- Page 1 HOW TO INSTALL FOLD DOWN SEAT FOR HANDI-LIFT EA6...
-
Page 2: Table Of Contents
Handi-lift EA6 Table of contents Introduction Preparation Fejl! Bogmærke er ikke defineret. Parts: Tools: Fejl! Bogmærke er ikke defineret. Step by step Install the bracket: Fejl! Bogmærke er ikke defineret. Make holes in the front cover: Install the fold down seat: ... -
Page 3: Introduction
Handi-lift EA6 1 Introduction If you for some reason have to install a fold down seat on an EA6, the description below will explain how to install it. 2 Preparation Before installing the fold down seat please read these instructions The fold down seat shall be mounted on the right hand side on the lift. -
Page 4: Parts
Handi-lift EA6 2.1 Parts: Indsæt billede af montagebeslag og Mounting bracket 2 stk skruer. # 6-2000-41 incl. 2 ø4x25 screws Complete fold down seat # 0-2000-00 2016 Page 4... -
Page 5: Tools
Handi-lift EA6 2.2 Tools: 3.8 mm drill 6.8 mm drill 12 mm drill 4 mm allen key 6 mm allen key M8 tap PH3 crosshead Rubber hammer Drill 2016 Page 5... -
Page 6: Step By Step
Handi-lift EA6 3 Step by step 3.1 Install the bracket: Before After 1) Open the lift and remove the front cover from the lift. 2) Drill 2 ø3,8 holes and one ø6,8 hole (see drawing 5 for measurements). 3) Make the M8 thread. -
Page 7: Make Holes In The Front Cover: 3.3 Install The Fold Down Seat
13) Install the front cover and the fold down seat. 14) Please check that there is a warning sign on the fold down seat, if not contact CAMA Lift in Denmark. 15) If it is possible please instruct the owner/ user how to operate the fold down seat.
