- Page 1 Product Manual Thrii Hand Wash Dryer Thrii-SS Solid Surface Thrii-DIS-SS Solid Surface Disabled THRII-ST-2 Stainless steel...
- Page 2 Product Manual Thrii Hand Wash Dryer Revision 29...
-
Page 3: Safety Information
Product Manual Thrii Hand Wash Dryer Safety Information WARNINGS! The appliance must be earthed. The means for disconnection from the mains supply must be incorporated in the fixed wiring in accordance with the wiring rules. Do not switch the unit on if there is a possibility that the water in the heater is frozen. The appliance must not be installed in locations where freezing can occur. -
Page 4: Table Of Contents
Product Manual Thrii Hand Wash Dryer Table of Contents Safety Information ........................... 3 Storage Information ..........................3 Disclaimer & Copyright Notice ......................6 Conventions ............................. 7 Warning ........................7 Note ........................7 Numbered procedures ..................... 7 Bullet lists ........................ 7 Menu items ...................... - Page 5 Product Manual Thrii Hand Wash Dryer Addendum for Thrii Rear Access Unit ................... 34 Addendum Notes: ....................34 Revision 29...
-
Page 6: Disclaimer & Copyright Notice
Every effort has been made to supply the information within this manual which is correct. Wallgate Limited will not be liable for any damage or loss that arises if the person installing, operating or maintaining the unit has not read or not complied with the manual. -
Page 7: Conventions
Certain conventions are used in this manual to make it easier to read and understand. It is recommended that you read and understand these warnings before you install and commission the Wallgate Thrii. Warning A warning with red text on a white background is used to give information about hazards that can cause injury or death. -
Page 8: Menu Items
Thrii fascia and bowl. Power up The external electricity supply is provided to the Thrii. Thrii® is a registered trademark of Wallgate Limited Description sourced from Wikipedia at http://en.wikipedia.org/wiki/British_standard_pipe_thread Revision 29... -
Page 9: Technical Specification
Product Manual Thrii Hand Wash Dryer 4. Technical Specification Weight Item Solid surface Solid surface Stainless DISABLED Steel Fascia 15.3 kg 15.3 kg 11.5 kg Engine 7.0 kg 7.0 kg 7.0 kg Support frame, etc. 4.5 kg 4.5 kg 4.5 kg Full soap container 2.6 kg 2.6 kg... -
Page 10: Overview
Product Manual Thrii Hand Wash Dryer 5. Overview The Wallgate Thrii is an integrated hand wash dryer unit with automatic infra-red sensor operation. There are three model options that are otherwise identical except for the fascia material. It is available in solid surface material, models Thrii-SS & Thrii-DIS-SS, and stainless steel (grade 316) with a solid surface bowl model THRII-ST-2. - Page 11 Product Manual Thrii Hand Wash Dryer Item Description Item Description Fascia IR Sensor Fascia Lock Soap Outlet (hidden) Wash Bowl Water Spray Nozzle Dispensing Unit Label (No label on no soap Dryer Outlet Version) Fig.2 Fascia Rear View Item Description Item Description Fascia...
-
Page 12: Installation And Commissioning
The Wallgate Thrii hand wash-dryer unit is a three-part assembly consisting of a flush support frame, a hinged fascia and engine assembly. It is necessary to install the mounting frame and prepare the services (electrical, water and waste) prior to installing the fascia. -
Page 13: Site Preparation
Product Manual Thrii Hand Wash Dryer ✓ 1 Wall frame waste connector ✓ 1 Waste pipe 32 – 40mm adapter pipe (AUS/NZ only) ✓ 1 Fascia lock key ✓ 1 Mains electrical plug and lead (2-metre length) ✓ 1 Water inlet plumbing assembly ✓... - Page 14 Terminate the cold-water supply with a suitable isolating tap. For optimum operation, a dynamic water flow pressure of between 1 & 3 bar is required. Note: Request advice from Wallgate before you connect the unit to a gravity- fed water supply. Revision 29...
-
Page 15: Installing The Support Frame, Water, Waste And Electrical Connections
The hinge-side of the frame should be hard up against the aperture. Fig.4 Typical site preparation for Wallgate Thrii unit. (Dimensions in millimetres) Note hinge positions on the right-hand side when looking from the front. Revision 29... - Page 16 Product Manual Thrii Hand Wash Dryer Thrii-SS Thrii-DIS-SS THRII-ST-2 Fig.5 Fascia Dimensions (in millimeters) Revision 29...
- Page 17 Fig.6 Typical site installation of Wallgate Thrii unit showing clamping bracket (view from the rear). 4. Insert the 4No. M10x150mm threaded rods through the corner angles on the support frame and into the brackets as shown in Fig. 6.
- Page 18 Product Manual Thrii Hand Wash Dryer 6. Install the waste connector to the frame as shown in Fig. 7 (below) along with the pipe adapter (Aus/NZ only) which then is terminated to the deep seal waste trap as detailed in section 6.2 site preparation. Note that the pipe adapter can be used for either a 32mm or 40mm pipe connection.
-
Page 19: Mounting The Fascia
Product Manual Thrii Hand Wash Dryer Note: The hand wash unit is supplied with a double check valve fitted to the water inlet connection which must be in place to comply with water regulations. Note: Avoid applying excessive amounts of pipe sealing compound as particles of sealant can block water filters and impede valve operation. - Page 20 Product Manual Thrii Hand Wash Dryer 3. Engage the ‘Hinge release lock’ spigot, fitted to each hinge to prevent accidental hinge latch release see Fig.9. 4. It is necessary to check the fascia alignment with the frame before proceeding further, as the hinges may need adjustment. Carefully close the fascia ensuring the door opens and closes freely.
- Page 21 Fig. 11b. Rear access only units are available, see product addendum sheet at end of the manual for more information, also contact Wallgate Ltd or visit www.wallgate.com. Fig.11 Securing the unit for rear-access only, 11a showing hinge side locks, 11b showing fixing repositioning.
-
Page 22: Engine Installation
Product Manual Thrii Hand Wash Dryer 6.2.4 Engine Installation 1. Remove the engine cover, retaining the engine cover fixing. 2. Remove the securing pin out through the side from the base of the engine Fig. 12 Fig.12 Securing pin removal Fig. -
Page 23: Electrical & Waste Connections
Product Manual Thrii Hand Wash Dryer 5. Replace the engine cover, ensuring the flexible hose and soap hose attached does not foul upon reassembly, and secure the cover into place with the fixing provided Fig. 15. Fig.15 Replacing the engine cover. 6.2.5 Electrical &... -
Page 24: Mains Water Connection From Support Frame To The Engine
Cold Water Supply Fig.16 Engine water supply hose connection to water connector on wall frame 6.2.8 Commissioning for use To commission the Wallgate Thrii: 1. Ensure the engine cover is securely fitted and the electrical plug is fully pushed in. - Page 25 Warning! The unit should only be operated with the fascia in the fully closed position and the waste outlet engaged. Failure to do so may result in leakage. 4. Switch ON the fused spur, this will power-up the Wallgate Thrii ready for use.
-
Page 26: Programmed Settings
Any service or repair work must be done by a qualified engineer. During the warranty period, the service or repair must only be done by a Wallgate engineer or appointed service agent. Refer to the Wallgate terms and conditions for warranty information. -
Page 27: Operation
Product Manual Thrii Hand Wash Dryer Fig. 18 LCD Control detail Item Description Item Description MED Fan speed LED indicator Menu Select button LOW Fan speed LED indicator UP Button Air Heater ON/OFF DOWN Button Air Heater OFF LED indicator ENTER Button Air Heater ON LED indicator FAN SPEED Button... -
Page 28: Soap Operation
Product Manual Thrii Hand Wash Dryer 7.1.1 Soap Operation There are 2 settings for soap delivery, FOAM (default) or LIQUID. The rocker switch used to change the soap option is located on engine unit. Adjust the switch to position 1 for foam or 0 for liquid see below; Soap selection switch. -
Page 29: Dryer Operation
Product Manual Thrii Hand Wash Dryer Viscosity: Wallgate provide Walcare-208, a low viscosity soap specifically formulated for use in Thrii hand wash dryers. Please refer to Thrii soap recommendation document for viscosity specifications. 7.1.2 Dryer Operation There are 3 dryer speed settings. The control to adjust the speed is located at the rear of the unit. -
Page 30: Advanced Adjustment
& to the cycle sequence. Warning! Incorrect alterations to the default hand wash settings may result in malfunctions or possible unit damage. If in any doubt, contact “Wallgate after- sales service” for advice & information. Description... -
Page 31: Hygiene Purge Adjustment
Instructions can be downloaded from the Wallgate web site or contact Wallgate Ltd ✓ Restore the unit to factory default settings. ✓ Instructions to change the cycle sequence of soap – water – hand dryer. -
Page 32: Care, Routine Maintenance, Service And Repair
Care and Cleaning • A range of compatible liquid soaps and specifications are available from Wallgate. • For cleaning see the Wallgate cleaning guides, for either stainless steel or solid surface, which can be found on the Wallgate website. • Cleaning kits are available from Wallgate Ltd. -
Page 33: Service And Repair
Any service or repair work must be done by a qualified engineer. During the warranty period, the service or repair must only be done by a Wallgate engineer or appointed service agent. Refer to the Wallgate terms and conditions for warranty information. - Page 34 It will only be serviceable through a rear service duct and have permanent brackets mounting it in position. 2. Depending on model supplied please follow respective drawings for mounting the unit (visit www.wallgate.com/products/hand-wash-dryers/thrii-range): THRII-SS-RA THRII-ST-2 THRII-DIS-SS-RA 3.
- Page 35 Wallgate Ltd. Crow Lane, Wilton, Salisbury, Wiltshire, SP2 0HB, England tel: +44 (0) 1722 744594 fax: +44 (0) 1722 742096 email: service@wallgate.com web: www.wallgate.com...
