- Page 1 INSTALLATION MANUAL Quarza Granite Kitchen Sinks KGD-441 / KGD-442 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2024 Kraus USA Plumbing LLC I REV. October 7, 2024...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com /...
- Page 3 Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.
-
Page 4: Tools You Will Need
Jig Saw Tape Measure Phillips Screwdriver Pencil Masking Tape Hole Saw NOTE: Specialized tools may be necessary to install Kraus Quartz Composite Kitchen sinks with countertop materials other than wood, marble or granite. Parts List · Cut-Out Template Mounting Hardware... -
Page 5: Hardware Included
Hardware (Included) Kit for Undermount Kit for Drop-In Installation Installation Important Instructions may vary depending on countertop material. Read all instructions · carefully, and ensure that counters are compatible with sink installation before proceeding. · Follow the plumber’s code and builder’s code effective in your area. ·... - Page 6 Dimensions R3" Ø 1 1/2" R3/4" R1" (76mm) (19mm) (37mm) (24mm) 3 1/2" (90mm) 7" (178mm) R5/8" (16mm) 21 1/2" (544mm) 25" (635mm) Model #: KGD-441 Sink Dimensions: 25” x 22” x 9 1/8” Min Cabinet Size: 33” R1 3/8" R3/4"...
- Page 7 Option A: DROP-IN INSTALLATION 1. Trace Opening · Locate the drop-in template in the box. Cut carefully along the dotted lines. Keep the inside portion of the template. It contains important · information concerning care and maintenance for your new sink. ·...
- Page 8 2. Cut Opening · Using the drill, make a small starting hole of about 1/2” on the inside of the cutting line. · Drill a second time in the same hole with a larger bit to enlarge the hole so that the jigsaw can be inserted properly.
- Page 9 3. Add Additional Faucet Hole (Optional) · Determine the location of the faucet. · Place the sink upside down on a suitable flat surface. · Using the 32mm (1 1/4”) diamond hole saw at high power (1500tr. per break through in the desired location.
- Page 10 4. Install Sink · Clean and dry the surface around the opening of the sink. · Verify that the sink fits correctly in the opening. The edge of the sink must sit on the counter. · Turn the unit upside down to apply sealant. Apply silicone-based sealant (not included) underneath the edge of the sink.
- Page 11 Option B: UNDERMOUNT INSTALLATION 1. Trace Opening · Locate the undermount template in the box. Cut carefully along the dotted lines. Keep the inside portion of the template. It contains important · information concerning care and maintenance for your new sink. ·...
- Page 12 2. Cut Opening · Using the drill, make a small starting hole of about 1/2” on the inside of the cutting line. Drill a second time in the same hole with a larger bit to enlarge the hole so that the jigsaw can be ·...
- Page 13 3. Add Additional Faucet Hole (Optional) · Determine the location of the faucet. · Place the sink upside down on a suitable flat surface. · Using the 32mm (1 1/4”) diamond hole saw at high power (1500tr. per break through in the desired location.
- Page 14 4. Install Sink · Turn the sink upside down. Align the sink with the cutting line on the counter. · Using a pencil, mark 10 spots around the frame at a distance of about 1/4” (6.4mm) from the edge of the sink. ·...
-
Page 15: Maintenance
Do not leave sharp objects on the surface of the sink for an extended period of time. Do not use abrasive cleaning products, sanding tools, steel wool or bleaching products. Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance... - Page 16 Kraus warrants the structure and finish of the Kitchen Sink to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the sink was Kitchen Sink was first installed.
- Page 17 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 18 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
