This user's guide describes the operation of the evaluation module for the TAS5518
Digital Audio PWM Processor and the TAS5261 Digital Amplifier Power Output Stage
from Texas Instruments.
.............................................................................................
1
Overview
.................................................................................
2
Quick Setup Guide
..................................................................................
3
System Interfaces
............................................................................................
4
Protection
5
Related Documentation from Texas Instruments
1
Integrated PurePath Digital™ Amplifier System
2
Physical Structure for the TAS5518-5261K2EVM (Approximate Layout)
3
TAS5518 GUI Window
4
Recommended Power-Up Sequence
5
J901 and J900 Pin Numbers
..................................................................................
6
J902 Pin Numbers
7
J100 and J200 Pin Numbers
1
Recommended Supply Voltages
2
Recommended Supply Voltages
...............................................................................
3
J901 Pin Description
...............................................................................
4
J900 Pin Description
...............................................................................
5
J900 Pin Description
6
J100 and J200 Pin Description
.................................................................................
7
J40 Pin Description
.................................................................................
8
J60 Pin Description
9
TAS5621 Warning/Error Signal Decoding
10
Related Documentation From Texas Instruments
Contents
.............................................
List of Figures
................................................
.............................................................................
............................................................
......................................................................
......................................................................
List of Tables
.................................................................
.................................................................
...................................................................
.....................................................
............................................
User's Guide
SLAU193 – October 2006
TAS5518-5261K2EVM
...................
TAS5518-5261K2EVM
2
3
5
9
10
2
3
5
6
6
7
7
4
6
6
6
7
7
8
9
10
10
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments TAS55185261K2
Summary of Contents for Texas Instruments TAS55185261K2
- Page 1 ................. J60 Pin Description ............. TAS5621 Warning/Error Signal Decoding ..........Related Documentation From Texas Instruments PurePath Digital, Equibit are trademarks of Texas Instruments. Windows is a trademark of Microsoft Corporation. SLAU193 – October 2006 TAS5518-5261K2EVM Submit Documentation Feedback Downloaded from Elcodis.com...
- Page 2 Overview The TAS5518-5261K2EVM PurePath Digital™ customer evaluation amplifier module demonstrates the two audio integrated circuits TAS5518 and TAS5261 from Texas Instruments (TI). TAS5518PAG is a high-performance, 32-bit (24-bit input) multichannel PurePath Digital™ pulse width modulator (PWM) based on Equibit™ technology with fully symmetrical AD modulation scheme. It accepts input sample rates from 32 kHz to 192 kHz.
- Page 3 www.ti.com Quick Setup Guide PCB Key Map Physical structure for the TAS5518-5261K2EVM is illustrated in Figure Figure 2. Physical Structure for the TAS5518-5261K2EVM (Approximate Layout) Quick Setup Guide This section describes the TAS5518-5261K2EVM board in regards to power supplies and system interfaces.
- Page 4 • 2 pc. Cables for speaker connection. • 1 pc. PurePath Digital™ CD-ROM: If any of these items is missing, contact the Texas Instruments Product Information Center nearest you to inquire about a replacement. Connect Input-USB board to TAS5518-5261K2EVM using the two delivered IDC cables.
- Page 5 For easy access of the file, it is recommended to copy the files into the directory where the GUI is installed. Default is C:\Program Files\Texas Instruments Inc\TAS5518\ For more advanced use of the GUI, see the GUI user’s guide and data sheet for the TAS5518.
- Page 6 www.ti.com System Interfaces Table 2. Recommended Supply Voltages Description Voltage Limitations Current Recommendations (4-Ω Load) System power supply 15–20 V 0.3 A Output stage power supply 0–50 V 5 A (10-A peak) The rated current corresponds to a 2-channel full scale (125 W each), which most likely is adequate for a standard 2-channel amplifier design.
-
Page 7: Psu Control Interface (J902)
www.ti.com System Interfaces PSU Control Interface (J902) This interface is used for onboard sensing of output supply voltage and for the power supply volume control (PSVC) signal. Figure 6. J902 Pin Numbers Table 5. J900 Pin Description Net-Name on Schematics Description –... -
Page 8: Control Interface (J40)
www.ti.com System Interfaces Control Interface (J40) This interface connects the TAS5518-5261K2EVM board to a TI input-USB board. Table 7. J40 Pin Description Net-Name on Schematics Description Ground RESERVED — Ground RESET System reset (bi-directional). Activate MUTE before RESET for quiet reset RESERVED —... -
Page 9: Digital Audio Interface (J60)
www.ti.com Protection Digital Audio Interface (J60) The digital audio interface contains digital audio signal data (I2S), clocks etc. See the TAS5518 data sheet (SLES115) for signal timing and details not explained in this document. Table 8. J60 Pin Description Net-Name on Schematics Description Ground MCLK... -
Page 10: Additional Documentation
Related Documentation from Texas Instruments 4.2.2 Overtemperature Protection (OTP) TAS5261 has an on-chip temperature-sensing system. If the chip temperature reaches a critical temperature, the overtemperature warning pin goes low. If the chip temperature continue to increase, the TAS5261 protects itself by shutting down the power stage. In this case, both OTW and SD are low. -
Page 11: Evaluation Board/Kit Important Notice
EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards. -
Page 12: Important Notice
TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products...
