Alemlube EL Series Owner Technical Manual
Hot water hose reels
Hide thumbs
Also See for EL Series:
- Owner technical manual (11 pages) ,
- Instruction manual (5 pages) ,
- Service instructions (3 pages)
Advertisement
Quick Links
Description
The Alemlube EL Series HR30000 hot water hose reels are quality hose handling, retrieval and storage systems with crimped hose
end, integral carry handle and detachable mounting bracket enabling 180º hose reel rotation. Manufactured with high density impact
resistant and UV stabilised polypropylene cover, EL Series HR30000 hot water hose reels feature a positive latching system that
automatically locks the hose at the desired length and the heavy duty internal spring assembly easily retrieves the hose when
partially or fully extended. Use teflon tape or thread sealant to the outlet fitting on the hose and then connect the tool or nozzle.
Suitable for use in the agricultural, automotive, manufacturing, contractor and transport sectors, the HR30000 hot water hose reel
increases safety by reducing rewind speed by up to 80%.
Mountable on the wall or ceiling, EL Series HR30000 hot water hose reels feature a constant speed control device ensuring safe and
accurate rewinding.
Specifications
Uses
Working Pressures
Materials
HR30000 / HR30070 / HR30070C / HR30080 / HR30080C / HR30090C
HR30000 SERIES HOSE REELS
PART No.
PRODUCT DESCRIPTION
HR30070
EL Series hot water hose reel complete with 20m x 10mm ID Hybrid Polymer hose and 0.9m lead in hose
HR30070C
EL Series hot water hose reel complete with 20m x 10mm ID Hybrid Polymer hose and 0.9m lead in hose & nozzle
HR30080
EL Series hot water hose reel complete with 15m x 12mm ID Hybrid Polymer hose and 0.9m lead in hose
HR30080C
EL Series hot water hose reel complete with 15m x 12mm ID Hybrid Polymer hose and 0.9m lead in hose & nozzle
HR30090C
EL Series hot water hose reel complete with 15m x 12mm ID Hybrid Polymer hose and 0.9m lead in hose & nozzle
NSW / ACT
QLD / PNG
TEL: (02) 9677 1555
TEL: (07) 3204 9166
FAX: (02) 9675 1155
FAX: (07) 3204 1224
OWNER'S TECHNICAL MANUAL
EL SERIES
HR30000 SERIES Hot Water Hose Reels
Hot water
300psi (20bar)
Polypropylene covers - Hybrid Polymer hose
VIC / TAS
TEL: (03) 8787 8288
FAX: (03) 8787 8266
Visit our website at
www.alemlube.com.au
WA
SA / NT
TEL: (08) 9302 4199
TEL: (08) 8241 7111
FAX: (08) 9303 2095
FAX: (08) 8241 7011
or
www.alemlube.co.nz
PSI/BAR
300psi/20bar
300psi/20bar
300psi/20bar
300psi/20bar
300psi/20bar
NZ
TEL: (64) 9 447 1007
FAX: (64) 9 447 1008
1
