Assembly Instructions
Caution: You must read this before you proceed
Please look in the Leg for Hardware Packs
PLANTER
Caution: This Planter is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever moving/lifting the Planter and to prevent damage to the Planter, two
adults are required to execute these actions.
Noble House Home Furnishings LLC
9
Advertisement
Related Manuals for Noble House Home Furnishings PLANTER
Summary of Contents for Noble House Home Furnishings PLANTER
- Page 1 Caution: This Planter is NOT a TOY. Keep your child/children at bay during the assembly process. Whenever moving/lifting the Planter and to prevent damage to the Planter, two adults are required to execute these actions. Noble House Home Furnishings LLC...
-
Page 2: Part List
Part List Label Picture Description Front Panel Back Panel Right Panel Left Panel Bottom Panel Left Leg Support Right Leg Support Noble House Home Furnishings LLC... - Page 3 First Leg Support Second Leg Support Bar Wheel Left Leg Right Leg Hardware Label Picture Description ① Screw (M6x25mm) ② Screw (M6x45mm) ③ Screw (M6x55mm) ④ Bolt (M6x25mm) ⑤ Allen Key Noble House Home Furnishings LLC...
-
Page 4: Assembly Preparation
This Planter has multiple parts and may require up to 20 minutes to assemble. To give you an overview of the Planter parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. - Page 5 With assistance from your adult partner, attach the Front Panel(A) and the Back Panel(B) to the Left Panel© and the Right Panel(D) using 8 Screws(①) and the Allen Key(⑤) as shown in the above picture. Do not fully tighten the Screws. Noble House Home Furnishings LLC...
- Page 6 Attach the assembled part in Step 3 to the assembled part in Step 2 using Screws(③) and the Allen Key(⑤) as shown in the above picture. Do not fully tighten the Screws. Noble House Home Furnishings LLC...
- Page 7 With assistance from your adult partner, turn the assembled part in Step 5 right side up. Then place the Bottom Panel(E) into the base of the Planter in the direction of the arrow as shown in the above picture. Noble House Home Furnishings LLC...
- Page 8 Step 7 In a sequential manner, gradually tighten all Screws, Bolts at all joints until evenly secured. Inspect the Planter and make sure all parts are adequately connected. Your Planter is ready for use. Noble House Home Furnishings LLC...
- Page 9 Noble House Home Furnishings LLC...
