ENDA ET2011 PID TEMPERATURE CONTROLLER
Thank you for choosing ENDA ET2011 temperature controller.
35x77mm sized.
Dual setpoint selection.
Thermocouple types or PT100 input selection (specify at order).
PID Self Tune.
Selftune automatic PID calculation or
manually enter PID parameters if known.
Soft-Start feature.
Zero point input shift.
Alarm or temperature control assignment for CA/2 relay output.
SSR Output control selection.
Heating/Cooling control selection.
Incase of sensor failure, manual control or relay positions can be selected.
CE Marked According to European Norms.
TECHNICAL SPECIFICATIONS
Input Type
PT100 Resistance thermometer
PT100 Resistance thermometer
J (Fe-CuNi) Thermocouple
K (NiCr-Ni) Thermocouple
T (Cu-CuNi) Thermocouple
S (Pt10Rh-Pt) Thermocouple
R (Pt13Rh-Pt) Thermocouple
ENVIRONMENTAL CONDITIONS
Ambient/Storage Temperature 0 ... +50°C/-25 ... +70°C (with no icing)
Max. Relative Humidity
80% Relative humidity for temperatures up to 31°C, decreasing linearly to 50% at 40°C.
Rated Pollution Degree According to EN 60529 ; Front Panel : IP62, Rear Panel : IP20
Max. 2000m
Height
KEEP AWAY device from exposed to corrosive, volatile and flammable gases or liquids and DO NOT USE the device in similar hazardous locations.
ELECTRICAL CHARACTERISTICS
Supply
110V AC / 230V AC +%10 -%20 , 50/60Hz ; 10-30V DC / 8-24V AC SMPS
Power Consumption
Max. 5VA
Wiring
Power connector: 2.5mm²' screw-terminal conenction.
Line Resistance Max. 100?
Data Retention EEPROM (minimum 10 years).
EMC EN 61326-1: 2013
Safety Requirements EN 61010-1: 2010 (Pollution degree 2, overvoltage category II)
OUTPUTS
Relay : 250V AC, 8A (for resistive load), Selectable as NO+NC Control or Alarm2 output.
C/A2 Output
SSR Output
Max 20mA 12Volt (as control output).
Life Expectancy for Relay
Mechanical 30.000.000; Electrical 100.000 operation. 250V AC, 8A (resistive load).
CONTROL
Control Type Single set-point and alarm control.
Control Algorithm
A/D Converter 12 bit.
Sampling Time
100ms.
Proportional Band
Can be adjusted between 0% and 100%. If Pb = 0%, On-Off control is selected.
Can be adjusted between 1 and 250 seconds.
Control Period
Hysteresis
Can be adjusted between 1 and 50°C/F.
Output Power
The ratio of power at a setpoint can be adjusted between 0% and 100%.
HOUSING
Housing Type
Suitable for flush-panel mounting according to DIN 43 700.
Dimensions
W77xH35xD71mm
Weight Approx. 215g (after packing)
Self extinguishing plastics.
Enclosure Material
Avoid any liquid contact when the device is switched on.
DO NOT clean the device with solvent (thinner, gasoline, acid etc.) and / or abrasive cleaning agents.
SURAN

Industrieelektronik
An der Hanfrötze 6 / D-77731 Willstätt
°C
EN 60751
-99.9...300.0 °C
EN 60751
-200...600 °C
EN 60584
0... 600
EN 60584
0...1300
EN 60584
0... 400
EN 60584
0...1700
EN 60584
0...1700
Tel.: +49 (0)7852 / 4889 962
Order Code : ET2011 -
1- Supply Voltage
230...230V AC
110...110V AC
LV.......10-30V DC /
Scale Range
°F
-99.9...543.0 °F
-328...1112 °F
°C +32... +1112 °F
°C +32... +2372 °F
°C +32... +752 °F
°C +32... +3092 °F
°C +32... +3092 °F
E-mail : info@suran-elektronik.de
Internet : www.suran-elektronik.de
°F SSR
C/A2
