Assembly Instructions
Caution: You must read this before you proceed
Please look underneath seat panel for hardware packs
CAUTION : This Adirondack Chair is NOT a TOY.
Keep your child / children at bay during the assembly process.
For moving the Adirondack folding and to prevent damage to the
Adirondack Chair, two adults are needed to execute this action.
Noble House Home Furnishings LLC
ADIRONDACK CHAIR
Page 1 OF 9
Advertisement
Related Manuals for Noble House Home Furnishings ADIRONDACK CHAIR
Summary of Contents for Noble House Home Furnishings ADIRONDACK CHAIR
- Page 1 Keep your child / children at bay during the assembly process. For moving the Adirondack folding and to prevent damage to the Adirondack Chair, two adults are needed to execute this action. Page 1 OF 9 Noble House Home Furnishings LLC...
-
Page 2: Parts List
Parts List Description Label Picture Seat Panel Backrest Support Bar of Front Leg Right Armrest Left Armrest Folding Support Bar Right Front Leg Left Front Leg Page 2 OF 9 Noble House Home Furnishings LLC... - Page 3 Picture Bolt (M x 6 35 mm Plastic Washer (Ø6.5/Ø1 x2mm) Screw ( M6x60 Screw ( M x 4 30mm (Use with Screwdriver) Allen Wrench Screwdriver (Not provided) Before Beginning Assembly: Page 3 OF 9 Noble House Home Furnishings LLC...
- Page 4 Left Front Leg (H) FRONT FACING This Adirondack Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Adirondack Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 Attach Pre-fixed Front Leg in Step 2 to Seat Panel (A) using Bolt ( 1 ), Plastic Washer ( 2 ), and Allen Wrench ( 5 ). Do not fully tighten Bolts Note: The Plastic Washer should be placed between the Seat Panel and Front Leg. Page 5 OF 9 Noble House Home Furnishings LLC...
- Page 6 Attach Folding Support Bar(G) to Seat Panel(A) using Bolt ( 1 ), Plastic Washer ( 2 ), with Allen Wrench ( 6 ). Do not fully tighten Bolts. Note:Plastic Washer should be placed between Seat Panel and Folding Support Bar. Page 6 OF 9 Noble House Home Furnishings LLC...
- Page 7 Note: Plastic Washer should be placed between Right Armrest and Right Front Leg. Repeat the same process with the Left Armrest (H). In a sequential manner, tighten all Bolts and Screws at all joints until fully locked into position. Page 7 OF 9 Noble House Home Furnishings LLC...
- Page 8 To open: pull the Backrest and Seat up as indicated by the arrows, then insert the Wooden Pins through the Legs. Note: This Adirondack Chair is heavy, always have a second adult to assist whenever moving or lifting it. Page 8 OF 9...
-
Page 9: Care And Maintenance
Not for commercial use. For residential use only . Stains may be removed with mild soap solution and damp cloth. Dust and pick-up spills using a clean, non-colored, lint-free cloth . Page 9 OF 9 Noble House Home Furnishings LLC...
