- Page 1 HOW TO Install Bowden-cables on EA9...
-
Page 2: Table Of Contents
Handi-lift EA9 Table of contents Introduction Preparation. 2.1 Parts 2.2 Tools Step by step 3.1 Installation of cable for upper and lower ramp 3.2 Installation of cable on lifts with side-access-ramp 2023 Side 2... -
Page 3: Introduction
Handi-lift EA9 1 Introduction If you for some reason must the Bowden-cable, the description below is explaining how you must update this system. 2 Preparation. Before you install the new Bowden-cable please read these instructions carefully. Check that you have all the necessary parts and tools to upgrade the system. -
Page 4: Parts
Handi-lift EA9 2.1 Parts Bowden-cable 2.2 Tools Locking pliers Universal key 2023 Side 4... -
Page 5: Step By Step
Handi-lift EA9 3 Step by step 3.1 Installation of cable for upper and lower ramp Install the cable in the ball head and in the bracket on the frame, as shown on the photos. 3.2 Installation of cable on lifts with side-access-ramp Install the cable in the ball head (bend the cable in approx. - Page 6 Handi-lift EA9 Turn the bracket 180°. Install the cable in the bracket and pull the cable as far down as possible. Adjust the lower lock nut, so it is situated 3 mm below the bracket. Push the cable up against the bracket and fasten the upper lock nut.
