Summary of Contents for Cama Handi-Lift ML7
- Page 1 Installation manual For Handi-Lift ML7 Original Version...
-
Page 2: Table Of Contents
Handi-Lift ML7 Table of content Introduction ....................3 Check the parts and drawing ..............3 Electrical installation ................3 Forces on the building ................4 Install the tower ..................4 Tower positioning ................. 4 Installing the lift unit .................. 7 Attach the back frame to the tower ............ -
Page 3: Introduction
Handi-Lift ML7 1 Introduction 1.1 Check the parts and drawing Before you start installing please read this installation manual. Check the received parts for transport damage. Next, study carefully the installation drawing that comes with the lift to ensure that all dimensions are correct and corresponds to the installation site. -
Page 4: Forces On The Building
Handi-Lift ML7 Forces on the building LOAD & FORCES 2946N 1129N 2300mm. 770N 2000mm. 870N 1800mm. 960N 1700mm. 1050N 1500mm. 1120N 1450mm. 1190N Fig. 2 The tower is fixed to the floor and to the wall with M10x90mm (Class 8.8) Glue bolts. - Page 5 Handi-Lift ML7 Place the tower on the floor against the wall. Adjust the tower to be perpendicular to the wall of the landing. (see fig. 3) The distance between the centre of the tower and the landing wall is given on the installation drawing.
- Page 6 Handi-Lift ML7 Finally, adjust the tower to be vertical in both directions before fixing it to the wall and the floor, so the landing fits. Mount the bolts in the wall with glue as described on the glue package. Fasten the nuts.
-
Page 7: Installing The Lift Unit
Handi-Lift ML7 Installing the lift unit 4.1 Attach the back frame to the tower Place the back frame of the lift on the floor in front of the tower. Fig. 5 Connectors and cables are put through the hole on both sides. -
Page 8: Connect The Electrical
Handi-Lift ML7 Position the back frame to the mounting holes of the carriage. Fasten the back frame using the four screws and washers. Fig. 7 4.2 Connect the electrical Leave the lift carriage and back frame in the lower position of the tower. Place the platform on the floor in front of the back frame. -
Page 9: Connect The Platform To The Back Frame
Handi-Lift ML7 Fig. 9a Fig. 9b 4.3 Connect the platform to the back frame Mount the platform to the back frame using the two screws and nuts (M12x160/M12x180). If necessary, adjust the lower position of the platform using the set screws. -
Page 10: Connect The Power
Handi-Lift ML7 Now install the control boxes Adjust the limit switches, as shown in the photo: Fig. 12 4.4 Connect the power Fig. 13 The wires are connected to the safety cut-out as follows: L1 is connected to terminal 2 ©... -
Page 11: Load Cell Adjustment
Handi-Lift ML7 N is connected to terminal 4 Earth is connected to the earth terminal 4.5 Load cell adjustment Test the lift with max. load (Ex. 300 kg.) + 50kg. The load cell is adjusted from the factory, however if it is necessary to adjust it, it is done by turning the load cell sensor. -
Page 12: Handicap Symbol
Handi-Lift ML7 4.6 Handicap symbol In public places, you need to install the international Handicap Symbol (ISO 7000) with a minimum size of 50 mm next to each control box. See picture below: Filling oil It is important that you fill oil on the unit, however be careful not to overfill it. -
Page 13: Final Touch
Handi-Lift ML7 Final touch Install the back cover, if there is a gate, you need to install it before the back cover, see chapter 7: Fig. 15 Examples of an installation: © 2021 Page 13 Version 1.2... -
Page 14: Install The Gate
Handi-Lift ML7 Install the gate Important: you need to install the gate in the closed position. If the gate is not in closed position on receipt, then there is a mark on the foot plate that indicates which position is closed. On the installation drawing you can see where to place it, please make sure it is in level. - Page 15 Handi-Lift ML7 The gate can be connected to the lift in two different ways: Hole in the floor: No hole – use slot in foot plate Fig. 18a Fig. 18b Connect the plug from the lift with the plug from the gate.
- Page 16 Handi-Lift ML7 Make sure the gate is flush with the edge of the floor and then glue and tighten the M10x90 glue bolts. Fig. 20 Now you are ready to test the gate. Make sure it can open and close properly.
-
Page 17: Installation Test Certificate
Rated load: ____________ kg Handi-lift serial no: ______________________ Rated speed: ___________ m/s Type and year of manufacture: _________________________ Manufacturer: CAMA Lift ApS, Ellehammervej 6, DK 9900 Frederikshavn Contract electrical supply: _________ V _________ Phase _________ Hz Mains supply fuse rating: _________ A Verification test on each machine before first use ... -
Page 18: Declaration A
Handi-Lift ML7 The correct clearance dimensions and from the surrounding structure are maintained throughout the full travel of the Handi-Lift The Handi-Lift shall be subjected to insulation tests Verify that the polarity of the mains supply connection is correct Test to verify the functional operation of the overspeed detection...
