- Page 1 HOW TO Change the side edge to a side-access-ramp...
-
Page 2: Table Of Contents
Handi-lift EA6 / EA7 / ML7 Table of contents Introduction Preparation. 2.1 Parts Fejl! Bogmærke er ikke defineret. 2.2 Tools Fejl! Bogmærke er ikke defineret. Step by step 3.1 Demount the side edge 3.2 Installation of the side-access-ramp 2019... -
Page 3: Introduction
Handi-lift EA6 / EA7 / ML7 1 Introduction If you for some reason must change the side edge to a side-access-ramp, the description below is explaining how you must do this operation. 2 Preparation. Before you install the side-access-ramp please read these instructions carefully. Check that you have all the necessary parts and tools to install the side-access-ramp. -
Page 4: Step By Step
Handi-lift EA6 / EA7 / ML7 3 Step by step 3.1 Demount the side edge Use a screwdriver to remove the 2 UMBRAKO screws that is holding the side edge, see picture below: Flaps holding the side edge is removed: ... -
Page 5: Installation Of The Side-Access-Ramp
Handi-lift EA6 / EA7 / ML7 3.2 Installation of the side-access-ramp Install the Bowden-cable on the ramp as shown on below picture: Hold the side-access-ramp in a 90° angle and tighten the two 6 mm socket screws with a 3 mm Allen key. - Page 6 Handi-lift EA6 / EA7 / ML7 Adjust the spring: Drill holes and make thread for the fastening of the spring: 2019 Page 6...
- Page 7 Handi-lift EA6 / EA7 / ML7 Install the spring: The installation of the side-access-ramp is now completed, and you can put the platform back together again. We suggest that you make a test drive with the lift to check if the side-access-ramp is working properly.
