WARRANTY”...
  • Page 28: Testing

    12" Hg [-41 kPa] for 5 minutes. If not, lifting this load requires additional precautions (eg, a load sling). Contact WPG for more information. 8) Lower the load after 5 minutes or before the vacuum level diminishes to 12" Hg [-41 kPa].
  • Page 29: Operational Tests

    1..The load surface should have either a flat surface or no more curvature than the lifter is designed for (if any). 2..For more information, search for your lifter’s Model Number at www.wpg.com and select the “Troubleshooting” link on the product page.
  • Page 30: Rated Load Test

    7) Prepare a written report of the test and keep it on file. 1..An equivalent simulation may also be used. Contact WPG for more information. 2..A “qualified person” has successfully demonstrated the ability to solve problems relating to the subject matter and work, either by possessing a recognized degree in an applicable field or a certificate of professional standing, or by possessing extensive knowledge, training and experience.
  • Page 31: Maintenance

    MAINTENANCE Note: Refer to SERVICE MANUAL #35277 when applicable. ACUUM AINTENANCE Pad-to-Load Friction Coefficient The friction coefficient represents the lifter's ability to resist load slippage. The Maximum Load Capacity is based on a friction coefficient of 1, as determined by testing of clean, new, standard rubber vacuum pads on clean, dry, regular glass.
  • Page 32: Pad Cleaning

    4) Allow each pad to dry completely before using the lifter. 1..A brush with bristles that do not harm rubber can help remove contaminates clinging to sealing edges. If these cleaning methods are not successful, contact WPG or an authorized dealer for assistance. MRPTHD-AC: #35066...
  • Page 33: Replacement Parts

    53132 1/3/3 Pad Fitting ‒ Elbow ‒ 5/32" ID 53122 8/12/20 Vacuum Pad ‒ Model VPFS9 / 9" [23 cm] Diameter (for MRPTHD89AC) 49506TA Vacuum Pad ‒ Model G3370 / 11" [28 cm] Diameter ‒ Lipped (for MRPTHD12/2011LAC) 49646T 12/20 End Plug ‒...
  • Page 34: Limited Warranty

    Contact the WPG Technical Service Department. When factory service is required, ship the complete product – prepaid – along with your name, address and phone number to the street address listed at the bottom of this page. WPG may be reached by phone or fax numbers listed below.
  • Page 35 MRPTHD-AC: #35066 Rev 1.0/2-21...
  • Page 36 Rev 1.0/2-21 MRPTHD-AC: #35066...
  • Page 37 MRPTHD-AC: #35066 Rev 1.0/2-21...
  • Page 38 Rev 1.0/2-21 MRPTHD-AC: #35066...
  • Page 39 MRPTHD-AC: #35066 Rev 1.0/2-21...
  • Page 40 Rev 1.0/2-21 MRPTHD-AC: #35066...
  • Page 41 MRPTHD-AC: #35066 Rev 1.0/2-21...
