Summary of Contents for BLAUBERG BLAUAIR CFV
- Page 1 Air hAndling unit BLAUAIR CFV USER’S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................19 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the BLAUAIR CFV unit and all its modifications. - Page 3 BlAuAir CFV www.blauberg-na.com DO NOT ALLOW CHILDREN TO OPERATE THE UNIT. DO NOT STORE ANY EXPLOSIVE OR HIGHLY FLAMMABLE SUBSTANCES IN CLOSE PROXIMITY TO THE UNIT. DO NOT OPEN THE UNIT DURING OPERATION. DO NOT BLOCK THE AIR DUCT WHEN THE UNIT IS SWITCHED ON.
- Page 4 BlAuAir CFV www.blauberg-na.com DO NOT MOUNT ROOM-TO-ROOM FAN IN A FIRE-RATED WALL. POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
-
Page 5: Purpose
BlAuAir CFV www.blauberg-na.com PURPOSE CAUTION! FOR GENERAL VENTILATING USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS AND VAPORS AS WELL AS FLAMMABLE MIXTURES, EVAPORATION OF CHEMICALS, STICKY SUBSTANCES, FIBROUS MATERIALS, COARSE DUST, SOOT AND OIL PARTICLES OR ENVIRONMENTS FAVOURABLE FOR THE FORMATION OF HAZARDOUS SUBSTANCES (TOXIC SUBSTANCES, DUST, PATHOGENIC GERMS). -
Page 6: Designation Key
BlAuAir CFV www.blauberg-na.com DESIGNATION KEY... -
Page 7: Technical Data
BlAuAir CFV www.blauberg-na.com TECHNICAL DATA The unit is designed for indoor or sheltered use. Outdoor unsheltered mounting is allowed provided an extra cover and weather hoods are installed on the air ducts (not included in the delivery set). The frost protection for the water drainage and connected pipelines must be provided during sub-zero ambient temperatures (if the unit is equipped with air cooler). -
Page 8: Unit
BlAuAir CFV www.blauberg-na.com ød Model BL02 CFV 1500(2500) BL03 CFV 3500 BL07 CFV 5000(6000) The full technical data list is stated in the supplied technical data sheet. UNIT UNIT DESIGN 1: drain pipe; 2: water heater (only for the units with water heater); 3: electric heater (only for the units with electric heater);... - Page 9 BlAuAir CFV www.blauberg-na.com The unit design provides change of the air duct positioning. For this purpose the side walls are plugged. To change positioning of the air ducts use the plugs from the side walls for the front panel. Intake air...
-
Page 10: Installation And Set-Up
BlAuAir CFV www.blauberg-na.com INSTALLATION AND SET-UP ALL OPERATIONS DESCRIBED IN THIS USER’S MANUAL MUST BE PERFORMED BY QUALIFIED PERSONNEL ONLY, PROPERLY TRAINED AND QUALIFIED TO INSTALL AND MAINTAIN VENTILATION EQUIPMENT. DO NOT ATTEMPT TO INSTALL THE PRODUCT YOURSELF. IT IS UNSAFE AND IMPOSSIBLE WITHOUT SPECIAL KNOWLEDGE. - Page 11 BlAuAir CFV www.blauberg-na.com Fill up the U-traps with water before using the system. The trap must be filled with water at all times as long as the system is operating. The condensate drainage system should not be directly connected to the common sewage system to avoid polluting the air with bacteria and odors.
- Page 12 BlAuAir CFV www.blauberg-na.com For the models with a water heater For the models without water heater Casing dimensions A [mm] BL02 CFV BL03 CFV BL07 CFV The delivery set includes removable levelling feet to adjust horizontal levelling of the unit and provide required clearance from the floor to enable correct mounting of the condensed water drainage.
-
Page 13: Connection To Power Mains
BlAuAir CFV www.blauberg-na.com CONNECTION TO POWER MAINS Connection to power mains must be conducted in compliance with the automation user’s manual. TECHNICAL MAINTENANCE WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:... - Page 14 BlAuAir CFV www.blauberg-na.com To access the heat exchanger remove the holder 13 (see page 7). Loosen the screws (1) on the retaining clamps (2) using a hexagon wrench. Pull the heat exchanger out.
-
Page 15: Storage And Transportation Regulations
BlAuAir CFV www.blauberg-na.com STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range +41 ˚F...+104 ˚F at RH not exceeding 70%. • Storage environment must not contain aggressive vapours and chemical mixtures provoking corrosion, insulation, and sealing deformation. -
Page 16: Manufacturer's Warranty
Production meets standard operating requirements in the USA and Canada. Blauberg warrants to the original purchaser of the unit that it will be free from defects in materials or workmanship for a period of 24 months from the date of original purchase. The Blauberg warrants to the original purchaser of the unit that the integrated control unit will be free from defects in materials and workmanship for a period of 24 months from the date of original purchase. - Page 17 BlAuAir CFV www.blauberg-na.com...
- Page 18 BlAuAir CFV www.blauberg-na.com...
-
Page 19: Certificate Of Acceptance
BlAuAir CFV www.blauberg-na.com CERTIFICATE OF ACCEPTANCE Unit Type Air handling unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 20 BUSA192-5EN-03...
