Proceq equotip 540 Operating Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Operating Instructions
60 0 Y Ye e a ar rs s o o f f Iin nn no o v va at ti i o o n n
Swiss Precision since 1954

Advertisement

loading
Need help?

Need help?

Do you have a question about the equotip 540 and is the answer not in the manual?

Questions and answers

Related Manuals for Proceq equotip 540

Summary of Contents for Proceq equotip 540

  • Page 1 Operating Instructions 60 0 Y Ye e a ar rs s o o f f Iin nn no o v va at ti i o o n n Swiss Precision since 1954...
  • Page 2 1. Safety and Liability General Information This manual contains important information on the safety, use and main- tenance of the Equotip 540. Read through the manual carefully before the first use of the instrument. Liability Our “General Terms and Conditions of Sales and Delivery” apply in all cases. Warranty and liability...
  • Page 3 2. Getting Started The Equotip 540 is typically used for testing the hardness of metallic sur- faces. The user has a choice to select either Leeb rebound, the Portable Rockwell or UCI principle, see chapter “3.1 Performing Measurements”.
  • Page 4 Figure 1: Insert Battery There are three status LEDs on the right side of the display. The middle light is the power indicator which is when charging and turns to green when battery is fully charged. The lower LED is used for application spe- cific notification.
  • Page 5 Energy Saving Energy saving may be programmed as desired under System/Power settings. Connections Snap-in connectors Figure 2: Connections  For Leeb Impact Devices use the Snap-in connector 1.  For UCI Probe use the Snap-in connectors 1 or 2.  USB Host: Additionally connect a mouse, keyboard or USB stick. ...
  • Page 6 3. Main Menu On start up the main menu is displayed. All functions may be accessed directly via the Touchscreen. Return to the previous menu by pressing the back button or the return icon (arrow) at the top left corner of the Touchscreen. Measurement: Measurement display screen, see chapter “3.
  • Page 7 4. Measurement 4.1. Performing Measurements 4.1.1. Leeb Testing Procedure (except Leeb U) Select automatic compensation for impact direction “Automatic”, see chapter “3.2.1 Controls”. If “Automatic” is not allowed, set the impact direction (    ). The Equotip Leeb Impact Devices DL doesn’t support automatic mode. The impact direction must be selected manually. Select the appropriate material group, hardness scales and number of impacts per measurement series.
  • Page 8 measurement series are displayed. NOTE! Make sure the loading tube is allowed to slowly return back to the starting position. Do take care so the loading tube does not spring back uncontrolled, which may result in permanent device damage. NOTE! If possible, follow the standard practice of Leeb rebound hardness testing as described in the standards ISO 16859-1 (metallic materials), ASTM A956 (steel, cast steel and cast iron only), or other applicable standards.
  • Page 9 4.1.2. UCI Testing Procedure 1. Place the probe on the sample to test. The probe must be perpendicular to the surface (± 5°). The special foot can be used to increase repeatability and reduce distortion of the results, see chapter “14. Ordering Information”. 2.
  • Page 10 4.2. Measurement Screen 4.2.1. Controls (Only Equotip550) (Only Equotip 550) Figure 7: Measurement Screen...
  • Page 11 4.2.2. Measurement Views Equotip 540 is fully customizable as a device and can display three different measurement views simultaneously. Each view can be switched to meet the user’s requirements by simply clicking on the icon related to the particular display at the top right corner of each screen.
  • Page 12  Sample ID’s: Defines the custom field. 4.3. Measuring Methods Equotip 540 family of instruments included 2 model: Equotip 540 UCI and Equotip 540 LEEB D/DC. Equotip 550 family of instruments is capable of accepting three different test methods using a single...
  • Page 13 4.3.1. Equotip Leeb D/DL 4.3.1.1. Test Principle During measurement with Equotip 540 impact devices (D, DL); an impact body with a ball indenter is launched by spring energy against the sample to be measured, and then rebounds. Before and after the impact, a permanent magnet inside the impact body passes through a coil in which a voltage signal is induced by the...
  • Page 14 4.3.1.2. Sample Preparations Keep the sample free of vibrations during the test. Light and thin parts must be specially fastened, see chapter “3.3.1.6 Testing Light Samples”. Ensure that the surface of the work piece is clean, smooth and dry. If required, use appropriate cleaning agents for cleaning, such as acetone or isopropanol. Do not use water or any other detergent fluids.
  • Page 15 4.3.1.4. Test Conditions To ensure proper hardness readings, the following conditions must be fulfilled. If one or more conditions are not met, the measurement result may be significantly false. Impact device type D/DL Roughness grade class ISO 1302 Surface Max. roughness depth Rt (μm / μinch) 10 / 400 preparation Average roughness Ra (μm / μinch)
  • Page 16 4.3.1.5. Testing Light Samples If the samples are lighter than specified in chapter “3.3.1.4 Test Condi- tions” or sample sections have unfavorable mass distribution they can vibrate as the impact body hits the test point. This results in unwanted energy absorption. Such samples shall be supported by solid worktops. If the mass falls below the specific requirements but still exceeds the coupling amount then coupling it to a larger mass can help prevent vibra- tions.
  • Page 17 • The original HLDL-HB conversion curve for “1 Steel and cast steel” is now adapted using the two data points. The detailed procedure on how to create custom conversion curves in the Equotip 540 is given in chapter “6.4 Conversion Curve Creation”.
  • Page 18 In contrast, hardness scale conversions are correct only when the appropriate material group is selected. Free online material databases and the Equotip 540 on-board reference documents can be useful to assign your materials to one of the default material groups. Suitability of conversions should be qualified on calibrated samples before use.
  • Page 19 D/DC Steel and cast steel Vickers 81-955 80-950 101-964 84-1211 81-1012 90-646 81-646 101-640 83-686 81-694 Brinell 81-654 48-100 38-100 37-100 Rockwell 22-70 20-72 20-70 20-68 21-68 61-88 61-88 28-104 29-103 30-99 31-97 Shore 30-102 275-2194 275-2297 340-2194 283-2195 305-2194 σ1 Rm N/mm²...
  • Page 20 4.3.2. Equotip Ultrasonic Contact Impedance (UCI) 4.3.2.1.Test Principle The UCI method uses the same pyramid-shaped diamond as a conventional Vickers hardness tester. Unlike Vickers testing, no optical evaluation of the indentation is required, enabling fast and portable measurements. The UCI method excites a rod into an ultrasonic oscillation. The test load is applied by a spring and typically ranges from 1 to 10 kg of force (HV1 –...
  • Page 21 4.3.2.4. Test Conditions To ensure proper hardness readings, the following conditions must be fulfilled. If one or more conditions are not met, the result may be misleading. Probe setup HV1 (~10 N) HV5 (~50 N) Minimal required thickness 5 mm / 0.2 inch Minimal required weight 0.3 kg / 0.66 lbs Required surface roughness...
  • Page 22 The Equotip 540 offers for this a fast and easy way. Once the hardness value is converted to Vickers, it can be further converted to any other available hardness unit according to either the ASTM E140 or the ISO 18265.
  • Page 23 your instrument is fully operational and you can now continue with your measurements. NOTE! The performance check should be done regularly before using the instrument to verify the mechanical and electronic functions of the probe and the indicating device. This requirement is also included in the relevant hardness standards, see chapter “13.
  • Page 24 Conversion Standards – UCI The default measuring method is according to ASTM A1038 and DIN 50159. For conversions, the user has the choice to select either ISO 18265 or ASTM E140.26 © 2017 Proceq SA Impact direction (Leeb only) With exception to DL and U devices all Leeb impact devices have automatic direction compensation.
  • Page 25 5.1.3. Sample IDs After Measurement Use this setting to define if the current sample ID’s should be kept for the next measurement series or deleted. Edit Entries The entries of the different sample ID fields can be deleted or edited here. For easy increasing or decreasing, use the up- and down- arrows.
  • Page 26 UCI this option is not available.. NOTE! Storing signal data will cause measurement files to take up more memory. Enable Warnings Choose to enable warning display signals and sounds to indicate false measurements.© 2017 Proceq SA 27. Use report templates Here a template for the report can be selected.
  • Page 27 DIN 50157 Hardness testing of metallic materials with portable measuring instruments operating with mechanical penetration depth. o DIN 50159 Hardness testing with the UCI method.28 © 2017 Proceq SA o ASTM A956 Standard test method for Leeb hardness testing of steel products.
  • Page 28 5.3.1. Standard Conversions Proceq has developed correlations to convert the Leeb hardness measurements to other commonly used hardness scales based on groups of alloys that have a close relationship. The conversions for HLD and Material Group 1 (Carbon Steels) are standardized according to ASTM E140-12b.
  • Page 29 Click on and confirm with click on o The uploaded images appear in the Images Explorer© 2017 Proceq SA 29 NOTE! The USB stick must be either formatted in FAT or FAT32. NTFS is not supported. 5.4.2. Report template explorer The report templates can be managed here.

  • Page 30: Troubleshooting

    the measurement files in the data explorer of which a report should be created, mark them by ticking the box. Tap the button to create the reports. The report will be created with the selected report template. Repeat this for each file. A seperate PDF will be created for each measurement series. NOTE! The report option is only visible if an USB stick is connected to the instrument.
  • Page 31 Sample is insufficiently supported. Prepare the sample for the impact e.g. through use of the coupling method. If the instrument still shows excessive deviations: return the device to an authorized Proceq Service Centre for recalibration / inspection.© 2017 Proceq SA 41.
  • Page 32 Conditions” for the minimum requirement. Prepare the test piece for the test i.e. by supporting it with a larger metal piece. If the instrument still shows excessive deviations: Return the device to an authorized Proceq Service Centre for recalibration / inspection.
  • Page 33 process, don’t touch the display unit, as it can bias the calibration. 7. Technical Specifications 7.1. Instrument Display: 7” color display 800x480 pixels Memory Internal 8 GB Flash memory (up to 1’000’000 measurements) Regional settings Metric and Imperial units, multi-language and timezone supported Battery Lithium Polymer, 3.6 V, 14.0 Ah Battery lifetime >...
  • Page 34 7.4. Equotip UCI Probe Dimensions 155 x ø 40 mm (6.1 x ø 1.57 inches) without foot Weight 270 g (9.52 oz) Power Supply via Proceq Interface Measuring Range 20 – 2000 HV Measuring accuracy ± 2% (150 – 950 HV) Resolution...
  • Page 35 Test direction Any direction (no correction required) Trigger loads Selectable: HV1 (~9.8N), HV5 (~49N), HV10 (~98N) Diamond indenter Vickers diamond according to ISO 6507-2 Operating temperature 0 to 50°C (32 to 122°F) Humidity Non-condensing, 90% max. 8. Standards & Guidelines ISO 16859 ISO 18265 DIN 50156 / 50157 / 50159...
