Summary of Contents for AL Tech Portable MPEG Player
-
Page 2: Table Of Contents
Introduction... 3 Specifications ... 3 Precautions... 4 System Requirements... 4 Package Content ... 4 Product Overview ... 5 1. Use as External USB HDD... 6 1.1 Insert Hard Disk... 6 1.2 Format Built-in HDD via USB ... 7 1.2.1 Windows 98SE, ME... 7 1.2.2 Windows 2000... - Page 3 2.2.3.2 Jpeg File Preview Setup ...22 2.2.3.3 Language Selection Setup...22 2.2.3.4 Check Firmware Version...22 2.3 Basic Screen Menu ...23 2.3.1 Media Type Selection ...23 2.3.2 File Selection...23 2.4 Play Video Files ...24 2.5 Play DVD Files...27 2.6 Play Music Files...29 2.7 Play Photo Files...31 2.8 Make a Play-List...33 2.9 Remote Controls...34...
-
Page 4: Introduction
Introduction Portable Mpeg4 Player is 2.5” HDD interface type of MPEG4 player based on USB 2.0 High Speed. It can be connected to TV in home or a monitor. It is not only an external USB HDD but also the best portable AV device that displays Music, Movie and photo. -
Page 5: Precautions
Precautions ▪ We strongly recommend you to back up the data to another safe media. We are not responsible for data damage or loss in built-in HDD. ▪ It’s better unplug the power adaptor when you do not use for a long time. ▪... -
Page 6: Product Overview
Product Overview ① Power Front ② HDD View ③ IR ④ IR Receiving Area ① USB ② 5V Back ③ IR/5.1 View ④ SD/HD ⑤ AV - Front View - ① Power ③ IR ② HDD Power LED HDD LED IR LED IR receiving area for remote signals - Back View -... -
Page 7: Use As External Usb Hdd
1. Use as External USB HDD 1.1 Insert Hard Disk Use 2.5” IDE Hard Disk for Laptop(or Notebook) PC. Hard Disk should be “Master”. However, if the Hard Disk supports “Single” mode, you need to try to set “Single “mode. ①... -
Page 8: Format Built-In Hdd Via Usb
1.2 Format Built-in HDD via USB If the built-in HDD is not formatted, PC can not detect the hard disk drive. If so, format the hard disk first referring to the following guide. * If the hard disk drive is already formatted, see “1.3 Copy Data via USB”. 1.2.1 Windows 98SE, ME 1) Install Windows 98 Driver. - Page 9 8) Select “ 1. Create Primary DOS Partition ” and press [Enter]. 9) Wait until finishing verifying the drive integrity. 10) After finishing drive integrity verification, type “Y” at “Do you wish to use the maximum available size for a Primary DOS Partition (Y/N)”. 11) Type the capacity or % which you want to use and press [Enter].
-
Page 10: Windows 2000
14) Type “ exit ” command at “ C:\WINDOWS> ” and press [Enter] for returning to windows screen. 15) Unplug the Mpeg4 Player and plug again. New volume will be appeared at [My Computer]. Click mouse right button at the new volume and select [Format]. - Page 11 5) Click [Next] at the Create Partition Wizard Windows. 6) Check [Primary Partition] and click [Next]. 7) Type number that you want to use and click [Next]. 8) Assign a drive letter and click [Next]. 9) Choose FAT32 or NTFS at File system to use and click [Next].
-
Page 12: Windows Xp
1.2.3 Windows XP 1.2.3 Windows XP 1) Connect Mpeg4 Player to PC via USB cable. (If not detected, plug the power cable of Mpeg4 Player) 2) Click [Settings→Control Panel→ Administrative Tools→Computer Management→Disk Management] on Windows. If you can not find Administrative Tools at Control Panel, click “... - Page 13 9) Choose FAT32 or NTFS at File system to use and click [Next]. FAT 32 system is available on windows 98SE/ME/2000/XP, but NTFS system is available on windows 2000/XP only. If you choose FAT32 system on Windows 2000/XP, one drive letter’s maximum size will be limited to 32GB. If you want to use one drive letter of 32GB more, you have to format on windows 98SE/ME.
-
Page 14: Copy Data Via Usb
1.3 Copy Data via USB 1.3 Copy Data via USB It is possible to use as a external USB hard disk drive.. You can copy data from your PC to built-in HDD of Mpeg4 It is possible to use as a external USB hard disk drive.. You can copy data from your PC to built-in HDD of Mpeg4 Player via USB. -
Page 15: Windows Me
1.3.2 Windows ME 1) After connecting Mpeg4 Player, windows itself will install driver automatically. And then, check the driver installation at Windows [Start > Settings > Control Panel > (view all Control Panel options) > System > Device Manager > Universal Serial Bus controllers > USB Mass Storage Device] 2) Check ‘My Computer’... -
Page 16: Windows 2000, Xp
1.3.3 Windows 2000, XP 1) After connecting Mpeg4 Player, windows itself will install driver automatically. And then, check the driver installation at Windows [Start > Settings > Control panel > (switch to classic View on Windows XP) > system > Hardware > Device manager > Universal Serial Bus controllers >... -
Page 17: Linux
1.3.4 Linux It can be available on Linux 2.4 higher. [Automatic Mount] After booting, do log-in. Connect Mpeg4 Player -> Power On Mpeg4 Player -> Check the detection with [fdisk] -> make Mount Pointer (ex. mediatest) at Folder Mount(/mnt) -> Edit [/etc/fstab] -> add the following; /dev/sda /mnt/mediatest vfat noauto, user 0 0 /dev/sda /mnt/mediatest ntfs noauto, user 0 0 Do Log-in again. -
Page 18: Use As Multimedia Player
2. Use as Multimedia Player 2.1 Connect to External AV Device 2.1.1 Connect Video Cable Mpeg4 Player supports 2 type of video output; “Composite, Component”. Use video connection that your TV supports. Normally, TV supports composite video connection. Do not connect USB cable when connecting TV. •Component Y, Pb, Pr •... -
Page 19: Connect Audio Cable
2.1.2 Connect Audio Cable Mpeg4 Player supports 2 type of audio output; “Stereo, Coaxial”. Use audio connection that your TV or Audio set supports. Do not connect USB cable when connecting TV. •Coaxial: Digital 5.1 Ch. • : Connect to IR/5.1 jack of Mpeg4 Player. Supplied Coaxial Cable... -
Page 20: Basic Setup
2.2 Basic Setup 2.2.1 Video Setup This is guide for setting video output of Mpeg4 Player. You have to setup Mpeg4 Player’s video output mode same as TV set’s video input mode. When you can not see normal screen after connecting video cable, check followings, 1. - Page 21 ① Turn on Mpeg4 Player and press [SETUP] on MediaType Selection screen. < Setup Procedure> ② Move to ‘Video Setup’ icon and press [ENTER]. ③ Move to Video Output Mode that you want and press [ENTER]. ④ Finally, press [SETUP] again for saving configurations.
-
Page 22: Audio Setup
2.2.2 Audio Setup This is guide for setting audio output of Mpeg4 Player. You can use Stereo or Digital 5.1 ch.. Analogue/DCPM: Select when you connect the supplied AV cables (Red / White) to TV or Audio set directly. Encoded Digital: Select when you want to listen through 5.1Ch by connecting receiver (or amplifier) with supplied coaxial cable. -
Page 23: Other Setup
2.2.3 Other Setup This is guide for setting TV Type, JPEG File Preview, Language Selection. In addition, current firmware version shows. ① Turn on Mpeg4 Player and press [SETUP] in MediaType Selection Screen. 2.2.3.1 TV Type Setup Select one among 4:3 Letter Box, 4:3 Pan Scan, or 16:9. 2.2.3.2 Jpeg File Preview Setup It is possible to enable or disable preview the photo file as a thumbnail image before playing. -
Page 24: Basic Screen Menu
2.3 Basic Screen Menu 2.3.1 Media Type Selection After turning on Mpeg4 Player, you can see MediaType Selection screen. In this screen, you can select “Video”, “Audio”, Photo” or make “Play-List” with ◀▶ arrow button. Press [ENTER]. Select one media type that you want to play. 2.3.2 File Selection After selecting a Media type, ‘File Selection’... -
Page 25: Play Video Files
2.4 Play Video Files It is possible to play video files like AVI, MPG, MPEG, DAT, M2V, and VOB. Select ‘Video’ icon in Media Type Selection screen. Video file list will be displayed. Just move to a file and press [ENTER] or [PLAY/PAUSE] button. - Page 26 Subtitle Language Select Subtitle Sync. 4, 5, 6 Subtitle Number Button Color Change Zoom Vertical Zoom Full Custom Scr. SIZE Default Screen Position Jump to TIME SEARCH Preferable Playback Time Delete Input CANCEL Numbers Control luminosity, Brt. CONT color depth, brightness Show File FILE INFO...
- Page 27 PLAY / PAUSE Playback Next All Files ▶ PLAY / PAUSE Pause ▶ I PREV Playback I◀◀ Previous File NEXT Playback Next File ▶▶ Screen Reset Number button After the file that you select, play next all files continuously. It is same as [PLAY/PAUSE] button.
-
Page 28: Play Dvd Files
2.5 Play DVD Files DVD manager function support to play DVD Ripping File same as original DVD. Make a folder and then save all ripping files into the folder. After connecting TV(or Monitor), select VIDEO_TS.IFO file at the folder. Make sure that all the ripping files including VIDEO_TS.IFO from one DVD title will be located at one folder. - Page 29 A-B REPEAT A-B repeat TITLE Go to Title Menu ANGLE Angle Show File FILE INFO Information Jump to Preferable TIME SEARCH Playback Time Delete Input CANCEL Numbers Control luminosity, Brt. CONT color depth, brightness PREV Playback I◀◀ Previous Chapter NEXT Playback Next Chapter ▶▶...
-
Page 30: Play Music Files
2.6 Play Music Files It is possible to play music files like MP3, OGG, WAV, WMA. Select Audio icon in Media Type Selection screen. Music file list will be displayed. Just move to a file and press [ENTER] or [PLAY/PAUSE] button. Select ‘Audio’... - Page 31 NEXT Playback Next File ▶▶ Go to 10 Sec. in Forward ▶▶ Go to 10 Sec. in Backward ◀◀ ENTER Playback a File PLAY / PAUSE Playback Next All Files ▶ PLAY / PAUSE Pause ▶ VOLUME + Volume Up VOLUME - Volume Down MUTE...
-
Page 32: Play Photo Files
2.7 Play Photo Files It is possible to play photo files like JPG(JPEG). Select Photo icon in Media Type Selection screen. Photo file list will be displayed. Just move to a file and press [ENTER] or [PLAY/PAUSE] button. Select Picture icon in Media Type Selection screen. Remote Control Function Show File... - Page 33 PLAY / PAUSE Playback Next All Files ▶ PLAY / PAUSE Pause ▶ Zoom In ▶▶ Zoom Out ◀◀ ANGLE Rotation 방향키 Panning ▲▼◀▶ ENTER Return to Ori g i n al Photo Control luminosity, Brt. CONT color depth, brightness Photo Slide Show If you play all files with 'Play All' icon or [PLAY/PAUSE], photo slide shows will be started.
-
Page 34: Make A Play-List
2.8 Make a Play-List User can register all media type of files like video, music, and photo to play-list. The registered media files to play-list will be played without discriminating media type. It is not possible to play each registered files independently. Use 'Play All, Random Play' icon or [PLAY/PAUSE] button. Additionally, registered play-list will be deleted after rebooting. -
Page 35: Remote Controls
2.9 Remote Controls This is guide for basic use of remote control. For more details, ‘2.3 Basic Screen Menu’, ‘2.4 Play Video Files’, ‘2.5 Play DVD Files’, ‘2.6 Play Music Files’, ‘2.7 Play Photo Files’, ‘2.8 Make a Play-List’. ENTER Play a File ▲▼◄►... -
Page 36: Others
After connecting TV set, move to the upgrade file and press [ENTER]. Upgrade is progressed automatically. After finishing upgrade, you can check firmware version on Setup screen. Press [SETUP] button. Technical Support Contact your local distributor in your country or AL Tech, Inc. in Korea www.airlinktek.com, Tel 82-2-3011-9219, Fax 82-2-566-6186, E-mail sales@airlinktek.com...
