  6. Operating instructions manual

WPG FLEXR Series Operating Instructions Manual

Flat lifter, air-powered
Hide thumbs Also See for FLEXR Series:
Table of Contents

Advertisement

Quick Links

Download this manual
KEEP FOR FUTURE REFERENCE
OPERATING
INSTRUCTIONS
INTENDED FOR USE BY SKILLED
PROFESSIONALS • READ AND
UNDERSTAND BEFORE OPERATING
FLEXR(L) SERIES
FLAT LIFTER,
AIR-POWERED
Model numbers: FLEXR4HV11AIR,
FLEXR6HV11AIR, FLEXRL6HV11AIR (shown)
Record serial number in blank space above (to locate, see serial
Rev 5.1/4-21
label on the product).
1
908 W. Main • P.O. Box 368
Laurel, MT USA 59044
800-548-7341 (phone)
406-628-8231 (phone)
406-628-8354 (fax)
www.WPG.com
FLEXR(L)-HV11AIR: #35036
