Summary of Contents for AL Tech MG-25P
-
Page 2: Table Of Contents
Table of Contents C hapter 1. Portable Mpeg4 Player I ntroduction ... 3 M ain Specifications & Functions S upported Media Formats ... 3 R equired System (PC) ... 3 P re-Cautions ... 4 P roduct Specifications ... 5 P ackage ... - Page 3 1 . Play Video Files ...17 2 . Play Audio Files ..18 3 . Play Photos ...18 4 . Make Play-List ...19 5 . How to use Remote Control 6 . DVD Manager ...21 C hapter 7. Appendix ... 22 A ppendix.
-
Page 4: Chapter 1. Portable Mpeg4 Player
Chapter 1. Portable Mpeg4 Player Introduction This Mpeg4 Player is 2.5” HDD interface type of MPEG4 player based on USB 2.0 High Speed. It can be connected to TV in home or a monitor. It is not only an external USB HDD but also the best portable AV device that displays Music, Movie and photo. -
Page 5: Pre-Cautions
Pre-Cautions We strongly recommend to read the below “Pre-Cautions.. □ We strongly recommend you to back up the data to another safe media. We are responsible for the hardware of the Mpeg4 Player only but don’t have the responsibility for data damage or loss in a HDD. -
Page 6: Product Specifications
Product Specifications Product Name Portable Mpeg4 Player Power DC 5V/2A Weight 160g (without HDD) Dimension 80 x 148 x 24 mm Working 0˚ C ~ 50˚ C Temperature Working Humidity 10% ~ 75% Available OS Windows 98/SE/ME/2000/XP, MAC 9.0 higher, Linux 2.4 higher PC Interface 480Mbps USB 2.0 High-Speed(USB 1.1 compatible) HDD Type... -
Page 7: Package
Package Mpeg4 Player DC Adaptor USB Cable Remote Control This is basic accessories and shall be changed without prior notice (AV 1,2,3 Cable Length : 1M) Explanation of the exterior Appearance FRONT VIEW ① Power LED ③ IR LED ④ IR Receiver ②... -
Page 8: Chapter 2. How To Assemble & Insert Hdd
2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player Chapter 2. How to Assemble & Insert HDD This is how to assemble or disassemble HDD to/from the Mpeg4 Player. ※ [Note] : The HDD that is inserted to the Mpeg4 Player should be “Master”. -
Page 9: Chapter 3. How To Connect A Pc & The Mpeg4 Player
Chapter 3. How to Connect a PC & the Mpeg4 Player Connect a PC & the Mpeg4 Player with supplied USB Cable. [Note] : Installation Driver should be installed on a PC first for Windows 98/SE users. Refer to the below instructions. -
Page 10: 2) Windows Me/2000/Xp Users
●●● [Note] : Refer to how to remove the Mpeg4 Player safely from a PC ●●● (2) Windows ME/2000/XP Users [Note] : No need to installation any Installation Driver. Connect the Mpeg4 Player and a PC by using supplied USB Cable then the PC detect the Mpeg4 Player as a [USB Mass Storage Device] at [My Computer]. -
Page 11: Mac Users
2. MAC Users No need to install the installation driver at MAC OS 9.x version and the Mpeg4 Player will be detected automatically. If the Mpeg4 Player is detected correctly, an icon is appeared at a monitor. When remove the Mpeg4 Player safely, drag the icon to a trash and unplug the Mpeg4 Player. 3. -
Page 12: Chapter 4. Connect The Mpeg4 Player To External Av Devices By Cables
Chapter 4. Connect the Mpeg4 Player to external AV Devices by Cables This Mpeg4 Player supports Composite, S-Video, and Component for Video and Stereo & 5.1Ch sound by Digital Output (Coaxial). Refer to the below examples. 1. Connect by Composite for Video & Stereo for Audio It’s for normal TV connection. -
Page 13: Connect By S-Video For Video & Stereo For Audio
3. Connect by S-Video for Video & Stereo for Audio Connection for Video through S-Video and for Audio through Stereo Connect AV 2 Cable (Yellow, S- Video) to SV/5.1 Jack Connect S-Video (black color) to S-Video Jack of 4. Connect by S-Video for Video & 5.1Ch for Audio Connection for Video through S-Video and for Audio through 5.1Ch (Coaxial) After cable connection, set the Audio as 5.1Ch at Setup page of the Mpeg4 Player. -
Page 14: Connect By Component For Video & 5.1Ch For Audio
until you see the main page (Mpeg4 Player LOGO PAGE) and then press [Setup] button in order to match [Video] setup with TV. Connect AV 3 Cable (Yellow, Red, Green) to SV/5.1 Jack Connect COMPONENT (Pr) Jack of TV Connect to COMPONENT (Y) Jack of TV 6. -
Page 15: Chapter 5. Basic Setup Of The Mpeg4 Player
Chapter 5. Basic Setup of the Mpeg4 Player 1. Video Setup The default Video Setup is Composite Connection for general TV. If a general cable (Yellow) is connected, no need to change. If you want to connect by other cables, select a proper TV system (NTSC / PAL) for a TV to receive a correct video signal. -
Page 16: Audio Setup
⑤ Now, the new configuration is applying. ⑥ Be sure to press [Enter] button to change the new setup. Finally, press [Setup]button for saving configurations. ●●● [Note] ●●● If you see an abnormal screen, the TV does not support [Progressive]. In this case, press [Video] button on a remote controller until you have a normal screen. - Page 17 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player button. ●●● [Note] ●●● □ Setup of TV Type (Screen Ratio Configuration) : Select one (4:3 Letter Box, 4:3 Pan Scan, 16:9). □ JPEG File Preview : If enable “JPEG File Preview ON”, a small picture will be shown at the left side of a screen. □...
-
Page 18: Chapter 6. Play Video, Audio And Photo
Chapter 6. Play Video, Audio and Photo 1. Play Video Files Select [Video] -> Press [Enter] button then you will see video files you saved into the Mpeg4 Player. Select a file you would prefer and press [Enter] or [Play] button then the file will be played. [Menu Description] □... -
Page 19: Play Audio Files
2. Play Audio Files Select [Audio] -> Press [Enter] button then you will see audio files you saved into the Mpeg4 Player. Select a file you would prefer and press [Enter] or [Play] button then the file will be played. [Menu Description] □... -
Page 20: Make Play-List
2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player □ Volume + : Enlarge photos (Zoom In) □ Volume - : Reduce photos (Zoom Out) □ ANGLE Button : Rotate photos (Rotation) □ ▲ / ▼ / ▶ / ◀ buttons : Move photos to up, down, left and right (Panning) ●●●... -
Page 21: How To Use Remote Control
5. How to use Remote Control MENU Move to main menu while playing DVD. TITLE Move to Title menu while playing DVD. ANGLE Apply Angle function. (Photo Rotation) REPEAT Set Chapter/Title repeat. A-B REPEAT Set the A-B repeat. SLOW Play slowly 1/2, 1/4, 1/8. ENTER Save a new configuration /Select or play file. -
Page 22: Dvd Manager
2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player 6. DVD Manager DVD manager function support to play DVD Ripping File same as original DVD. Make a folder and then save all ripping files into the folder. After connecting TV(or Monitor), select VIDEO_TS.IFO file at the folder. -
Page 23: Chapter 7. Appendix
Chapter 7. Appendix Appendix. How to Format Hard Disk 1. Format on Windows 98/SE/ME ●●● [Note] : Check the windows 98 driver installation ●●● First of all, you have to install Windows 98 Driver before formatting. (1) After installing windows 98 driver, and the plug the Mpeg4 Player into USB port of your (2) Select [Start →... - Page 24 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (6) Type the last Disk number in 0% usage. (7) Select “1. Create DOS partition or Logical DOS Drive” and press [Enter]. (8) Select “ 1. Create Primary DOS Partition ” and press [Enter]...
- Page 25 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (9) Wait until finishing verifying the drive integrity. (10) After finishing drive integrity verification, type “Y” at “Do you wish to use the maximum available size for a Primary DOS Partition (Y/N)”...
- Page 26 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (11) Type the capacity or % which you want to use and press [Enter]. (12) Drive integrity verification will start again. After finishing that, press [ESC] key when the “Primary DOS Partition created, drive letters changed or added” message displays. (13) Press [ESC] key again.
- Page 27 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player 2. Format on Windows 2000 (1) Plug the Mpeg4 Player into USB port of your PC. (2) Select [Start → Settings → Control Panel → Administrative Tools → Computer Management → Disk Management] on Windows. (3) If the [Disk Signature and Upgrade Disk Wizard] is started, click Next to progress for finishing the wizard.
- Page 28 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (5) Click [Next] at the Create Partition Wizard Windows. (6) Check [Primary Partition] and click [Next]. (7) Type number that you want to use and click [Next].
- Page 29 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (8) Assign a drive letter and click [Next] (9) Choose FAT32 or NTFS at File system to use and click [Next] ●●● [Note] ●●● FAT 32 system is available on windows 98/SE/ME/2000/XP, but NTFS system is available on windows 2000/XP only. ●●●...
- Page 30 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player 3. Format on Windows XP (1) Plug the Mpeg4 Player into USB port of your PC. (2) Select [Settings → Control Panel → Administrative Tools → Computer Management → If you can’t find Administrative Tools at Control Panel, click Disk Management] on Windows.
- Page 31 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (5) Click [Next] at the New Partition Wizard. (8) Check [Primary Partition] and click [Next]. (9) Type number that you want to use and click [Next].
- Page 32 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player (10) Assign a drive letter and click [Next]. (11) Choose FAT32 or NTFS at File system to use and click [Next]. ●●● [Note] ●●● FAT 32 system is available on windows 98/SE/ME/2000/XP, but NTFS system is available on windows 2000/XP only. ●●●...
- Page 33 Appendix. Check the Driver Installation for the Mpeg4 Player at Windows 1. At Windows 98/SE 2. At Windows ME 3. At Windows 2000/XP 2.5” HDD MULTIMEDIA JUKIBOX Portable MPEG4 Player Check at [Start > Settings > Control Panel > System > Device Manager > Hard disk controllers >...
-
Page 34: Appendix. Non High-Speed Usb Hub Message
Appendix. Non High-Speed USB Hub Message The message will be displayed On windows XP when you plug the Mpeg4 Player into USB 1.1 spec. Host adapter. Appendix. Check when new local disk drive not be created. Check HDD’s jumper is master. Check to match the pin socket of the Mpeg4 Player with the pins of HDD.
