Summary of Contents for Cama HANDI-LIFT EA6
- Page 1 INSTALLATION MANUAL FOR HANDI-LIFT EA6...
-
Page 2: Table Of Contents
Program the PLC: Installation manual for fold down seat Check list: Parts: Tools: Step by step Install the bracket: Make holes in the front cover: Install the fold down seat: Installation Test Certificate Cama 6 2011 Page 2 Version 1.0... -
Page 3: Introduction
Handi-lift EA6 1 Introduction 1.1 Check the parts and drawing: Before you start installing please read this installation manual. Check the received parts for transport damage. Next, study carefully the installation drawing that comes with the lift to ensure that all angels and dimensions are correct and all dimensions are there. -
Page 4: Forces On The Building
Handi-lift EA6 2 Forces on the building Wall mounted rail 1. The wall mounted bracket must be fixed by 2 pieces of M10 Glue bolts with disc and cap nuts in the top and lower holes and 1 piece of coach screw in the middle hole. -
Page 5: Install The Rails
Handi-lift EA6 Stanchion mounted rail 1. Support stanchions must be fixed to concrete landing and treads, They must be fixed by 3 pieces of M10 Glue bolt with discs and self-locking nuts. 3 Install the rails 3.1 Column installation: Only if the Handi-Lift is installed on columns you have to start with them. - Page 6 Handi-lift EA6 NOTE! It is very important that the support bracket is plumb (see fig 2). It may be necessary to pack out the support brackets on uneven walls. fig. 2 Mark out the first support bracket you want to put up (it can be anyone of them, usually the bottom or top first).
- Page 7 Handi-lift EA6 Before introducing the rail to the support brackets lubricate the “tee bolt” location sleeve lightly with a freeing solution to aid installation (see fig 5). fig. 5 Place the required “tee bolts” in the rail section and introduce to the support brackets.
-
Page 8: Curved Rail Installation
Handi-lift EA6 3.3 Curved rail installation: The curved sections of the rail can now be fixed. Insert the rail-joining stud into the curved rail section, threading in until tight and ensuring that the grub screws are accessible from the inner side of the straight rail (see fig 9). -
Page 9: Fasten All "Tee Bolts" And Support Brackets
Handi-lift EA6 With a spirit level ensure that the rack is level throughout the entire installation (see fig 12). Tighten all “tee bolts” and grub screws at the rail jointing studs. fig. 12 NOTE! If the fittings are not in plumb, it can deteriorate the operation of the lift with at least 30% 3.4 Fasten all “tee bolts”... -
Page 10: Installing The Lift Unit
Handi-lift EA6 4 Installing the lift unit 4.1 Place the lift unit on the rail: Hand wind platform in it’s down position and remove the front cover from the lift unit. Install the loose carrying arms Plug the remote control into the control board (see fig 16) And turn on the unit at the key switch. -
Page 11: Connect The Electrical
Mount the front cover on the lift and carry out full test and commission of unit to certificate. Carry out full operational instruction to customer and hand over certificate and operation manual for Handi-Lift EA6. The customer shall approve the installation and the demonstration in writing. 2011 Page 11 Version 1.0... -
Page 12: Installation Manual For Fold Down Seat
Handi-lift EA6 5 Installation manual for fold down seat 5.1 Check list: Before installing the fold down seat please read these instructions The fold down seat shall be mounted on the right hand side on the lift. Check that you have all the right parts, and tools to install the fold down seat. -
Page 13: Step By Step
Handi-lift EA6 6 Step by step 6.1 Install the bracket: Before After 1) Open the lift and remove the front cover from the lift. 2) Drill 2 ø3,8 holes and one ø6,8 hole 3) Make the M8 thread (see drawing for measurements). -
Page 14: Make Holes In The Front Cover
7) Install the front cover and the fold down seat. 8) Please check that there is a warning sign on the fold down seat, if not contact CAMA Lift in Denmark. 9) If it is possible please instruct the owner/ user how to operate the fold down seat. -
Page 15: Installation Test Certificate Cama
Rated load: ____________ kg Stairlift serial no: ______________________ Rated speed: ___________ m/s Type and year of manufacturer: _________________________ Manufacturer: CAMA Lift ApS, Ellehammervej 6, DK 9900 Frederikshavn Contract electrical supply: _________ V _________ Phase _________ Hz Mains supply fuse rating: _________ A √... - Page 16 Handi-lift EA6 The alarm device when activated operates correctly All notices, etc. are correctly displayed Undergo without failure a dynamic test to check the forces imposed by the maximum working load Undergo the testing of the overload detection device for wheelchair...
