Xtender36'
Xtender36'
Assembly Instructions
DO NOT RETURN THIS BATTING CAGE TO THE RETAIL STORE WHERE
PURCHASED. CALL TOLL FREE: (800) 492-9334
DO NOT LEAVE THE XTENDER CAGE ASSEMBLED DURING STRONG WIND, SNOW, SLEET, OR ICE
STORMS. THE XTENDER IS NOT DESIGNED TO WITHSTAND EXTREME WEATHER CONDITIONS
AND DAMAGE TO THE FIBERGLASS FRAMES CAUSED BY EXTREME WEATHER MAY NOT BE
USE THIS PRODUCT WITH ADULT SUPERVISION ONLY. SERIOUS BODILY INJURY MAY OCCUR!
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: 435-688-0741
Home Batting Cage
IMPORTANT
IMPORTANT WARRANTY WARNING:
COVERED IN THE MANUFACTURERS WARRANTY.
WARNING:
READ WARNING LABELS CAREFULLY.
®
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Heater Sports Xtender36'
Summary of Contents for Heater Sports Xtender36'
- Page 1 Xtender36’ Xtender36’ Home Batting Cage Assembly Instructions IMPORTANT DO NOT RETURN THIS BATTING CAGE TO THE RETAIL STORE WHERE PURCHASED. CALL TOLL FREE: (800) 492-9334 IMPORTANT WARRANTY WARNING: DO NOT LEAVE THE XTENDER CAGE ASSEMBLED DURING STRONG WIND, SNOW, SLEET, OR ICE STORMS.
-
Page 2: Parts List
Page 2 PARTS LIST Part# A-1 (Quantity 4) - 44" Long Model#XT399 Fiberglass Rod with Foam Pad Revised 5-25-2010 Part# B (Quantity 12) - 44" Long Metal Fitting/Ring & Fiberglass Rod with Foam Pad Part# G - (Quantity 1) Roll Of Black Tape Part# C (Quantity 8) - 44"... -
Page 3: Do Not Return This Product To The Store
Page 1 Page 3 STEP 1: Pound Ground Stake (Part# F) Into Ground 12 Feet Apart From Each Other (8X). Note: Make Sure Stakes Are Perfectly Straight Up And Down. 12 Feet Part# C 12 Feet Part# C 12 Feet Part# C 12 Feet Part# C... - Page 4 Page 4 STEP 2: End Pole Assemblies (Quantity 2), Middle Pole Assemblies (Quantity2) (Refer to Part #’s Below.) Slide each section together and tape. Repeat for all four Pole Assemblies. Note: Position the Rope Rings in the same direction, and when forming the arch be sure to face the Rope Rings to the inside of the cage area.
- Page 5 STEP 3: Tie Net Guide Ropes to Rings on each Pole Assembly. (As shown) Page 5 End Pole Rings (4X) Net Guide Net Guide Ropes (4X) Ropes (4X) Support Rope Support Rope End Pole Tie Guide Rope (4X) to Rings Rings (4X) on End Pole Assembly.
- Page 6 Page 6 STEP 6: Hammer Rope Stakes (Part# I) into ground and tie Support Ropes onto Rope Stake holes (4X). Make sure rope is tight. Net Guide Rope(s) Net Guide Rope(s) Support Rope Caution: Excessive wind can cause frame assembly to collapse. Make sure Support Ropes are secure Pound Part#I (Rope Stake) into ground and tie at all times and take down in...
- Page 7 Page 7 STEP 7: After the frame arches are formed, tie additional Black Guide Ropes where Part# D And Part# C join together between each arch. This allows additional support and keeps the netting form sagging into the cage area. Rope Knot Joint of Part# D and Part# C.
- Page 8 Page 8 STEP 8: Unfold Part# H (Batting Cage Net) and lay out long ways on the ground. Gently begin placing Part# H (Batting Cage Net) over the assembled frame. IMPOrTaNT: Un-tie Support Ropes from Rope Stakes. When the netting is in place slide the rope through the net- ting back down to the Rope Support Stake and re-tie the knot.
- Page 9 Page 9 OPTIONaL aCCESSOrY (Sold Separately): You can purchase any Heater Sports Pitching Machine product to attach to the Xtender Home Batting Cage. Call Toll Free: 1-800-492-9334 to locate a retail store near you. WarNING Make sure Heater Sports Pitching Machine is...
- Page 10 Xtender36’ Xtender36’ Page 1 Optional: Joining 2 Cages (Must purchase 2 separate cages) INSTRUCTIONS Step #1 Fully assemble both batting cages and place them end-to-end 4 -2 inches apart. Batting Cage #2 Batting Cage #1 IMPOrTaNT OPTION When joining cages you can use just one arch in the middle where the cages meet.
- Page 11 Page 2 Joining 2 Cages INSTRUCTIONS Step #2 Match the red reinforced seams together where the cages meet. Using the extra support ropes weave the two cages together. Batting Cage #1 Extra Support Rope (From the ends where Batting Cage #2 the cages meet) Batting Cage #1 Batting Cage #1...
- Page 12 Page 3 Joining 2 Cages INSTRUCTIONS Step #4 Using scissors, cut an opening in the netting where the stitched netting come together on both cages. Batting Cage #2 Batting Cage #1 Step #5 (Optional) After cutting the netting on both cages take the extra netting and attach it to the end of the cage opposite the Pitching Machine Harness.
