Xtender30'
Xtender30'
Home Batting Cage
Assembly Instructions
IMPORTANT
DO NOT RETURN THIS BATTING CAGE TO THE RETAIL STORE WHERE
PURCHASED. CALL TOLL FREE: (800) 492-9334
IMPORTANT WARRANTY WARNING:
DO NOT LEAVE THE XTENDER CAGE ASSEMBLED DURING STRONG WINDS, HEAVY SNOW, SLEET,
OR ICE STORMS. THE XTENDER IS NOT DESIGNED TO WITHSTAND EXTREME WEATHER
CONDITIONS AND DAMAGE TO THE FIBERGLASS FRAMES CAUSED BY EXTREME WEATHER
MAY NOT BE COVERED IN THE MANUFACTURERS WARRANTY.
WARNING:
USE THIS PRODUCT WITH ADULT SUPERVISION ONLY. SERIOUS BODILY INJURY MAY OCCUR!
READ WARNING LABELS CAREFULLY.
®
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: 435-688-0741
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Heater Sports Xtender30'
Summary of Contents for Heater Sports Xtender30'
- Page 1 Xtender30’ Xtender30’ Home Batting Cage Assembly Instructions IMPORTANT DO NOT RETURN THIS BATTING CAGE TO THE RETAIL STORE WHERE PURCHASED. CALL TOLL FREE: (800) 492-9334 IMPORTANT WARRANTY WARNING: DO NOT LEAVE THE XTENDER CAGE ASSEMBLED DURING STRONG WINDS, HEAVY SNOW, SLEET, OR ICE STORMS.
-
Page 2: Parts List
PARTS Page 2 LIST (This Clips To The Hole In Part# I Rope Stake) Part# A-1 (Quantity 2) - 44" Long - End & Middle Pole Assemblies Fiberglass Rod with Foam Pad (These Clip To The Rings On Part# A-1) Part# A-2 (Quantity 1) - 44"... -
Page 3: Do Not Return This Product To The Store
Page 3 STEP 1: Pound Ground Stake (Part# F) Into Ground 12 Feet Apart From Each Other (6X). Note: Make Sure Stakes Are Perfectly Straight Up And Down. 15 Feet Part# F 15 Feet Part# F Part# F 12 Feet 12 Feet 12 Feet 15 Feet... - Page 4 Page 4 STEP 2: End Pole Assemblies (Quantity 2) (Refer to Part #’s Below.) Slide each section together and tape together. Repeat for the second End Pole Assembly. Part# B Part# A-1 Part# C Part# D Part# D Part# C Part# B-1 Part# B Part# G...
- Page 5 STEP 4: Clip Net Support Ropes to Rings on End Pole Assembly (2X). Page 5 Net Support Ropes (4X) End Pole Rings (4X) Net Support Ropes (4X) Stabilizer End Pole Rope Clip Rope (4X) to Rings Rings (4X) on End Pole Assembly. Repeat for other end.
- Page 6 Page 6 STEP 7: Hammer Rope Stake (Part# I) into ground and clip Stabilizer Rope into Rope Stake hole (6X). Make sure rope is tight. Support Rope(s) Support Rope(s) Stabilizer Rope Caution: Excessive wind can cause frame Rope Clip assembly to collapse. Make sure Stabilizer Ropes are secure Pound Part#I (Rope Stake) into ground and clip at all times and take down in...
- Page 7 Page 7 STEP 8: Where Part# D And Part# C join together (Middle Pole Assembly), wrap straight end of Part# E (Black Rope With Loop) around Middle Pole Assembly joint, slip through Part# E Loop and pull tight. Wrap straight end of Part# E (Black Rope with Loop) around joint of Part# D and Part# C (End Pole Assembly), pull tight, and tie a knot.
- Page 8 Page 8 STEP 9: Unfold Part# H (Batting Cage Net) and lay out long ways on the ground. Gently begin placing Part# H (Batting Cage Net) over the assembled frame. Important: Un-clip Stabilizer Rope from Part# I (Rope Stake). Slide Rope & Clip inside the Batting Cage, then out through an opening in the top of the Batting Cage Net.
- Page 9 You can purchase any Heater Pitching Machine product to attach to the Xtender Home Batting Cage. Call Toll Free: 1-800-492-9334 to locate a retail store near you. WARNING Make sure Heater Sports Pitching Machine is STEP 10: turned off and unplugged when attaching...
- Page 10 Xtender30’ Xtender30’ Page 1 Optional: Joining 2 Cages (Must purchase 2 separate cages) INSTRUCTIONS Step #1 Fully assemble both batting cages and place them end-to-end 4 -2 inches apart. Batting Cage #2 Batting Cage #1...
