Read This Before
Operating The Heater Pro
THE HEATER PRO BOWLING MACHINE THROWS REAL REGULATION BALLS; HOWEVER,
THE ACCURACY OF THE HEATER DEPENDS ON THE QUALITY, HARDNESS AND TYPE OF
HEATER SPORTS RECOMMENDS USING HEATER BOWLING MACHINE BALLS IN THE HEATER PRO MACHINE.
THESE BALLS HAVE BEEN PRECISELY CRAFTED TO PROVIDE YOU WITH HOURS OF ACCURATE, TROUBLE FREE
BATTING AND FIELDING PRACTICE.
Heater Bowling Machine Balls
Heater Bowling Machine Balls are recommended for use with the Heater Pro Machine. These balls
are incredibly accurate, long lasting, and produce the fastest ball speed.
Regulation Leather Balls:
The Heater Pro Bowling Machine works well with real leather balls; however, accuracy will vary more
than with bowling machine balls because the seams on leather balls cause the machine to pinch the ball dif-
ferently on each pitch. Be sure and use real leather balls, not simulated leather balls. Batters should be aware
at all times.
KNOWN PROBLEMS WITH SIMULATED (SYNTHETIC) LEATHER COVERED BALLS . . .
Simulated (synthetic) leather balls:
Simulated leather balls are inexpensive seamed balls that don't work well in the Heater Pro Machine.
During operation, portions of the simulated leather cover comes off the ball and attaches to the wheel of the
Heater Pro. Also, during operation, consumers have reported seeing small puffs of smoke coming out of the
Heater Pro. These puffs are not smoke, but actual pieces of the simulated leather ball being turned into small
dust particles as they pitch out of the Heater Pro Bowling Machine.
IF BALLS GET WET, THEY WILL NOT PITCH PROPERLY UNTIL THEY DRY.
KNOWN FACTS ABOUT DIFFERENT BALLS:
The speed and accuracy of each pitch is dependent on the hardness, roundness, and type of each ball used.
For example: If you have 12 balls and four are softer than the others (these balls will throw lower than the
other balls), if four are harder than the others (these balls will throw higher than the other balls), and if four are
not round (these balls will throw inside and outside). THIS LEAVES THE USER WITH THE IMPRESSION THAT THE
HEATER PRO BOWLING MACHINE IS INACCURATE WHICH IS NOT CORRECT.
IMPORTANT OPERATING INSTRUCTIONS
BALLS YOU USE IN THIS MACHINE!
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: 435-688-0741

Advertisement

loading
Need help?

Need help?

Do you have a question about the HeaterPro HTR499CM110V and is the answer not in the manual?

Questions and answers

Summary of Contents for Heater Sports HeaterPro HTR499CM110V

  • Page 1 THE ACCURACY OF THE HEATER DEPENDS ON THE QUALITY, HARDNESS AND TYPE OF BALLS YOU USE IN THIS MACHINE! HEATER SPORTS RECOMMENDS USING HEATER BOWLING MACHINE BALLS IN THE HEATER PRO MACHINE. THESE BALLS HAVE BEEN PRECISELY CRAFTED TO PROVIDE YOU WITH HOURS OF ACCURATE, TROUBLE FREE BATTING AND FIELDING PRACTICE.
  • Page 2: Leg Assembly

    ™ CRICKET BOWLING MACHINE INSTRUCTIONS IMPORTANT DO NOT RETURN THIS BOWLING MACHINE TO THE RETAIL STORE WHERE PURCHASED. CALL TOLL FREE: (800) 492-9334. WARNING: THIS PRODUCT IS TO BE USED BY ADULTS ONLY. SERIOUS BODILY INJURY MAY OCCUR! MAKE SURE MACHINE IS TURNED OFF BEFORE ASSEMBLY! KEEP HANDS AND ALL BODY PARTS AWAY FROM CRICKET ENTRY AND EXIT! SERIOUS HAND AND BODILY INJURY MAY OCCUR! LEG ASSEMBLY STEP 1: Slide leg sections together (See illustration).
  • Page 3 BOWLING MACHINE AUTO-BALL FEEDER ASSEMBLY STEP 1: Slide Sections A - B - C Together. Section C Section B Section A STEP 2: Insert 1/4” Short Bolt From Inside Of Feeder Through Hole In Feeder Bracket (4X). 1/4” Short Bolt STEP 3: Place Washer Over Short Bolt.
  • Page 4 HEATER PRO HEIGHT ADJUSTMENT PARTS LIST Tri-Pod Pivot Hole Hardware Metal Washer (Qty 2) Hex Head Bolt (Qty1) Nylon Hex Nut (Qty 1) Tri-Pod Slot Hardware U-Brace Pivot Hole Plastic Washer (Qty 2) Carriage Bolt (Qty1) Metal Washer (Qty 1) U-Brace Slot Hole Tri-Pod Pivot Hole Tri-Pod Pivot Slot...
  • Page 5 Pre-Operating Instructions Check The Air Pressure In The Heater Bowling Machine Tire. Warning: Make sure Heater Bowling Machine is unplugged and the tire is not spinning during these operations. Pre-Operation #1 Locate Allen Wrench (provided in package) and unscrew (3) three wheel cover screws.
  • Page 6 ™ Cricket Bowling Machine Instructions CAUTION! USE HEATER BOWLING MACHINE BALLS FOR THE MOST ACCURATE PITCH POSSIBLE. BOWLING MACHINES THAT USE A WHEEL TO THROW BALLS WILL NOT THROW REAL BALLS AS ACCURATE BECAUSE OF THE SEAMS ON THE BALL. IMPORTANT: THIS PRODUCT IS TO BE USED BY ADULTS ONLY.
  • Page 7 ™ Cricket Bowling Machine Instructions WARNING! ROTATING THE HEAD OF THE HEATER PRO FROM FAST BALL TO CURVE BALL POSITIONS CHANGE THE DIRECTION AND TRAJECTORY OF THE PITCHED BALL. MAKE SURE NO PERSONS ARE IN FRONT OF MACHINE WHILE ADJUSTING FOR FAST BALL OR CURVE BALL PITCHES.
  • Page 8 Knob Setting = 2, Est. Speed = 18 MPH • Knob Setting = 0, Est. Speed = 0 MPH Thank you for purchasing the Heater Pro Bowling Machine. If you have any questions or com- ments on how Heater Sports can improve the Heater Bowling Machine, please call our 24 hour customer service hotline at (800) 492-9334.
